Kollmorgen CE06200-1H348H12

Product Description:​
CE06200-1H348H12 is a custom-ordered AKM-family servo motor — 62 mm frame size, approx. 2.0 kW rated, 12.7 Nm continuous torque at 3000 RPM (some references show 6.37 Nm @ 3000 RPM for standard AKM62 — the CE code may indicate special winding or stack). The suffix "1H348H12" defines special shaft, feedback (likely Hiperface or EnDat 2048/2048), connector orientation, and sealing.

Kollmorgen P02406-NBC

Product Description:​
The "P" prefix generally refers to Kollmorgen's Goldline P-Series (or sometimes re-badged as part of Goldline+ / BMH lineage in later catalogs)​ — medium/high inertia, larger frame servo motor for 230/400 VAC. Frame 240 ≈ 240 mm flange, stack 6 (long), winding C, with resolver and brake (B = brake, C = connector/config). These were used in demanding continuous-duty applications needing higher inertia match.

Kollmorgen B01206-NBS

Product Description:​
B01206-NBS is a Goldline B-series low-inertia brushless servo motor — Frame size 120 (≈ 120 mm flange / 4.53"), stack length 6 (longest for that frame), winding B (230 VAC class), with resolver feedback and NEMA flange. "NBS" typically indicates no brake, standard resolver, sealed MS connectors.

Kollmorgen AKD-B00606-MBA

Product Description:​
This is the AKD "B" variant — AKD-BASIC, which integrates an onboard IEC 61131-3 motion controller (BASIC programming language) allowing standalone single-axis control without an external PLC. "006" = 6 A RMS continuous; "06" = 240 VAC (85–265 VAC 1/3-phase); "-MBA" denotes BASIC CPU, MMC slot, standard I/O, no fieldbus master (can use Modbus TCP or pulse/analog).

Kollmorgen AKD-P01207-NA

Product Description:​
The AKD-P01207-NA is a 480 VAC 3-phase Ethernet-based servo drive from the AKD platform. "P" = EtherCAT® communication; "012" = 12 A RMS continuous; "07" = 480 VAC (187–528 VAC input range); "-NA" = no additional option cards. It provides high-bandwidth torque/speed/position loops and is configured via Kollmorgen WorkBench software.

Kollmorgen CE06250-2G306B1

Product Description:​
The "CE" prefix denotes a Custom Engineered (CE) AKM-family servo motor. CE06250-2G306B1 indicates a 62 mm frame (AKM62), approx. 2.5 Nm rated torque, 3000 RPM nominal, with specific winding, feedback (incremental encoder or SFD), connector orientation, and sealing specified by the suffix "2G306B1". These motors are optimized to work with AKD-series drives.

Kollmorgen D55001-00000000

Product Description:​
The Kollmorgen part number D55001-00000000 most commonly references an external Dynamic Braking (Regenerative Discharge) Resistor Kit or Mounting Bracket/Accessory​ used with S700 or AKD drives for dissipating regenerated energy when a large inertial load decelerates. Exact resistance/power rating should be confirmed from the project BOM or Kollmorgen ordering code — D550xx series are often braking resistors or interface modules.

Kollmorgen B-102-A-29-02

Product Description:​
The B-102-A-29-02 is a compact, low-inertia permanent magnet brushless DC (BLDC/PMSM) servo motor from Kollmorgen's legacy Goldline B family. Frame size 102 (≈ 2.36" / 60 mm flange), winding A (230 VAC line-to-line), stack length 2, with resolver feedback and standard NEMA/metric mount. Designed for rapid acceleration/deceleration cycles.

Kollmorgen S70362-NANANA

Product Description:​
This is a high-current variant of the S700 series. The "36" denotes 36 A RMS continuous output (some documentation lists S70362 as 36 A cont. / 72 A peak; S70302 = 30 A / 60 A — verify exact label). It shares all S700 platform features: EtherCAT/CANopen onboard, STO, multi-feedback, MMC slot, three option card slots (all "NA" = empty). Intended for large-frame servo motors or multi-motor regenerative systems.

Kollmorgen S70602-NANANA-NA

Product Description:​
The S70602-NANANA-NA is a high-performance digital single-axis servo drive from Kollmorgen's S700 series. It accepts 208–480 VAC 3-phase input and delivers 6 A RMS continuous / 18 A RMS peak output current. The "NANANA" suffix indicates no option cards installed in the three expansion slots—onboard EtherCAT and CANopen are standard. It is designed for complex motion tasks requiring high dynamic response, autotuning, and multi-feedback support.

Kollmorgen 65WKS-M310/22

Product Introduction:​
The 65WKS-M310/22 is a Kollmorgen S300 (SERVOSTAR 300) series digital servo amplifier, also marketed as SERVOSTAR 310. It is an earlier-generation drive preceding the AKD series but still widely used in legacy installations. "65WKS" is the Indramat/Kollmorgen legacy naming; "M310" = 310 model (10 A continuous), "/22" = firmware/option version.

Kollmorgen B-204-B-23

Product Introduction:​
The Kollmorgen "B-xxx-B-xx" numbering is characteristic of the legacy Goldline B-series frameless permanent magnet brushless motor kits. The B-204 is the frame size (diameter/stack length group); "-B-23" specifies winding configuration, magnet grade, and stack length variant. These are frameless kits​ — rotor (magnet ring + hub) and stator (wound laminations + leads) only — intended to be built into a machine's own structure (bearing set, housing provided by machine designer).
