Product Series: B&R X20 Series (Compact I/O System) Product Introduction: The B&R X20DI9371 is an 8-channel digital input module from the B&R X20 compact I/O system. It accepts 24 VDC digital signals from field sensors, switches, and encoders. The module supports both sink (NPN) and source (PNP) input configurations, making it universally compatible with all standard field device types. It connects to the X20 backplane via the M12 connector interface.
Product Series: B&R X20 Series (Compact I/O System) Product Introduction: The B&R X20DC2398 is a 8-channel digital output module from the B&R X20 compact I/O system. It provides 8 sink-type digital output channels operating at 24 VDC with a maximum current rating of 0.5 A per channel. This module is designed for direct field device control in industrial automation environments and integrates seamlessly into the B&R X20 backbone system via the M12 connector interface.
Product Series: B&R X20 BM Series (Communication) Product Overview: The X20BM11 is a CANopen communication module for the B&R X20 I/O system. It enables the X20 I/O station to communicate on a CANopen network (CiA 301 / CiA 402 compliant) at speeds up to 1 Mbit/s. This module is ideal for decentralized I/O architectures using CANopen as the fieldbus.
Product Series: B&R X20 BM Series (Communication) Product Overview: The X20BM05 is a PROFIBUS DP slave communication module for the B&R X20 I/O system. It enables the X20 I/O stations to communicate with a PROFIBUS DP master (such as a Siemens S7 PLC) at transmission speeds up to 12 Mbit/s. This module bridges the X20 backplane bus with the PROFIBUS DP fieldbus.
Product Series: B&R X20 BC Series (Counter / High-Speed I/O) Product Overview: The X20BC0083 is a 3-channel counter and high-speed input module for the B&R X20 I/O system. It supports incremental encoder inputs (A/B phase), frequency measurement, and pulse counting at speeds up to 1 MHz. This module is essential for position feedback, speed measurement, and motion control applications.
Product Series: B&R X20 BB Series (Digital Input — High Voltage) Product Overview: The X20BB82 is an 8-channel digital input module designed for 48 V DC input signals. It provides group galvanic isolation and is intended for applications where higher voltage digital signals are used, such as in systems with 48 V DC control circuits or long cable runs requiring higher noise immunity.
Product Series: B&R X20 BB Series (Digital Input with Diagnostics) Product Overview: The X20BB81 is an 8-channel digital input module with full per-channel diagnostics including wire-break detection and short-circuit detection. It is the diagnostic variant of the X20BB80, delivering the same channel count with enhanced fault monitoring.
Product Series: B&R X20 BB Series (Digital Input) Product Overview: The X20BB80 is an 8-channel digital input module for 24 V DC signals in the B&R X20 I/O system. It provides group galvanic isolation and is designed for applications requiring a moderate number of digital inputs in a compact form factor.
Product Series: B&R X20 BB Series (Digital Input with Diagnostics) Product Overview: The X20BB57 is a 16-channel digital input module with full diagnostic capability including wire-break detection and short-circuit detection. It is the diagnostic-enhanced version of the X20BB52, designed for applications where input integrity monitoring is mandatory.
Product Series: B&R X20 BB Series (Digital Input) Product Overview: The X20BB52 is a 16-channel digital input module for the B&R X20 I/O system. It accepts 24 V DC signals and provides galvanic isolation between channel groups. This module is designed for standard on/off signal acquisition from sensors, switches, and proximity detectors in machine automation.
Product Series: B&R X20 AT Series (Analog Temperature Input) Product Overview: The X20AT6402 is a 4-channel analog input module designed for RTD (Resistance Temperature Detector) signal acquisition. It supports Pt100, Pt1000, Ni100, Ni1000, and Cu50 sensors with 2-wire, 3-wire, and 4-wire connection modes. The module delivers 16-bit resolution with per-channel galvanic isolation.
Product Overview: The X20AT4222 is a 4-channel analog input module designed for thermocouple signal acquisition. It is part of the B&R X20 I/O system and is engineered for high-precision temperature measurement in industrial automation environments. The module features galvanic channel-to-channel isolation and supports 8 thermocouple types directly.
