Yokogawa FU20-05-T2-NPT Turbine Flowmeter with NPT Connection

Technical Specifications:

  • Measurement Range: 0.05-0.5m³/h for liquids, 0.5-5m³/h for gases, covering a wide flow range.
  • Accuracy: ±0.5% of reading for liquids, ±1.0% of reading for gases, ensuring measurement precision.
  • Repeatability: ±0.1% of reading, providing consistent measurement results.
  • Operating Temperature: -20℃ to 120℃, compatible with various process temperatures.
  • Operating Pressure: Up to 10MPa, suitable for high-pressure applications.
  • Output Signal: 4-20mA DC current signal and pulse output, frequency proportional to flow rate.
  • Connection Type: 1/2-inch NPT male thread, ensuring secure installation.
  • Material: 316 stainless steel body, corrosion-resistant for harsh media.

Yokogawa SR5030B85 High-Precision Servo Drive for Direct Drive Motors

Technical Specifications:

  • Rated Output Power: 3kW, matching 3kW direct drive motors.
  • Input Voltage: Three-phase AC 200-240V, 50/60Hz, voltage tolerance ±10%.
  • Output Current: 15A continuous, 22.5A peak, meeting motor current demands.
  • Control Modes: Position, speed, torque control, freely switchable via configuration.
  • Positioning Accuracy: ±0.01°, enabling ultra-precise positioning.
  • Communication Interfaces: RS-485 (Modbus/RTU), Ethernet (EtherCAT), supporting real-time data transmission.
  • Operating Temperature: 0℃ to 40℃, storage temperature: -20℃ to 60℃.
  • Protection Rating: IP20, suitable for cabinet installation.

Yokogawa DR1015B80 High-Torque Direct Drive Servo Motor

Technical Specifications:

  • Rated Torque: 15N·m, peak torque: 45N·m, meeting heavy-load motion requirements.
  • Rated Speed: 1000rpm, maximum speed: 2000rpm, balancing speed and torque.
  • Encoder: 23-bit absolute encoder, providing precise position feedback with a resolution of 8,388,608 pulses per revolution.
  • Stator Resistance: 1.2Ω, inductance: 3.5mH, ensuring efficient power conversion.
  • Rotor Inertia: 0.0012kg·m², enabling fast acceleration/deceleration.
  • Operating Temperature: 0℃ to 40℃, storage temperature: -20℃ to 60℃.
  • Protection Rating: IP65, dustproof and waterproof for industrial environments.

Yokogawa CP134E-16-S1

  • Technical Specifications:
    • Number of Channels: 16 isolated channels, ensuring no cross-interference.
    • Input Signal: 24V DC, ON at 19.2V DC min, OFF at 5.0V DC max, input current 3mA per channel.
    • Input Impedance: 8kΩ when ON, ≥1MΩ when OFF.
    • Response Time: ≤1ms, enabling rapid signal capture.
    • Isolation Voltage: 500V AC between channels and backplane.
    • Data Update Cycle: 10ms, providing real-time data refresh.
    • Operating Temperature: -10℃ to 55℃, storage temperature: -20℃ to 60℃.
    • Power Consumption: 1.5W (24V DC), low energy consumption.

Yokogawa F3SP534S

echnical Specifications:

  • Safety Integrity Level (SIL): Designed to meet SIL 3 requirements for high-risk applications.
  • Input/Output (I/O) Capacity: Multiple safety inputs and outputs for connecting safety devices such as emergency stop buttons, safety interlocks, and light curtains.
  • Communication: Supports various industrial communication protocols for integration with control systems and HMI (Human-Machine Interface).
  • Programming: User-friendly programming software for configuring safety functions and logic.

Yokogawa UD1AG3-100N-D-2TA-N+DM1A-100G

  • Technical Specifications:
    • Flow Measurement Range: Depends on the pipe size and fluid properties, but typically covers a wide range of flow rates.
    • Accuracy: High accuracy, often within ±1% of reading for clean liquids.
    • Display Module (DM1A-100G): Provides local readout of flow rate, totalized flow, and other relevant parameters.
    • Communication: May include digital communication interfaces for integration with control systems.

Yokogawa DYA-E2D-CS1

  • Technical Specifications:
    • Measurement Range: Typically covers a wide range of pressures, depending on the specific model variant.
    • Accuracy: High accuracy class, often within ±0.1% FS (Full Scale).
    • Display: Digital LCD display for clear readout of pressure values.
    • Output Signals: May include analog outputs (e.g., 4-20 mA) and digital communication interfaces (e.g., RS-485).

Yokogawa YA11F-SMS4/FMF1/TBR1

  • Product Name: Yokogawa YA11F-SMS4/FMF1/TBR1 (Discontinued Model)
  • Product Introduction: The YA11F series was designed for precise measurement and control in industrial processes. Although this specific model has been discontinued, it was part of Yokogawa's range of field instruments known for reliability and accuracy.

Yokogawa UR5CG3-015N/DR5C-015G

Technical Specifications:

  • UR5CG3-015N Servo Drive:
    • Rated Output Power: 1.5kW, matching the 1.5kW direct drive motor.
    • Input Voltage: Three - phase AC 200-240V, 50/60Hz.
    • Output Current: 7.5A (continuous), 11.2A (peak).
    • Control Mode: Position control, speed control, torque control.
    • Positioning Accuracy: ±0.01°, which can achieve ultra - high - precision positioning.
    • Communication Interface: RS - 485, Ethernet, supporting multiple communication protocols.

Yokogawa UT350-00 Advanced Digital Indicating Temperature Controller

Technical Specifications:

  • Input Type: Universal input, supporting thermocouple (K/J/T/B/R/S/E/N), RTD (Pt100/JPt100/Cu100), 0-10V DC voltage, 0-20mA DC current, and 0-100mV DC millivolt signals.
  • Indication Accuracy: ±0.1% of full scale, ensuring precise measurement.
  • Control Cycle: 200ms, fixed cycle to ensure stable control.
  • Control Output: Optional 4-20mA current output, voltage pulse output, and relay contact output.
  • Communication Interface: Ethernet (Modbus/TCP), RS - 485 (Modbus/RTU), supporting data interaction with the upper - level system.
  • Working Voltage: 100-240V AC, 50/60Hz; optional 24V DC power supply.
  • Working Temperature: -10℃ to 55℃, storage temperature: -20℃ to 60℃.

Yokogawa ISC40FF-SA Inductive Conductivity Sensor

Technical Specifications:

  • Measurement Range: 0-2000mS/cm, which can meet the measurement needs of high - conductivity solutions.
  • Measurement Accuracy: ≤0.5% of reading ±1.0μS/cm, ensuring the accuracy of measurement results.
  • Process Temperature Range: PEEK material: -20℃ to 130℃; PFA material: -20℃ to 100℃.
  • Process Pressure Range: PEEK material: up to 20bar (depending on the installation method); PFA material: up to 10bar.
  • Built - in Temperature Sensor: Pt1000, which can realize automatic temperature compensation of conductivity measurement.

Yokogawa UT150L-RN FM-Certified Limit Temperature Controller

Technical Specifications:

  • Input Type: Universal input, supporting thermocouple (K/J/T/B/R/S/E/N), RTD (Pt100/JPt100/Cu100), and DC mV/V signals.
  • Indication Accuracy: ±0.1% of full scale, ensuring the accuracy of temperature measurement.
  • Control Type: Upper - limit or lower - limit control, with a latching function after the limit is triggered.
  • Control Output: Relay contact, voltage pulse, or 4-20mA current output, which can be selected according to the control object.Optional Functions: Dual alarm output, measurement value (PV) forwarding output, and RS - 485 communication (supporting Modbus protocol).
