Yokogawa AAI543-H53

Technical Specifications:

  • Number of channels: 16 isolated channels.
  • Input signal: 4-20mA DC, 0-20mA DC, 1-5V DC, etc..
  • Accuracy: ±0.1% of full scale.
  • Data update cycle: 10ms.
  • Input resistance: 270Ω (20mA) to 350Ω (4mA) when powered on, 500kΩ or more when powered off.

Yokogawa F3SP22-0S

Technical Specifications:

  • Safety integrity level: SIL 2, in line with IEC 61508 standard.
  • Number of input/output channels: 16 safety-related input channels, 16 safety-related output channels.
  • Input signal: 24V DC (sinking/sourcing type).
  • Output signal: 24V DC, each channel current 2A.
  • Response time: ≤10ms.
  • Working voltage: 24V DC, current consumption ≤ 1A.
  • Working temperature: -20~70°C.

Yokogawa ADV151-PF3

Technical Specifications:

  • Number of channels: 32 isolated digital input channels.
  • Input signal: 24V DC (input voltage range 19.2-30V DC).
  • Input current: ≤5mA per channel.
  • Response time: ≤1ms.
  • Isolation: 500V AC between channels, 2kV AC between input and system for 1 minute.
  • Working temperature: -20~70°C (comply with ISA standard G3 option).
  • Connection method: Pressure clamp terminal (with surge absorber), model ATB5S-10.

Yokogawa EB501-10

Technical Specifications:

  • Communication bus: Compatible with Yokogawa's proprietary ESB bus, supporting dual redundancy configuration.
  • Number of communication ports: 2, supporting redundant connection.
  • Data transmission rate: 100Mbps (full-duplex).
  • Working voltage: 24V DC, current consumption ≤ 500mA.
  • Working temperature: -20~70°C.
  • Isolation: Bus and system isolation voltage 1.5kV AC for 1 minute.

Yokogawa DL1640Yokogawa DL1640

Technical Specifications:

  • Analog bandwidth: 200MHz.
  • Sampling rate: 200MS/s (4 channels simultaneously).
  • Maximum record length: 8MW (DL1640).
  • Display: 6.4-inch wide-view TFT color LCD.
  • Input channels: 4 isolated analog channels.
  • Input voltage range: 1mV/div - 10V/div (1-2-5 step).
  • Interface: Optional USB, Ethernet, PC card, Zip drive, floppy drive.
  • Power supply: DC power module + battery pack, supporting AC input.

Yokogawa 440A-EDS4G-914

Technical Specifications:

  • Measurement range: -0.1~32MPa (C diaphragm) / -0.1~50MPa (D diaphragm).
  • Reference accuracy: ±0.12% of span (including linearity, hysteresis, and repeatability).
  • Output signal: 4-20mA DC, optional FOUNDATION Fieldbus or PROFIBUS PA digital communication.
  • Power supply: 10.5-42V DC (normal/explosion-proof type), 10.5-32V DC (intrinsically safe type).
  • Damping time constant: 0.2-64 seconds adjustable.
  • Isolation: Input and system isolation voltage 2kV AC for 1 minute.

Yokogawa F3AD08-4V Channel Analog Input Module for PLC

Technical Specifications:

  • Number of Channels: 8 isolated channels, no cross-interference.
  • Input Signal: 0-5V DC, 1-5V DC, -10 to +10V DC, 0-10V DC, selectable per channel.
  • Resolution: 12-bit A/D conversion, capturing subtle signal changes.
  • Accuracy: ±0.1% of full scale, ensuring precise signal conversion.
  • Sampling Cycle: 1ms per channel, enabling rapid data acquisition.
  • Isolation Voltage: 500V AC between channels and backplane.
  • Operating Temperature: 0℃ to 40℃, storage temperature: -20℃ to 60℃.
  • Power Consumption: 1.2W (24V DC), low energy consumption.

Yokogawa RB301 Redundant Bus Module

Technical Specifications:

  • Bus Type: Dual redundant internal bus, supporting data transmission rates up to 100Mbps.
  • Switchover Time: ≤1ms, realizing seamless bus switching without data loss.
  • Number of Connected Modules: Up to 32 I/O modules per bus, supporting system expansion.
  • Isolation Voltage: 500V AC between buses, preventing mutual interference.
  • Operating Temperature: -10℃ to 55℃, storage temperature: -20℃ to 60℃.
  • Power Consumption: 2W (24V DC), low energy consumption.
  • Dimensions: 100×160×220mm, fitting standard control cabinets.

Yokogawa SB301 Power Supply Backup Module

Technical Specifications:

  • Output Voltage: 24V DC, output stability ±1%, ensuring stable power supply.
  • Output Current: 5A continuous, 10A peak, meeting module power demands.
  • Backup Time: 30 minutes at full load (5A), extendable with external batteries.
  • Charging Current: 1A, automatically charging the internal battery when the main power is on.
  • Input Voltage: 24V DC (from main power supply), voltage tolerance ±10%.
  • Operating Temperature: 0℃ to 40℃, storage temperature: -20℃ to 60℃.
  • Protection Functions: Overcurrent, overvoltage, and short-circuit protection.
  • Battery Type: Sealed lead-acid battery, maintenance-free.

Yokogawa VF311 Compact Variable Frequency Drive

Technical Specifications:

  • Rated Power: 1.5kW, matching small and medium-sized motors.
  • Input Voltage: Three-phase AC 200-240V, 50/60Hz, voltage tolerance ±10%.
  • Output Voltage: 0-230V AC, output frequency 0.1-400Hz, adjustable speed range.
  • Output Current: 7.5A (continuous), 15A (peak), meeting motor current demands.
  • Control Method: V/f control and vector control, switchable based on application.
  • Communication Interface: RS-485 (Modbus/RTU), enabling remote monitoring and control.
  • Protection Functions: Overcurrent, overvoltage, undervoltage, overheating, and short-circuit protection.
  • Operating Temperature: -10℃ to 40℃, storage temperature: -20℃ to 60℃.

Yokogawa F3CU04-0N High-Speed Counter Module for PLC Systems

Technical Specifications:

  • Number of Counter Channels: 4 independent channels, capable of simultaneous counting.
  • Counting Frequency: Up to 500kHz per channel, handling high-speed pulse signals.
  • Counting Modes: Up-counting, down-counting, and up/down counting, configurable per channel.
  • Count Range: 32-bit (0 to 4,294,967,295), meeting large-count requirements.
  • Input Signal: 24V DC, NPN/PNP selectable, compatible with various sensors.
  • Response Time: ≤1μs, ensuring rapid pulse detection.
  • Isolation Voltage: 500V AC between channels and backplane.
  • Operating Temperature: 0℃ to 40℃, storage temperature: -20℃ to 60℃.

Yokogawa DX2020-1-4-3 Advanced Data Acquisition and Recording Station

Technical Specifications:

  • Number of Input Channels: 16 universal channels, supporting thermocouple, RTD, voltage, and current signals.
  • Input Signal Range: Thermocouple (K/J/T/E/R/S/B), RTD (Pt100/JPt100), 0-10V DC, 4-20mA DC.
  • Measurement Accuracy: ±0.01% of full scale, ensuring precise data collection.
  • Sampling Rate: 10ms per channel, enabling rapid data acquisition.
  • Data Storage: 32GB internal memory, expandable via SD card up to 128GB.
  • Display: 7-inch color touchscreen with a resolution of 800×480, showing multiple parameters and trends.
