Moog D634Z510 Direct-Drive Servo Valve
Technical Specifications:
- Nominal Flow Rate: 15 to 120 L/min (4 to 32 GPM)
- Operating Pressure: Up to 350 bar (5,000 PSI)
- Input Signal: ±10 VDC or 4 to 20 mA
- Digital Communication: EtherCAT, PROFIBUS-DP, CANopen
Shop
You are here:
Moog G761-3515A High-Pressure Electro-Hydraulic Servo Valve
Technical Specifications:
- Nominal Flow Rate: 6 to 90 L/min (1.6 to 24 GPM)
- Operating Pressure: Up to 420 bar (6,000 PSI)
- Input Signal: 8 to 200 mA
- Mounting Standard: ISO 10372-06-05-0-92
Moog D681Z4195 Direct-Drive Servo Valve
Technical Specifications:
- Nominal Flow Rate: 10 to 50 L/min (2.6 to 13.2 GPM)
- Operating Pressure: Up to 350 bar (5,000 PSI)
- Input Signal: ±10 VDC or 4 to 20 mA
- Digital Communication: EtherCAT, PROFIBUS-DP, CANopen
Moog G631-3703B Electro-Hydraulic Servo Valve
Technical Specifications:
- Nominal Flow Rate: 4 to 63 L/min (1 to 17 GPM)
- Operating Pressure: Up to 315 bar (4,500 PSI)
- Input Signal: 8 to 200 mA
- Mounting Standard: ISO 4401-04-04-0-92
Moog G405-001 Proportional Control Valve
Technical Specifications:
- Nominal Flow Rate: 5 to 30 L/min (1.3 to 8 GPM)
- Operating Pressure: Up to 250 bar (3,625 PSI)
- Input Signal: 0 to ±10 VDC or 4 to 20 mA
- Hysteresis: ≤5%
Moog D661-450D-4 High-Flow Electro-Hydraulic Servo Valve
Technical Specifications:
- Nominal Flow Rate: 75 to 150 L/min (20 to 40 GPM)
- Operating Pressure: Up to 210 bar (3,000 PSI)
- Input Signal: 8 to 200 mA
- Mounting Standard: Moog-specific high-flow design
Moog G631-3003B Electro-Hydraulic Servo Valve
Technical Specifications:
- Nominal Flow Rate: 6 to 90 L/min (1.6 to 24 GPM)
- Operating Pressure: Up to 420 bar (6,000 PSI)
- Input Signal: 8 to 200 mA
- Mounting Standard: ISO 10372-06-05-0-92
Moog D661-4096 Electro-Hydraulic Servo Valve
Technical Specifications:
- Nominal Flow Rate: 20 to 200 L/min (5.3 to 53 GPM)
- Operating Pressure: Up to 350 bar (5,000 PSI)
- Input Signal: ±10 VDC, ±10 mA, or 4-20 mA
- Mounting Standard: ISO 4401-05-05-0-94
Moog D661-4465E High-Response Electro-Hydraulic Servo Valve
- Technical Specifications:
- Nominal Flow Rate: 30 to 250 L/min (8 to 66 GPM)
- Operating Pressure: Up to 350 bar (5,000 PSI)
- Input Signal: ±10 VDC or 4 to 20 mA
- Frequency Response: Up to 150 Hz
Moog D062-9125 Miniature Electro-Hydraulic Servo Valve
- Technical Specifications:
- Nominal Flow Rate: 0.2 to 2 L/min (0.05 to 0.5 GPM)
- Operating Pressure: Up to 210 bar (3,000 PSI)
- Input Signal: 8 to 200 mA
- Weight: 0.3 kg (0.66 lbs)
Moog D635 606A Direct-Drive Proportional Valve
- Technical Specifications:
- Nominal Flow Rate: 8 to 40 L/min (2.1 to 10.6 GPM)
- Operating Pressure: Up to 210 bar (3,000 PSI)
- Input Signal: 0 to ±10 VDC or 4 to 20 mA
- Linearity: ±2%
Moog G761-3051B High-Pressure Electro-Hydraulic Servo Valve
- Technical Specifications:
- Nominal Flow Rate: 6 to 90 L/min (1.6 to 24 GPM)
- Operating Pressure: Up to 420 bar (6,000 PSI)
- Input Signal: 8 to 200 mA
- Mounting Standard: ISO 10372-06-05-0-92
