ABB PM511V16 Processor Module

1. Technical Specifications • Processor: Motorola MC68040 running at 25 MHz • Memory: – Version PM511V08: 8 MB dynamic RAM with ECC – Version PM511V16: 16 MB dynamic RAM with ECC (upgrade kit available) • Storage: system program held on PCMCIA flash card (program card) • Power supply: 24 VDC ±20 %, consumed via backplane • Mechanical: single-slot 6U VME board, 160 mm × 160 mm × 120 mm, 0.8 kg • Operating temperature: 0 °C to +70 °C • Indicators: front-panel LEDs and four-position rotary switch for start / mode selection plus restart push-button

Woodward 5501-470 Digital Servo Controller

1. Technical Specifications • Input Voltage: 24 VDC (18–36 V range tolerated) • Operating Temperature: −20 °C to +70 °C • Control Output Types: PID, motion, speed and position loops • Digital Outputs: relay or open-collector, rated 0.5 A at 24 V • Analog I/O: 4–20 mA current loop, 0–10 V or ±10 V, 12-bit resolution • Communication Ports: RS-232/RS-485, Modbus RTU, optional Ethernet or CANopen • Processor: 32-bit ARM-based core, cycle time < 1 ms • Memory: 470 kB non-volatile for program and data logging • Dimensions: 125 mm × 120 mm × 90 mm; DIN-rail or panel mount • Enclosure: IP20 front, IP54 rear with cover kit; vibration-resistant to 5 g

GE IS215UCVEM08 Mark VI Controller Processor Module

Technical Specifications • Microprocessor: Intel Celeron 300 MHz • Memory: 32 MB DRAM • Storage: QNX real-time operating system pre-loaded • Ethernet: 10BaseT / 100BaseTX RJ-45 port on front panel • Serial Ports: COM1 and COM2 RS-232C • Auxiliary Interfaces: SVGA monitoring port (GE service use), PS/2 keyboard/mouse connector

GE VMIVME-2540 Intelligent Counter/Controller

1. Technical Specifications • Processor: on-board 15 MHz 68HC000 CPU • Counting depth: up to 4 billion events per channel • Frequency range: 1.16 × 10⁻³ Hz to 2.5 MHz • Period / pulse-width window: 400 ns to 8.5899 × 10⁶ s (32-bit floating-point) or 858 s (unsigned integer) • Channels: 4, 8, 16 or 24 software-selectable configurations • Output drive: 24 discrete outputs, ±10 V at 10 mA per channel, 12-bit resolution • Step rate for quadrature position control: up to 1.25 MHz with ¼-wave resolution • VMEbus interface: A32/A24/D32/D16/D8 slave, 64 kbyte memory window, ANSI/IEEE 1014-1987

GE 369-HI-R-M-0-0-0-E Motor Management Relay

echnical Specifications • Control power: HI range 50–300 VDC or 60–265 VAC 50/60 Hz, 20 VA nominal • Motor protection functions: overload, short-circuit, locked-rotor, phase-loss, phase-reversal, ground-fault, under- and over-voltage, under- and over-frequency, power factor, thermal modeling • Current inputs: 1 A or 5 A secondary, true RMS 1.04 ms/sample, burden < 0.5 VA • RTD inputs: 12 channels, isolated 36 Vpk, supports 100 Ω Pt, Ni, Cu elements • Metering package: real-time current, voltage, power, energy, frequency, power factor accuracy ±0.5 % • Digital inputs: 6 opto-isolated, 24–250 VDC/AC • Output contacts: 4 Form-C relay outputs, 8 A make, 5 A carry • Analog outputs: 4 optional 0–1 mA / 0–20 mA / 4–20 mA, 0.5 % accuracy • Communication: front RS-232, rear RS-485 (3 ports), Modbus RTU; optional Modbus TCP/IP, Profibus-DP/DPV1, DeviceNet

ABB DSDP170 57160001-ADF High-Performance Pulse Counting & Positioning Module

1. Technical Specifications • Product type: high-speed pulse counting board for the ABB S100 I/O system • Max. pulse frequency: 2.5 MHz • Positioning accuracy: ±0.05 % of measured value • Speed measuring range: 0 – 5 000 RPM • Counting resolution: software-selectable 1×, 2×, 4×, 8× • Input voltage range: 5 – 24 VDC, universal for most encoders and sensors • Output frequency: 30 kHz • Dimensions: 328.5 mm × 18 mm × 238.5 mm • Weight: 0.38 kg • Protection: IP20 module housing, designed for 19-inch rack / DIN-rail sub-rack mounting • Environmental rating: −20 °C to +60 °C operating, 95 % RH non-condensing • Certifications: CE, UL, RoHS compliant

ABB LM80.A — Laser Level Transmitter

he LM80.A is a non-contact, time-of-flight laser level transmitter engineered for continuous level, distance or positioning measurement of solids, opaque liquids and slurries. The instrument emits a narrow-beam laser pulse, measures the reflection time and calculates the exact distance to the material surface without physical contact .

ABB PPC907BE101 3BHE024577R0101 High-Performance Industrial Control Module

PPC907BE101 3BHE024577R0101 is a core control board within ABB’s AMC34 series, engineered for demanding medium- and high-voltage drive applications. It is factory-installed in ACS2000, ACS5000 and ACS6000 drive families and serves as the central application and motor-control computer for these systems.
Technical Specifications • Processor: dual-core ARM Cortex-A9, 800 MHz or dual-core 1.2 GHz (depending on revision) • Memory: 256 MB DDR3 RAM, 512 MB Flash (minimum); 2 GB DDR3 + 8 GB Flash variants exist • I/O handling: > 5 000 transactions per second, 8 analog inputs, 8 analog outputs, 32 digital I/O

ABB KSD211B 3BHE022455R1101 — High-Integrity Servo Drive Module

1. Technical Specifications • Supply voltage: three-phase 380–480 V AC ±10 % • Continuous output current: 16 A • Peak current (3 s): 48 A • Control method: field-oriented vector control (FOC) with auto-tuning PID • Positioning accuracy: ±0.02 mm (with 17-bit absolute encoder) • Loop update rate: 1 kHz (current), 4 kHz (speed), 1 kHz (position) • Feedback: absolute encoder, resolver, or incremental encoder • Communication: CANopen, RS-485, ABB Robot Network, EtherNet/IP via expansion • Safety: STO (Safe Torque Off) and SS1 (Safe Stop 1) certified to SIL 2 / ISO 13849-1 Cat. 3 • Response time to safety command: ≤ 50 ms • Regenerative braking: built-in, returns up to 25 % of braking energy to DC bus • Operating temperature: 5 °C to 45 °C (derating above 40 °C) • Protection class: IP20 (cabinet-mounted) with conformal coating • Dimensions: 200 mm W × 300 mm H × 150 mm D • Weight: 2.8 kg

ABB AO2000 LS25 Laser Gas Analyzer – Comprehensive Technical Profile

1. Core Technology & Performance • Measurement principle: Tunable Diode Laser Absorption Spectroscopy (TDLAS) • Target gases: O₂, CO, CO₂, NOₓ, NH₃, HCl and other IR-active species—range selectable by configuration • Accuracy: ±2 ppm or ±2 % of reading, whichever is greater • Response time (T₉₀): ≤1 second • Sensitivity: sub-ppm level dependent on gas and path length • Drift: < 1 % per month with automatic baseline correction

GE IS210BPPCH1AD – Complete Technical Dossier

1. Identification & Overview IS210BPPCH1AD is a simplex analog input / output terminal board engineered by General Electric for the Mark VI Speedtronic turbine-control family. It mounts on DIN rail, uses surface-mount technology, and communicates with the VAIC processor via a single high-density cable.

GE PMC-0247RC-282000 350-93750247-282000F Compact Intelligent PLC & I/O Module for GE PACSystems RX3i

1. Technical Specifications • Input power: 24 VDC nominal (18–30 VDC range) • Output type: relay, 10 A maximum per channel • Communication: Ethernet/IP, Modbus TCP, serial RS-232/RS-485 • Processor: high-performance 32-bit CPU • Memory: large-capacity RAM and user Flash for program and data storage • Programming: IEC 61131-3 languages (LD, ST, FBD, SFC, IL) • Isolation: 2.5 kV channel-to-bus, 3 kV channel-to-channel • Dimensions: compact single-slot RX3i form factor, DIN-rail or rack mount • Operating temperature: –20 °C to +60 °C • Humidity: 5 %–95 % RH non-condensing • Protection: IP20 enclosure, vibration 2 g, shock 15 g
