AEG AS-9715-001 Analog Input Module

  • Product Introduction: This is an 8 - channel analog input module belonging to the AEG AS series. It is dedicated to converting analog signals (like temperature, pressure, flow, etc.) from field sensors into digital signals that can be processed by the controller, acting as a crucial interface for data acquisition in industrial control systems.
  • Technical Specifications:
    • Input Channels: 8 single - ended or 4 differential analog input channels.
    • Input Signal Ranges: ±10 VDC, 0-10 VDC, 4-20 mA, 0-20 mA (configurable per channel).
    • Resolution: 16 - bit, with an accuracy of ±0.1% of the full scale.
    • Sampling Rate: 100 samples per second per channel, with simultaneous sampling capability.
    • Power Supply: 24 VDC, and power consumption is 3 W.
    • Isolation: 2500 VAC channel - to - channel and channel - to - ground isolation.
    • Operating Temperature: -20°C to +60°C.

AEG MM-FMC3-010 Modular Fieldbus Communication Module

  • Product Introduction: It is a modular fieldbus communication module under the AEG MM series, designed to serve as a communication interface between field devices and upper - level control systems in industrial automation setups. It enables seamless data exchange between diverse field devices and controllers, which is essential for the operation of distributed control systems.
  • Technical Specifications:
    • Power Supply: 24 VDC, with a voltage tolerance of ±10%, and power consumption not exceeding 5 W.
    • Communication Protocols: Profibus - DP, Modbus RTU/TCP, Ethernet/IP, CANopen.
    • Number of Communication Ports: 2 independent fieldbus ports, supporting daisy - chain connection.
    • Operating Temperature: -25°C to +70°C, Storage Temperature: -40°C to +85°C.
    • Protection Rating: IP20, suitable for cabinet - mounted installation.
    • Dimensions: 100mm × 160mm × 60mm (W×H×D).

Bently TSXDMZ28DR

Product Name: TSXDMZ28DR Schneider Discrete I/O Module – 28-point, relay output, spare part
Product Introduction: 28-point relay output module used in conjunction with TSX3722001 PLC for alarm annunciation in legacy Bently systems.
Technical Specifications:
  • Points: 16 DI, 12 DO relay
  • Voltage: 24 VDC
  • Contact Rating: 2 A
  • Isolation: 1,500 V

Bently TSX3722001

Product Name: TSX3722001 Schneider PLC CPU – spare part for legacy Bently interface
Product Introduction: Original Schneider Electric TSX 37-22 PLC CPU used in early Bently Nevada interface racks for data concentration. It is no longer manufactured but available as refurbished spare.
Technical Specifications:
  • CPU: TSX 37-22
  • Memory: 32 KB
  • I/O: 256 points
  • Power: 24 VDC
  • Communication: RS-485, Modbus

Bently TSP090-124EX

Technical Specifications:
  • Element: Pt100, Class A
  • Range: –50 °C to +250 °C
  • Accuracy: ±0.15 °C
  • Output: 4-20 mA, 2-wire
  • Power: 12 – 30 VDC
  • Protection: IP66, Ex d IIC T6
  • Approvals: ATEX, IECEx, CSA

Bently PWB78434-01

Product Name: PWB78434-01 Printed Wiring Board – spare part for 3500 power supply
Product Introduction: Factory spare circuit board for 3500/15 power supply modules. It is conformal-coated and tested to original specifications.
Technical Specifications:
  • Function: Power-supply control & regulation PCB
  • Coating: Acrylic conformal
  • Temperature: –55 °C to +125 °C
  • Approvals: UL recognized

Bently 3500/94M 184826-01

Product Name: 3500/94M Enhanced Display – 184826-01 I/O module, Gigabit Ethernet, ATEX approved
Product Introduction: Factory-configured 3500/94M with 184826-01 I/O board that provides Gigabit Ethernet and worldwide Ex certification for hazardous areas.
Technical Specifications:
  • Part Number: 184826-01
  • Ethernet: Gigabit, redundant
  • Approvals: ATEX Ex ia IIC T4 Ga, IECEx, CSA

Bently 3500/94M Enhanced System Display

Technical Specifications:
  • Display: 15.6-inch TFT colour, 1280 × 800 pixels
  • Touch: Projected capacitive, multi-touch
  • Processor: 1.6 GHz quad-core ARM Cortex-A72
  • Memory: 4 GB RAM, 32 GB eMMC
  • Communication: Gigabit Ethernet, USB 3.0, RS-485
  • Protocols: Modbus TCP, OPC UA, HTTP REST, VNC server
  • Power: 24 VDC, 25 W max
  • Operating Temperature: –20 °C to +60 °C
  • Approvals: CE, UL, ATEX Zone 2, SIL 2 capable

Bently 3500/93-01-00-00

Technical Specifications:
  • Mounting: Face-mount (display hinges on rack front)
  • Approvals: 00 (none)
  • Backlight: Determined by display part number (135785-01 or -02)
  • Communication: RS-422 to DIM
  • Power: 15.5 W max

Bently 3500/93 135785-02

Technical Specifications:
  • Display Type: Transflective FSTN LCD, 640 × 200 dots
  • Backlight: White electroluminescent, life >20,000 h
  • Brightness: 120 cd/m²
  • Power Consumption: 16 W max (backlight on)
  • Supply Voltage: 18 – 36 VDC
  • Operating Temperature: –20 °C to +60 °C
  • Approvals: ATEX Ex ia IIC T4 Ga, IECEx, CSA Class I Div 2
  • Communication: RS-422, USB device port on front for local laptop connection
  • Additional Ports: Front USB-B for local configuration laptop
  • Weight: 2.15 kg (display unit)

Bently 3500/93 135785-01 System Display Module

Technical Specifications:
  • Display Type: Reflective FSTN LCD, 640 × 200 dots
  • Screen Size: 8.0 in diagonal
  • Viewing Area: 154 × 48 mm
  • Backlight: None (requires ambient light)
  • Display Unit Dimensions: 203 × 413 × 31 mm
  • Display Unit Weight: 2.1 kg
  • Display Interface Module (DIM) Dimensions: 241 × 24 × 242 mm
  • DIM Weight: 0.82 kg
  • Power Consumption: 15.5 W max (unit + DIM)
  • Supply Voltage: 18 – 36 VDC (from rack or external supply)
