AEG AS-B809-016 16‑Channel 230 VAC Digital Input Module

  • Product Introduction: It is a 16‑channel digital input module belonging to the AEG Modicon 800 series, designed to collect 230 VAC switching signals from industrial field devices like limit switches, pushbuttons, and circuit breakers, and convert them into logic signals that can be identified by the PLC CPU for subsequent control logic operation.
  • Technical Specifications:
    • Input Channels: 16 independent digital input channels, divided into two common groups of 8 channels each.
    • Input Voltage: 160‑260 VAC, 47‑63 Hz; surge voltage: 400 VAC for 1 cycle, 300 VAC for 10 seconds.
    • Turn‑on Threshold: 112‑148 VAC; Turn‑off Threshold: 0‑90 VAC.
    • Typical Wetting Current: 8.5 mA at 230 VAC.
    • Response Time: ≤20 ms (on and off).

AEG AS-B805-016 Digital Input Module

  • Product Introduction: This is an 8 - channel digital input module of the AEG AS series. It is used to collect digital signals from external devices such as limit switches, proximity switches, and push - buttons, and transmit them to the CPU module for processing.
  • Technical Specifications:
    • Input Channels: 8 independent digital input channels.
    • Input Type: Dry contact input, supporting both normally open and normally closed contacts.
    • Input Voltage: 24 VDC, with a voltage tolerance of 15-30 VDC.
    • Input Current: 5 mA per channel when on.
    • Response Time: ≤2 ms.

AEG D984-385 984 385D Digital Output Module

  • Product Introduction: This is a 16 - channel digital output module of the AEG 984 series PLC. It converts the digital signals output by the CPU module into switching signals to drive external devices such as contactors, relays, and solenoid valves.
  • Technical Specifications:
    • Output Channels: 16 independent digital output channels.
    • Output Type: Relay output, rated switching voltage: 250 VAC/30 VDC.
    • Rated Switching Current: 5 A per channel, 10 A per common terminal.
    • Response Time: ≤10 ms (on and off).
    • Isolation: 2500 VAC between channels and between channels and the power supply.
    • Power Supply: 24 VDC, power consumption of 4 W.
    • Operating Temperature: -20°C to +60°C, Protection Rating: IP20.
    • Dimensions: 120mm × 160mm × 50mm (W×H×D).

AEG MM-PMC2-400 Advanced Operator Interface Panel

  • Product Introduction: This is an upgraded version of the AEG MM - PMC2 series operator interface panel, with a larger display screen and more powerful functions. It is used for complex human - machine interaction tasks in industrial control systems, providing a more intuitive and convenient operation experience.
  • Technical Specifications:
    • Display: 10.4 - inch color TFT LCD screen with a resolution of 800×600 pixels and a backlight life of over 50,000 hours.
    • Input Methods: Touchscreen (resistive) and membrane keypad with 30 function keys.
    • Communication Interfaces: RS - 232, RS - 485, Ethernet, Profibus - DP, Modbus TCP/IP.
    • Power Supply: 24 VDC (10-30 VDC), power consumption of 25 W.
    • Operating Temperature: -25°C to +70°C, Protection Rating: IP65 (front panel), IP20 (rear).
    • Dimensions: 400mm × 300mm × 100mm (W×H×D), Weight: 3.5 kg.

AEG ASP890300 Remote I/O Processor Module

  • Product Introduction: This is a remote I/O processor module of the AEG 800 series. It is used to manage the communication between the main controller and the remote I/O rack, enabling the controller to access and control the I/O modules in the remote rack, which is suitable for distributed control systems.
  • Technical Specifications:
    • Power Supply: Selectable 115/230 VAC or 24 VDC, power consumption of 10 W.
    • Communication Medium: Coaxial cable (75 ohms), Communication Rate: 1.544 MHz.
    • I/O Scanning Speed: Less than 5 ms for 256 I/O points.
    • Number of Remote I/O Racks: Up to 32 racks can be connected.
    • Power Output: +5.0 VDC (10 A), +4.3 VDC (5 A), -5.0 VDC (2 A), for powering remote I/O modules.
    • Operating Temperature: 0°C to +60°C, Protection Rating: IP20.

AEG AM-C986-004 Integrated Control Processor Module

  • Product Introduction: This is an integrated control processor module of the AEG 984B series PLC. It integrates a high - performance processor and a large - capacity memory, and is designed for complex industrial control applications requiring high computing power and large - scale program storage.
  • Technical Specifications:
    • Processor: 10 MHz Intel processor, supporting 32 - bit data processing.
    • Memory: 256 KB SRAM (expandable up to 128 KB extended data memory), 1 MB EPROM for program storage.
    • I/O Interface: Supports up to 2048 digital I/O points and 256 analog I/O points (via expansion racks).
    • Communication Ports: 2 RS - 232 ports, 1 Profibus - DP port.
    • Power Supply: 24 VDC, power consumption of 12 W.
    • Operating Temperature: 0°C to +55°C, Protection Rating: IP20.
    • Instruction Execution Speed: 1 ms per 1000 basic instructions.

AEG 41102/110CPU41102 Modicon 411 Series CPU Control Unit

  • Product Introduction: This is the core CPU control unit of the AEG Modicon 411 series PLC. It is responsible for executing control programs, processing input/output signals, and managing communication, serving as the brain of medium - sized industrial control systems.
  • Technical Specifications:
    • Processor: 32 - bit RISC processor with an operating frequency of 100 MHz.
    • Memory: 512 KB RAM (with battery backup), 1 MB Flash memory for program storage.
    • I/O Capacity: 24 digital inputs + 16 digital outputs (expandable up to 512 points via extension modules).
    • Communication Interfaces: RS - 485, Ethernet, CAN - open, Profibus - DP.
    • Power Supply: 110 VAC, power consumption of 25 W.
    • Operating Temperature: 0°C to +60°C, Protection Rating: IP20.
    • Instruction Execution Speed: Basic instructions take 0.1 μs per instruction, and complex instructions take 1 μs per instruction.

AEG AS-9715-001 Analog Input Module

  • Product Introduction: This is an 8 - channel analog input module belonging to the AEG AS series. It is dedicated to converting analog signals (like temperature, pressure, flow, etc.) from field sensors into digital signals that can be processed by the controller, acting as a crucial interface for data acquisition in industrial control systems.
  • Technical Specifications:
    • Input Channels: 8 single - ended or 4 differential analog input channels.
    • Input Signal Ranges: ±10 VDC, 0-10 VDC, 4-20 mA, 0-20 mA (configurable per channel).
    • Resolution: 16 - bit, with an accuracy of ±0.1% of the full scale.
    • Sampling Rate: 100 samples per second per channel, with simultaneous sampling capability.
    • Power Supply: 24 VDC, and power consumption is 3 W.
    • Isolation: 2500 VAC channel - to - channel and channel - to - ground isolation.
    • Operating Temperature: -20°C to +60°C.

AEG MM-FMC3-010 Modular Fieldbus Communication Module

  • Product Introduction: It is a modular fieldbus communication module under the AEG MM series, designed to serve as a communication interface between field devices and upper - level control systems in industrial automation setups. It enables seamless data exchange between diverse field devices and controllers, which is essential for the operation of distributed control systems.
  • Technical Specifications:
    • Power Supply: 24 VDC, with a voltage tolerance of ±10%, and power consumption not exceeding 5 W.
    • Communication Protocols: Profibus - DP, Modbus RTU/TCP, Ethernet/IP, CANopen.
    • Number of Communication Ports: 2 independent fieldbus ports, supporting daisy - chain connection.
    • Operating Temperature: -25°C to +70°C, Storage Temperature: -40°C to +85°C.
    • Protection Rating: IP20, suitable for cabinet - mounted installation.
    • Dimensions: 100mm × 160mm × 60mm (W×H×D).

Bently TSXDMZ28DR

Product Name: TSXDMZ28DR Schneider Discrete I/O Module – 28-point, relay output, spare part
Product Introduction: 28-point relay output module used in conjunction with TSX3722001 PLC for alarm annunciation in legacy Bently systems.
Technical Specifications:
  • Points: 16 DI, 12 DO relay
  • Voltage: 24 VDC
  • Contact Rating: 2 A
  • Isolation: 1,500 V

Bently TSX3722001

Product Name: TSX3722001 Schneider PLC CPU – spare part for legacy Bently interface
Product Introduction: Original Schneider Electric TSX 37-22 PLC CPU used in early Bently Nevada interface racks for data concentration. It is no longer manufactured but available as refurbished spare.
Technical Specifications:
  • CPU: TSX 37-22
  • Memory: 32 KB
  • I/O: 256 points
  • Power: 24 VDC
  • Communication: RS-485, Modbus

Bently TSP090-124EX

Technical Specifications:
  • Element: Pt100, Class A
  • Range: –50 °C to +250 °C
  • Accuracy: ±0.15 °C
  • Output: 4-20 mA, 2-wire
  • Power: 12 – 30 VDC
  • Protection: IP66, Ex d IIC T6
  • Approvals: ATEX, IECEx, CSA
