ABB PM865K01 3BSE031151R1 High-Integrity Safety CPU

Technical Specifications:

  • Processor: Equipped with a high-performance processor capable of fast execution of control algorithms.
  • Memory: Features substantial onboard memory to store program code, real-time data, and historical information.
  • Communication Interfaces: Supports multiple industrial communication protocols such as Modbus, TCP/IP, enabling efficient data exchange with HMIs, SCADA systems, and other controllers.
  • Redundancy Support: Offers redundancy options including power supply and controller redundancy to ensure high system availability in critical applications.
  • Real-Time Clock: Built-in real-time clock ensures accurate time stamping for event logging and fault diagnosis.
  • Operating Environment: Designed for industrial environments, capable of stable operation under wide temperature ranges, high humidity, and vibration conditions.

KONGSBERG DPS112 差分全球导航卫星系统（DGNSS）传感器

Technical Specifications:

  • Supports multiple sensor inputs including GPS, gyrocompass, wind sensors, and sonar to achieve precise position and orientation control.
  • Features redundancy in design to ensure continuous operation even if a single component fails.
  • Offers various levels of operational modes ranging from basic position holding to complex trajectory tracking capabilities.
  • Meets International Maritime Organization (IMO) standards for dynamic positioning systems, suitable for use under diverse environmental conditions.

XYCOM XVME-653–Detailed Technical Summary

  • Technical Specifications
    • Processor: Intel 233 MHz MMX Pentium CPU.
    • Cache: 512K of synchronous level 2 pipeline cache.
    • Memory: Supports up to 256 MB of fast - page or EDO DRAM, with ECC or parity, and is installed in 72 - pin SIMM sites.
    • Graphics: High - performance PCI local bus SVGA controller with 2 MB of VRAM.
    • Ethernet: 10/100 Mbit PCI Ethernet controller, with front - end RJ - 45 connector, and the Ethernet controller is Intel 82558.
    • Storage: Up to 72 MB of optional flash disk storage.
    • Serial Port: Two high - speed serial ports, compatible with 16550.
    • Parallel Port: One EPP/ECP parallel port.
    • Other Ports: One universal serial bus (USB) port, and PS/2 style keyboard and mouse ports.
    • Bus Interface: VMEbus.
    • Board Size: 6U 8HP (about 233 x 160 mm).
    • Operating Temperature Range: -40°C to +85°C.

NI PXIe-5105

  • Technical Specifications
    • Voltage Input Channels: 8.
    • Analog Input Resolution: 12 bits.
    • Analog Input Voltage Range: -15 V to 15 V.
    • Maximum Sampling Rate: 60 MS/s.
    • Oscilloscope Maximum Bandwidth: 60 MHz.
    • Analog Input Impedance: 1 MΩ or 50 ohms.
    • Bus Connector: PXI Express.
    • Memory: It can be configured with 16 MB, 128 MB, or 512 MB of memory.
    • Power Consumption: Approximately 23 W.
    • Operating Temperature Range: 0°C - 55°C.
    • Storage Temperature Range: -40°C - 71°C.

ABB PM902F 3BDH001000R0005

  • Technical Specifications
    • Power Supply Voltage: 24V DC, with an allowable range of 18 - 30V DC.
    • Environmental Temperature: 0 - 60°C.
    • Humidity: 5 - 95%, non - condensing.
    • Communication Interface: RS - 485, supporting Modbus RTU protocol.
    • Digital Inputs: 16, compatible with NAMUR sensors and PNP/NPN sensors.
    • Digital Outputs: 8, can be configured as PNP or NPN outputs, with a maximum load of 0.5A per output.
    • Frequency Range: Up to 50kHz.
    • Protection Rating: IP65.
    • Size: The net depth/length is 95 mm, the net height is 152 mm, and the net width is 227 mm.
    • Weight: 1.1 kg.

ABB PM511V16 3BSE011181R1 – Processor Module

  • Technical Specifications
    • Processor Type: PowerPC 603e or PowerPC 750, with a main - frequency of up to 800 MHz.
    • Operating Voltage: 24V DC.
    • Output Power: The maximum output power is 16W.
    • Working Temperature Range: -20°C to +60°C.
    • Storage Capacity: 2MB flash memory and 256MB SDRAM.
    • Communication Interface: Support Ethernet, serial port (RS - 232/RS - 485), Profibus DP, CANopen, EtherCAT, etc.
    • I/O Points: 16 digital inputs and 16 digital outputs, 4 analog inputs and 4 analog outputs.
    • Size: 230mm x 170mm x 65mm.
    • Protection Level: IP65.
    • Installation Method: DIN - rail installation.
    • Weight: About 1.5 kg.

MOOG D136-001-007–MSC I Motion Controller

Technical Specifications

  • Power Supply: Supports 24 VDC power supply, with a current of 10 A. Some models can also use 48 VDC input, and the output voltage is 0 - 10V DC.
  • Processor and Memory: Equipped with a 40 MHz CPU, 4 MB flash EEPROM, and 2 MB RAM.
  • Task Cycle Time: The minimum task cycle time is 400 microseconds.
  • Input/Output Channels: It has 16 voltage or current inputs, with a measurement range of ±10 V or ±20 mA; 4 voltage outputs, with an output range of ±10 V and a maximum output current of 5 mA; and 1 reference voltage output of +10 V. Besides, there are 8 analog inputs, 2 analog outputs, all with configurable range and 16 - bit resolution, and 8 digital I/O.
  • Communication Interface: It supports CANopen, EtherCAT, Profibus DP V1 (optional), and also has RS485 interface, 2 x TIA/EIA 232, and Ethernet interface.

GE V7768-312000

Technical Specifications

  • Processor: It may be equipped with an Intel Core 2 Duo processor up to 2.16 GHz or an Intel Celeron M processor up to 1.07 GHz. The L2 cache is 4 Mbyte for Core 2 Duo and 1 Mbyte for Celeron M.
  • Memory: It can support up to 2 Gbyte DDR2 SDRAM through a single SODIMM.
  • Storage: It can support up to 8 Gbyte bootable compact flash, accessible via the secondary IDE port and can be configured as a boot device through BIOS.
  • Interface: It has 2 serial ports, 4 USB 2.0 ports (2 in the front and 2 in the rear), 2 SATA ports, and a PS/2 keyboard/mouse interface on the front panel. There are also 2 gigabit Ethernet ports on the front panel, using Intel 82571, supporting network boot via PXE. In addition, it has a PCI - X PMC expansion site and a board - to - board connection for the PMC 237 CM1/V PMC expansion board. Some versions have a PCI Express 3.0 x16 interface, 8GB GDDR6 memory, a core clock of 1605 MHz, and a boost clock of 1905 MHz.

Woodward 8200-1312 Electro-Hydraulic Converter

  • Technical Specifications
    • Rated Voltage: 18 - 36V DC.
    • Power Consumption: 25W.
    • Input Signal: 0 - 10V DC, 4 - 20mA.
    • Output Signal: ±5A.
    • Response Time: Less than 10ms.
    • Accuracy: ±0.5%.
    • Protection Level: IP65.
    • Operating Temperature: - 40°C to 85°C.
    • Size: 150mm x 100mm x 60mm.
    • Weight: 1.5kg.
    • Shell Material: Aluminum alloy.
    • Connection Method: Cable connection.

ABB PM891K01 3BSE053241R1–Central Processing Unit for System 800xA

  • Technical Specifications
    • Processor Architecture: It adopts PowerPC 604e architecture, and some models are equipped with a 450 MHz MPC8270 processor. There are also versions with ARM Cortex - A53 quad - core 1.9 GHz processors.
    • Memory: It usually has 128 MB RAM and 4 MB flash memory, and some high - end models are equipped with 2 GB DDR4 RAM and 4 GB eMMC Flash (3.2 GB available to users).
    • Communication Interface: It supports RS - 232, RS - 485, and Ethernet interfaces. There are 2 Ethernet ports (10/100 Mbit/s or Gigabit Ethernet), and some models are also equipped with 1 USB 3.0 port.
    • Backplane Bus: Some models support ABB AF600 backplane bus with a bandwidth of 600 Mbps, which is downward - compatible with AF400.
    • Power Supply: The power supply is 24 V DC, with a range of ±30%, and the typical power consumption is 7.5 W.
    • Operating Temperature: The operating temperature range is generally - 25°C to +60°C, and some models can reach - 25°C to +70°C.
    • Size and Weight: The size is about 102.5 mm×102.5 mm×32 mm, and the weight is about 2.1 kg.
    • I/O Points: It can support up to 64 I/O points.

ABB PFCL201C – Pressductor PillowBlock Load Cell

  • Technical Specifications
    • Measurement Range: Available in multiple ranges, such as 5kN, 10kN, 20kN, and 50kN. Taking the 20kN model as an example, its measurement range is 0 - 20kN (20,000N).
    • Accuracy: Generally, it can reach ±0.2%FSO, and some models can reach up to ±0.1%FSO.
    • Non - linearity: ±0.2%FSO or better, and some high - end models can reach ±0.05%FSO.
    • Output: Common outputs include 2mV/V, 4 - 20mA, 0 - 10V, or RS485.
    • Bridge Resistance: Usually 350Ω.
    • Power Supply: The input voltage range is 12 - 24V DC.
    • Operating Temperature: -20°C to +80°C or -40°C to +85°C for some models.
    • Humidity: 5% to 95% non - condensing.
    • Protection Level: IP67, which can work in harsh environments.
    • Size: Approximately 100mm×50mm×25mm.
    • Weight: About 0.8kg.
    • Overload Capacity: For example, the 50kN model has an overload capacity of 500kN.

IC698CRE040-HN-2

  • Technical Specifications
    • Processor: Equipped with a 1.8GHz Pentium - M microprocessor.
    • Memory: 64MB of battery - backed RAM for program storage, and 64MB of non - volatile user flash memory.
    • Scan Rate: The typical scan rate is 0.024 ms per 1000 boolean contacts/coils.
    • Communication Interfaces: Support RS - 232, RS - 485 serial ports and Ethernet interfaces. The Ethernet interface has a data rate of 10M or 100M, with a 10BaseT RJ45 physical interface, and can support up to 16 web server and FTP connections in total for web - based data monitoring.
    • Power Requirements: +5VDC at 6.8 amps nominal, +12VDC at 0.003 amps nominal, and -12VDC at 0.003 amps nominal.
    • Operating Temperature Range: 0°C to 60°C.
    • Programming Languages: Support programming languages such as ladder diagram, C, structured text, and function block diagram.
    • Standard Compliance: Comply with the VME64 standard (ANSI/VITA 1), which is convenient for communication with I/O modules.
