AEG ALU130236017

  • Product Introduction: AEG ALU130236017 is a legacy central processing unit module belonging to the Modicon ALU130 series, serving as the core processing unit for early Modicon automation systems. It is designed to execute control logic, process data, and coordinate system operations in industrial automation applications, particularly suited for retrofitting older production lines and maintaining legacy equipment. The CPU features a 16-bit processor, on-board memory, and support for Modbus communication, ensuring compatibility with legacy I/O modules and control systems, making it a reliable solution for extending the service life of existing automation infrastructure.
  • Technical Specifications:
    • Processor: 16-bit industrial microprocessor, 16 MHz clock speed
    • Program Memory: 128 KB EPROM (non-volatile)
    • Data Memory: 32 KB RAM (battery-backed)
    • I/O Capacity: Up to 1024 digital I/O points, 64 analog I/O points (via expansion modules)
    • Communication Interface: RS-485 (Modbus RTU), 9600 bps baud rate

AEG AS-E785-904 Industrial Ethernet Communication Module

  • Product Introduction: AEG AS-E785-904 is a high-speed industrial Ethernet communication module designed for the Modicon M340 series PLC systems, enabling seamless integration into Ethernet/IP and Modbus TCP networks. The module supports real-time data transfer, TCP/IP communication, and built-in security features, making it ideal for connecting Modicon M340 PLCs to SCADA systems, HMIs, and other industrial devices in factory automation and process control applications. It features a rugged design with wide temperature tolerance, ensuring reliable operation in harsh industrial environments where continuous network connectivity is essential.
  • Technical Specifications:
    • Communication Protocol: Ethernet/IP, Modbus TCP
    • Network Interface: 10/100 Mbps RJ45 port (auto-sensing)
    • Data Transfer Rate: 100 Mbps (full-duplex)
    • Communication Distance: 100 m (copper cable), extendable via switches
    • IP Address Configuration: Static IP, DHCP
    • Connection Capacity: Up to 64 simultaneous TCP/IP connections

AEG 92-00838-03 Industrial Signal Isolator/Converter Module

  • Product Introduction: AEG 92-00838-03 is a precision industrial signal isolator and converter module designed to transmit and convert analog signals (4–20 mA, 0–10 V) while providing electrical isolation between field devices and control systems. It eliminates ground loops and electrical interference, ensuring accurate signal transmission in high-noise industrial environments. The module features high conversion accuracy, wide input/output range, and a compact design, making it suitable for process monitoring and control applications in chemical processing, power generation, and manufacturing, where signal integrity is critical to operational efficiency and safety.
  • Technical Specifications:
    • Input Signal: 4–20 mA DC, 0–10 V DC (configurable)
    • Output Signal: 4–20 mA DC, 0–10 V DC (selectable, dual output option)
    • Conversion Accuracy: ±0.1% of full scale
    • Isolation Voltage: 3000 V AC (input-output, input-ground, output-ground)
    • Common Mode Rejection Ratio (CMRR): >120 dB (@50/60 Hz)
    • Power Supply: 24 V DC (18–30 V DC)
    • Power Consumption: <1.2 W

AEG 140DDO84300

  • Product Introduction: AEG 140 DDO84300 is a high-performance 16-channel DC output module designed for the Modicon Quantum series PLC systems, optimized for high-current industrial control applications requiring reliable switching of 10–60 V DC loads. The module is organized into two 8-channel groups, with fast switching response and robust protection against electrical transients, making it suitable for controlling DC motors, solenoid valves, and other high-power DC devices in demanding automation environments. It integrates seamlessly with Modicon Quantum chassis, with built-in diagnostics and LED status indicators, ensuring optimal performance and easy troubleshooting in factory automation, process control, and material handling applications.
  • Technical Specifications:
    • Number of Channels: 16 DC output channels, 2 groups of 8 channels each
    • Output Voltage Range: 10–60 V DC (10.2–72 V DC surge tolerance)
    • Current Capacity: 6 A per group, 12 A total (resistive load)
    • Switching Response Time: 1 ms (on/off)
    • Output Logic: Positive (source) logic
    • Isolation: 2500 V AC (channel group-to-backplane bus)

AEG 120-147-005 Industrial Power Distribution Terminal Block Module

  • Product Introduction: AEG 120-147-005 is a heavy-duty industrial power distribution terminal block module engineered for secure, high-current electrical connections in industrial automation, power distribution, and control panel applications. It is designed to terminate and distribute 24-600 V AC/DC power to multiple field devices, with a robust modular design that ensures stable power transmission and protection against electrical faults. The module features a high-current carrying capacity, corrosion-resistant terminals, and compliance with global industrial safety standards, making it ideal for high-power applications in manufacturing plants, power generation facilities, and heavy-duty industrial environments where reliable power distribution is critical to operational continuity.
  • Technical Specifications:
    • Voltage Rating: 600 V AC/DC (continuous operation)
    • Current Rating: 35 A per terminal, 70 A per module (max)
    • Terminal Type: Copper alloy, screw-clamp terminals with tin plating
    • Terminal Quantity: 6 power distribution terminals (3 input, 3 output)
    • Wire Size: 1.5–16 mm² (AWG 16–6) solid/stranded copper wire

AEG AS-P933-01

  • Product Introduction: AEG AS-P933-01 is a high-reliability 120W redundant power supply module exclusively designed for Modicon 900 series PLC chassis, engineered to deliver uninterrupted, stable DC power to PLC CPU, I/O and communication modules in mission-critical industrial automation and process control applications. The module features dual independent 24 V DC input power paths, automatic power failover, high efficiency power conversion, and comprehensive overvoltage/overcurrent protection, ensuring zero power interruption to the PLC system if one input power source fails. It has a compact modular design, seamless backplane integration, and real-time status monitoring with LED indicators, making it an essential component for safety instrumented systems (SIS), critical process control, and 24/7 continuous operation applications where PLC downtime would result in production loss, equipment damage, or safety hazards.
  • Technical Specifications:
    • Power Output: 24 V DC (adjustable ±5% via trim potentiometer), 5 A continuous output (120 W total power)
    • Input Power: Dual redundant 24 V DC input (Path 1 + Path 2), 18-30 V DC operating range per input
    • Power Failover: Automatic seamless switchover (<1 ms) between input paths, no PLC system interruption
    • Conversion Efficiency: >92% at full load, >90% at 50% load (high efficiency reduces heat generation)
    • Ripple & Noise: <30 mV peak-to-peak (at 24 V DC output, full load) – low noise for sensitive PLC electronics
    • Protection Features: Overvoltage protection (OVP: 28.8 V DC auto-shutoff), overcurrent protection (OCP: 6 A current limit), overtemperature protection (OTP: thermal shutdown at 85°C), reverse polarity protection (input paths)

AEG AS-S908-000

  • Product Introduction: AEG AS-S908-000 is a high-reliability serial communication module designed for the Modicon 900 and 984 series PLC systems, engineered to extend serial communication capabilities for connection to field devices, HMIs, printers and third-party control equipment with RS-232/RS-485 interfaces. The module features two independent configurable serial ports, support for multiple industrial serial protocols, high-speed data transfer and built-in fault detection, delivering reliable bi-directional communication in harsh industrial environments. It integrates seamlessly with the Modicon backplane bus, supports configuration via PLC programming software, and is an ideal solution for expanding serial communication in Modicon PLC systems for factory automation, process control and building automation applications where industrial serial fieldbus connectivity is required.
  • Technical Specifications:
    • Number of Communication Ports: 2 fully independent configurable serial ports (Port 1: RS-232/RS-485; Port 2: RS-485 only)
    • Supported Protocols: Modbus RTU/ASCII, DF1, ASCII/RTU generic serial, Siemens S7 PPI, Mitsubishi FX protocol
    • Port Configuration: Software-configurable per port (protocol, baud rate, data bits, stop bits, parity, flow control)
    • Baud Rate: 1200/2400/4800/9600/19200/38400/57600/115200 bps, selectable per port
    • Data Format: Configurable data bits (7/8), stop bits (1/2), parity (none/odd/even)
    • Communication Distance: Up to 15 meters (RS-232), up to 1200 meters (RS-485, 9600 bps), extendable via repeaters

AEG PC-A984

  • Product Introduction: AEG PC-A984 is a high-performance central processing unit (CPU) module designed as the core of the Modicon 984 series PLC systems, engineered for medium to large-scale industrial automation and process control applications. The CPU features a 32-bit RISC processor, high-capacity on-board memory, multi-protocol communication support and a high-speed backplane bus interface, delivering fast program execution and real-time I/O data processing. It supports IEC 61131-3 programming standards, built-in diagnostic functions and redundant power supply input, with a rugged industrial design optimized for 24/7 continuous operation in harsh environments. The PC-A984 is the primary control component for Modicon 984 series PLC systems, enabling complex control logic, sequential process control and integration with industrial networks in factory automation, process control and building automation applications.
  • Technical Specifications:
    • Processor: 32-bit industrial RISC processor, 80 MHz clock speed
    • Program Execution Speed: 0.1 μs per boolean instruction, 0.5 μs per floating-point instruction
    • On-Board Memory: 2 MB Flash program memory (non-volatile), 1 MB RAM data memory, expandable via AS-M996-000 memory module
    • Supported Programming Standards: IEC 61131-3 (Ladder Logic, Function Block Diagram, Structured Text, Sequential Function Chart, Instruction List)

AEG AS-J890-001

  • Product Introduction: AEG AS-J890-001 is a multi-protocol industrial communication gateway module designed for the Modicon 800 and 900 series PLC systems, engineered to enable seamless data exchange between Modicon PLCs and third-party industrial control devices, HMIs, SCADA systems and industrial networks. The module features dual independent communication ports, support for all mainstream industrial communication protocols, and a high-speed backplane interface, providing bi-directional real-time data transfer and protocol conversion with ultra-low latency. It supports configuration via PLC programming software, has built-in fault detection and redundant communication options, and is an ideal solution for integrating Modicon PLC systems into multi-vendor industrial automation networks in factory automation, process control and building automation applications.
  • Technical Specifications:
    • Communication Ports: 2 independent configurable communication ports (Port 1: RS-485/RS-232; Port 2: Ethernet RJ45 + RS-485)
    • Supported Protocols: Modbus RTU/ASCII/TCP, Profibus-DP, Ethernet/IP, DeviceNet, CANopen, Siemens S7 PPI/MPI, Mitsubishi MC Protocol
    • Backplane Interface: Modicon 800/900 series proprietary high-speed bus, 20 Mbps data transfer rate, <0.5 ms latency
    • Data Transfer Capacity: Up to 1024 input and 1024 output data words (bi-directional), configurable data mapping

AEG AS-B875-002

  • Product Introduction: AEG AS-B875-002 is a high-precision 4-channel thermocouple input module designed for the Modicon 800 series PLC systems, optimized for critical temperature measurement and control applications in industrial process control, manufacturing and instrumentation. The module features built-in high-accuracy cold junction compensation (CJC), advanced signal conditioning, wide thermocouple type support and full channel-to-channel isolation, delivering ultra-precise and stable temperature data even in high-noise industrial environments. It supports high-speed sampling and configurable digital filtering, and integrates seamlessly with the Modicon 800 series backplane bus, making it an ideal solution for critical temperature monitoring in pharmaceutical, semiconductor, chemical and food manufacturing applications requiring GMP/ISO-compliant precision measurements.
  • Technical Specifications:
    • Number of Input Channels: 4 fully isolated thermocouple input channels (channel-to-channel and channel-to-backplane)
    • Supported Thermocouple Types: Software-configurable per channel – J, K, T, E, R, S, B, N (8 industrial standard types)
    • Measurement Range: Dependent on thermocouple type – J (-210°C to +1250°C), K (-270°C to +1372°C), T (-270°C to +400°C), E (-270°C to +900°C), R (0°C to +1768°C), S (0°C to +1768°C), B (400°C to +1820°C), N (-200°C to +1300°C)

AEG AS-M996-000

  • Product Introduction: AEG AS-M996-000 is a high-capacity non-volatile memory module designed for the Modicon 984 and 900 series PLC systems, engineered to provide expanded storage for large control programs, process data logs, recipe parameters and alarm event records. The module features industrial-grade SLC NAND Flash memory, a high-speed backplane interface, and no-battery data retention, eliminating the risk of data loss from battery failure and reducing maintenance requirements. It supports seamless integration with Modicon 984/900 series CPU modules, with automatic memory detection and allocation, and is ideal for complex industrial automation applications requiring large program storage, long-term data logging and high-reliability non-volatile memory.
  • Technical Specifications:
    • Memory Type: Industrial-grade SLC NAND Flash (non-volatile), no battery required for data retention
    • Total Memory Capacity: 4 MB (2 MB program memory + 2 MB data memory), dual partitioned storage
    • Data Retention: >15 years at 25°C, >7 years at 70°C (no power applied)
    • Access Speed: <40 ns read speed, <80 μs write speed (high-speed for real-time PLC operation)
    • Backplane Interface: Modicon 984/900 series proprietary high-speed bus, 10 Mbps data transfer rate

AEG 15A0251-000

  • Product Introduction: AEG 15A0251-000 is a high-reliability backplane module engineered as the core interconnect component for Modicon 800 series PLC chassis, providing a dedicated communication and power distribution bus for all installed I/O, communication and power modules. The backplane features a rugged PCB construction, gold-plated contact pins, isolated power/communication channels and built-in fault detection, ensuring fast, reliable data transfer and stable power distribution between the PLC CPU and all peripheral modules. It is designed for 24/7 continuous operation in harsh industrial environments, with high vibration/shock resistance and wide temperature tolerance, and is a critical replacement and upgrade component for Modicon 800 series PLC systems in factory automation, process control and building automation applications.
  • Technical Specifications:
    • Chassis Compatibility: Modicon 800 series 8-slot PLC chassis (primary and expansion chassis)
    • Number of Module Slots: 8 standard Modicon 800 series module slots, 1 dedicated CPU slot + 7 universal I/O/communication slots
    • Backplane Bus Protocol: Modicon 800 series proprietary high-speed bus, 20 Mbps data transfer rate
    • Data Transfer Latency: <0.5 ms between CPU and any I/O slot, synchronous data transfer for all slots
    • Power Distribution: Isolated +5 V DC (logic power) and +24 V DC (I/O power) to each slot; 5 A +5 V DC / 10 A +24 V DC per chassis total
