AEG PC-0984-785 Industrial Communication Interface Module

  • Product Introduction: It is an industrial - grade communication interface module used to realize the communication between the AEG PLC system and various fieldbus devices and upper - computer monitoring systems, so as to achieve the integration and information sharing of the industrial automation system.
  • Technical Specifications:
    • Supported Fieldbus Protocols: Profibus - DP, DeviceNet, Modbus RTU
    • Communication Interfaces: 1 Profibus - DP port, 1 DeviceNet port, 1 RS485 port
    • Data Transmission Rate: Profibus - DP: up to 12Mbps; DeviceNet: up to 500kbps; RS485: up to 115.2kbps
    • Working Voltage: 24V DC

AEG ALU150 Analog Signal Conversion Module

  • Product Introduction: It is an analog signal conversion module used to convert the analog signals from on - site sensors or other equipment into standard analog signals that can be recognized by the PLC or DCS system, so as to realize the integration of various analog signals in the industrial control system.
  • Technical Specifications:
    • Input Signal Types: 0-5V DC, 0-10V DC, 4-20mA DC
    • Output Signal Types: 4-20mA DC, 0-10V DC (switchable)
    • Conversion Accuracy: ±0.1% of full scale
    • Linear Error: ≤0.05% of full scale

AEG 490NRP25300 Network Router Module

  • Product Introduction: It is a network router module specially designed for industrial fields, which is used to realize data transmission and communication between different networks in the industrial automation system and ensure the smooth and reliable data communication.
  • Technical Specifications:
    • Network Interfaces: 2 Ethernet ports (10/100Mbps)
    • Routing Protocols: Static routing, RIP v1/v2
    • Firewall Function: Support for packet filtering and access control list (ACL)
    • Working Voltage: 24V DC

AEG Modicon AS-B802-008 Digital Output Module

  • Product Introduction: It is a digital output module designed for industrial automation control systems, which is used to output digital control signals to drive on - site actuators and realize the control of the production process.
  • Technical Specifications:
    • Number of Output Channels: 8 channels
    • Output Type: Transistor (NPN) output
    • Rated Voltage: 24V DC
    • Rated Current: 2A per channel, 8A for the whole module (total current)

AEG Modicon AS-B840-108 Analog Input Module

  • Product Introduction: This analog input module is used to collect analog signals (such as temperature, pressure, and flow) from on - site sensors and transmit them to the PLC for processing, providing data support for the control and monitoring of the production process.
  • Technical Specifications:
    • Number of Input Channels: 8 channels
    • Input Types: Thermocouple (J, K, T, E, R, S, B types), RTD (PT100, PT1000)
    • Input Range: For thermocouple: -200°C to +1800°C; for RTD: -200°C to +850°C
    • Accuracy: ±0.2% of full scale
    • Resolution: 16 bits
    • Working Voltage: 24V DC

AEG ALU150 Analog Output Module

  • Product Introduction: It is an analog output module used to convert the digital control signals from the PLC into analog signals (current or voltage) to control analog - controlled equipment in the industrial field, such as frequency converters and regulators.
  • Technical Specifications:
    • Number of Output Channels: 4 channels
    • Output Types: 4-20mA DC current output, 0-10V DC voltage output (switchable per channel)
    • Output Accuracy: ±0.1% of full scale
    • Resolution: 16 bits
    • Load Capacity: 500Ω for current output, 10kΩ for voltage output

AEG 110CPU62200 Programmable Logic Controller (PLC) CPU Module

  • Product Introduction: As the core component of the AEG 110 series PLC, it is responsible for executing user programs, processing input and output signals, and communicating with other modules and devices to realize the centralized control of the industrial automation system.
  • Technical Specifications:
    • Processor: 32 - bit RISC processor with a main frequency of 800MHz
    • Memory: 16MB RAM, 32MB Flash memory
    • Number of I/O Points: Up to 8192 points can be expanded
    • Communication Interfaces: Ethernet (TCP/IP), RS232, RS485
    • Programming Language: Ladder Diagram (LD), Function Block Diagram (FBD), Structured Text (ST)

AEG 6051-042.23602 Digital Output Module

  • Product Introduction: It is a digital output module for industrial automation control systems, which is used to convert the control signals from the controller into on - site executable actions to drive various actuators.
  • Technical Specifications:
    • Number of Output Channels: 16 channels
    • Output Type: Relay output
    • Rated Voltage: 230V AC, 24V DC
    • Rated Current: 5A per channel, 32A for the whole module (total current)
    • Response Time: ≤10ms
    • Working Voltage: 24V DC

AEG DEA156 Digital Encoder Module

  • Product Introduction: It is a digital encoder module designed for precise position and speed detection in industrial motion control systems, providing high - precision position and speed feedback signals for servo motors and stepping motors.
  • Technical Specifications:
    • Resolution: 156 pulses per revolution
    • Output Signal: A, B, Z three - channel square wave signals
    • Output Voltage: 5V DC
    • Output Current: 20mA per channel

AEG Modicon AS-B827-032 24V DC Digital Input Module

  • Product Introduction: This is a high - performance digital input module belonging to the AEG Modicon series, which is specially used to collect digital input signals in industrial automation control systems and transmit them to the main controller for processing, so as to realize the monitoring and control of on - site equipment.
  • Technical Specifications:
    • Number of Input Channels: 32 channels
    • Input Type: 24V DC sinking input
    • Input Voltage Range: 18-30V DC
    • Input Current: 5mA per channel

AEG MM-PM10-20S Power Monitoring Module

  • Product Introduction: It is a dedicated power monitoring module designed for industrial power distribution systems to provide real-time and accurate monitoring of electrical parameters, ensuring the stable and efficient operation of the power system.
  • Technical Specifications:
    • Input Voltage: 3-phase 400V AC, 50/60Hz
    • Current Measurement Range: 0-100A
    • Accuracy Class: 0.5S for current and voltage, 1.0 for power
    • Communication Interface: RS485, Modbus RTU protocol
    • Working Voltage: 24V DC

AEG AS-C951-009 Industrial PLC Chassis Expansion Backplane

  • Product Introduction: AEG AS-C951-009 is a high-reliability 9-slot industrial PLC chassis expansion backplane exclusively designed for the Modicon 900 series PLC systems, engineered to provide a secure, high-speed interconnect for Modicon 900 series CPU, I/O, communication, and power supply modules in medium to large-scale industrial automation and process control applications. The backplane features a proprietary high-speed data bus, dedicated isolated power distribution rails, and rugged mechanical construction, delivering stable 10 Mbps data transfer between modules and reliable 24 V DC/5 V DC power distribution to all installed PLC components. It is built with corrosion-resistant metal framing, gold-plated contact slots, and vibration-resistant mounting hardware, with compliance with Modicon 900 series mechanical and electrical specifications. The expansion backplane enables scalable system expansion for Modicon 900 series PLCs, supporting the addition of I/O, communication, and special function modules to meet the growing requirements of complex industrial automation systems in manufacturing, process control, and municipal infrastructure applications.
  • Technical Specifications:
    • Slot Quantity: 9 standard Modicon 900 series module slots, compatible with all Modicon 900 series I/O, communication, CPU, and power modules
    • Backplane Data Bus: Proprietary Modicon 900 series high-speed bus, 10 Mbps synchronous data transfer rate, <0.5 ms module-to-module latency
    • Bus Topology: Linear daisy-chain, support for up to 4 cascaded expansion backplanes (36 total slots) per CPU
    • Power Distribution Rails: 3 isolated power rails (5 V DC logic power, 24 V DC I/O power, 24 V DC auxiliary power), individually fused
