Yokogawa SCP461-51 Safety-Related Redundant CPU Module

  • Product Introduction: It is a safety - level redundant CPU module belonging to Yokogawa's ProSafe - RS safety instrumented system. It is designed based on the IEC 61508 standard, with SIL 3 safety integrity level. It is used to implement the core safety logic calculation and control functions in the industrial process.
  • Technical Specifications:
    • Safety integrity level: SIL 3, in line with IEC 61508 and IEC 61511 standards.
    • CPU configuration: Dual - core redundant CPU, operating frequency 800MHz.
    • Memory: 1GB SDRAM (with ECC function), 512MB Flash.

Yokogawa ALP111-S00 Process Control Network Communication Module

  • Product Introduction: It is a special communication module for Yokogawa's CENTUM CS3000/CENTUM VP DCS system. It is used to realize the data exchange between the process control network (Vnet/IP) and the field control station, ensuring the real - time and integrity of data transmission between the system layers.
  • Technical Specifications:
    • Communication protocol: Vnet/IP protocol, communication speed 1Gbps.
    • Working voltage: 24V DC, power consumption ≤ 400mA.
    • Isolation: 1.5kV AC between the network port and the system for 1 minute.

Yokogawa ALE111-S51 Ethernet Communication Module

  • Product Introduction: It is a high - speed Ethernet communication module designed for Yokogawa's DCS and safety instrumented systems. It provides a standard Ethernet interface to realize data communication between the control system and upper - level computers, operator stations, MES systems and other external devices, and supports multiple industrial Ethernet protocols.
  • Technical Specifications:
    • Communication protocol: Support Ethernet/IP, Modbus TCP, PROFINET and other protocols.
    • Number of ports: 2 independent 10/100/1000Mbps Ethernet ports.
    • Working voltage: 24V DC, current consumption ≤ 300mA.

Yokogawa CP461-11 Redundant CPU Module for CENTUM VP DCS

  • Product Introduction: It is a high - performance redundant CPU module designed for Yokogawa's CENTUM VP distributed control system. It adopts a dual - CPU redundant architecture, which can automatically switch when a fault occurs, ensuring the continuous and stable operation of the industrial process, and is the core component to improve the reliability of the control system.
  • Technical Specifications:
    • CPU model: 32 - bit RISC processor, operating frequency 1GHz.
    • Memory configuration: 2GB DDR3 SDRAM, 1GB Flash memory.
    • Redundancy mode: 1:1 hot standby redundancy, automatic switching time ≤ 100ms.

Yokogawa SNT501-53 Safety Network Terminal Module

  • Product Introduction: It is a safety - related network terminal module belonging to Yokogawa's ProSafe - RS safety instrumented system. It is mainly used to realize the data interaction between the safety control station and the field safety instrument, ensuring the real - time and reliability of safety information transmission, and meeting the strict safety requirements of industrial processes.
  • Technical Specifications:
    • Safety integrity level: SIL 2, in line with IEC 61508 and IEC 61511 standards.
    • Communication protocol: Supports ESB safety bus, communication speed 1 Mbps.
    • Number of channels: 16 safety - related signal channels (input/output configurable).

Yokogawa ACG10S-E2120+AIP903

  • Product Introduction: It is a combined module set composed of the ACG10S - E2120 power module and the AIP903 I/O interface module, which is specially used for the power supply and signal interface expansion of Yokogawa's industrial control system. It integrates power conversion and I/O signal processing functions to provide a stable and efficient solution for the system's power supply and signal interaction.
  • Technical Specifications:
    • ACG10S - E2120 Power Module:
      • Input voltage: AC 100-240V, frequency 50/60Hz.
      • Output voltage: 24V DC, output current 10A.
      • Efficiency: ≥ 85%.
      • Working temperature: -10~60°C.

Yokogawa SB401-50 Bus Interface Module

  • Product Introduction: It is a programmable bus interface module specially designed for Yokogawa's CENTUM VP DCS system. It serves as a critical bridge for data transmission and communication between the DCS system and various I/O modules, supporting flexible configuration to meet the diverse needs of industrial automation scenarios, and ensuring stable data exchange in harsh industrial environments.
  • Technical Specifications:
    • Communication bus: ESB bus, communication speed 1 Mbps.
    • Redundancy support: Dual - bus redundancy configuration available.
    • Working voltage: 24V DC, power consumption ≤ 10W.
    • Isolation: 2kV AC between the bus and the system for 1 minute.

Yokogawa EB401-10

  • Product Introduction: It is a 16-channel digital I/O module for Yokogawa CENTUM VP DCS system, which integrates digital input and output functions, and is used to connect on-site discrete devices (such as valves, pumps, sensors, etc.) and realize signal interaction between the control system and on-site devices.
  • Technical Specifications:
    • Number of channels: 16 channels (8 digital inputs and 8 digital outputs).
    • Digital input: 24V DC, input voltage range 19.2-30V DC, input current ≤5mA, response time ≤1ms.
    • Digital output: 24V DC, output current 2A per channel, short-circuit protection function.

Yokogawa ALR121-S00

Technical Specifications:

  • Communication protocol: Modbus RTU/TCP, Ethernet/IP, etc..
  • Number of communication ports: 2 Ethernet ports (10/100Mbps).
  • Working voltage: 24V DC, current consumption ≤ 300mA.
  • Working temperature: -20~70°C.
  • Isolation: 1.5kV AC between communication port and system for 1 minute.
  • Data transmission rate: 100Mbps (Ethernet).

Yokogawa YHC4100-01-1-0

  • Product Introduction: It is a portable handheld HART communicator launched by Yokogawa, which is used to communicate with HART protocol field instruments (such as pressure transmitters, flowmeters, etc.), and can realize functions such as parameter configuration, calibration, and diagnosis of field instruments.
  • Technical Specifications:
    • Communication protocol: HART 7.0.
    • Power supply: Rechargeable lithium-ion battery, working time ≥ 12 hours.
    • Display: 3.5-inch color LCD, with backlight function.

Yokogawa SAI143-S63

Technical Specifications:

  • Number of channels: 16 channels, module isolation.
  • Input signal: 4-20mA DC.
  • Transmitter power supply: 2-wire setting, applicable to all 16 channels simultaneously.
  • Data update frequency: 40ms.
  • Isolation: 1.5kV AC between input signal and system for 1 minute.
  • Working temperature: -20~70°C (comply with ISA standard G3 option).
  • Connection method: Analog pressure clamp terminal (with surge absorber), model STA4S-10.

Yokogawa AAI543-H53

Technical Specifications:

  • Number of channels: 16 isolated channels.
  • Input signal: 4-20mA DC, 0-20mA DC, 1-5V DC, etc..
  • Accuracy: ±0.1% of full scale.
  • Data update cycle: 10ms.
  • Input resistance: 270Ω (20mA) to 350Ω (4mA) when powered on, 500kΩ or more when powered off.
