Yokogawa 253710-D/M3/C7 Terminal Block

Technical Specifications:

  • Type: Spring - type terminal block, suitable for 1.5-2.5mm² cables.
  • Rated voltage: 600V AC.
  • Rated current: 20A.
  • Contact resistance: ≤1mΩ.
  • Insulation resistance: ≥100MΩ.
  • Working temperature: -40~85°C.
  • Material: High - temperature resistant engineering plastic (housing), copper alloy (contact).

Yokogawa AXF025C-NNAL1L-BA11-2NB

Technical Specifications:

  • Pipe diameter: DN25 (1 inch).
  • Measurement accuracy: ±0.35% of rate (0.2% of rate optional for high - precision type).
  • Flow range: 0.05-10m/s.
  • Fluid temperature: -40~160°C (general type), -10~160°C (sanitary type).
  • Fluid conductivity: ≥5μS/cm.
  • Output signal: 4-20mA DC, pulse output, HART communication.
  • Power supply: 100-240V AC or 24V DC.
  • Protection level: IP67 (sensor), IP65 (converter).

Yokogawa OR342-2 Digital Output Relay Module

Technical Specifications:

  • Number of channels: 8 independent relay output channels.
  • Output contact capacity: 250V AC, 5A per channel (resistive load).
  • Response time: ≤10ms.
  • Working voltage: 24V DC, current consumption ≤ 200mA.
  • Isolation: 2kV AC between output and system for 1 minute.
  • Working temperature: -20~70°C.
  • Connection method: Screw terminal, easy to wire and maintain.

Yokogawa CX2410-1-0-1 Data Acquisition Module

Technical Specifications:

  • Number of channels: 4 isolated analog input channels.
  • Input signal: 4-20mA DC, 1-5V DC, thermocouple (K, J, T, E, etc.), RTD (Pt100).
  • Measurement accuracy: ±0.05% of full scale.
  • Data update cycle: 10ms.
  • Isolation: 500V AC between channels, 1.5kV AC between input and system for 1 minute.
  • Working voltage: 24V DC, current consumption ≤ 100mA.
  • Working temperature: -20~70°C.

Yokogawa DY040-EBMAA1D/FF1/SCT

Technical Specifications:

  • Measured medium: Liquid, gas, steam (avoid multiphase flow and viscous fluid).
  • Measurement accuracy: ±0.75% of reading (liquid), ±1% of reading (gas, steam).
  • Repeatability: ±0.2% of reading.
  • Process temperature: -29~250°C (general type).
  • Process pressure: Up to 10MPa.
  • Output signal: 4-20mA DC current output, FOUNDATION Fieldbus (FF1) digital communication.
  • Power supply: 10.5-42V DC.
  • Connection method: Wafer or flange connection, stainless steel tag plate (SCT option)quote.us.yokogawa.com

Yokogawa AXFA14C-E1-21/CF1

Technical Specifications:

  • Communication protocol: FOUNDATION Fieldbus (FF1).
  • Input signal: The signal from the magnetic flowmeter sensor (the induced voltage generated by the fluid cutting magnetic field).
  • Output signal: 4-20mA DC current output, pulse output (up to 20000 PPS).
  • Power supply: 100-240V AC or 100-120V DC.
  • Working temperature: -40~60°C (explosion - proof type).
  • Explosion - proof certification: CSA certification (CF1 option).
  • Connection method: 1/2”NPT electrical connection.

Yokogawa FX106-4-2 4-Channel Paperless Videographic Recorder

Technical Specifications:

  • Number of input channels: 4 isolated analog input channels.
  • Input signal: Support thermocouple (R, S, B, K, E, J, T, N, etc.), RTD (Pt100, JPt100), 4-20mA DC and 1-5V DC signals.
  • Measurement interval: 1s, 2s optional.
  • Storage capacity: Built - in 128MB flash memory, supporting external CF card expansion (up to 2GB).
  • Display: 5.5 - inch TFT color LCD, multiple display modes (trend graph, digital value, bar graph, etc.).
  • Power supply: 100-240V AC, 50/60Hz, power consumption ≤ 35VA.
  • Protection level: IP65 (front panel).

Yokogawa UT450-00 Digital Indicating Controller

Technical Specifications:

  • Input type: Universal input, supporting thermocouple (R, S, B, K, E, J, T, N, etc.), RTD (Pt100, JPt100), 4-20mA DC and 1-5V DC signals.
  • Measurement accuracy: ±0.1% of full scale.
  • Input sampling period: 200ms.
  • Control output: Relay contact output (250V AC, 5A), voltage pulse output (12V DC, 100mA), 4-20mA DC current output (optional).
  • Power supply: 100-240V AC, 50/60Hz, power consumption ≤ 10VA.

Yokogawa LM21020L0G Digital Indicating Controller Module

Technical Specifications:

  • Input signal: Universal input, supporting thermocouple (K, J, T, E, etc.), RTD (Pt100, JPt100), 4-20mA DC current signal and 1-5V DC voltage signal.
  • Measurement accuracy: ±0.1% of full scale.
  • Control output: Relay contact output (250V AC, 5A), voltage pulse output (12V DC, 100mA), current output (4-20mA DC).
  • Working voltage: 100-240V AC, 50/60Hz, power consumption ≤ 15VA.
  • Display: 5 - digit LED display, with backlight function, the display value can be read clearly under various lighting conditions.
  • Communication interface: RS - 485 (Modbus RTU protocol), baud rate 9600bps - 38400bps optional.

Yokogawa ANT502-50 Optical ESB Bus Node Unit.

Technical Specifications

  • Communication Interface: Optical ESB bus, LC connector (IEC61754 - 20 compliant).
  • Fiber Type: Quartz single - mode, complying with IEC 60793-2-50 B1.1 standard.
  • Transmission Distance: Up to 5 km per hop (when used with ANT401).
  • Maximum Optical Loss: 0-10 dB at 1.3 μm wavelength.
  • Supported Network Topologies: Chain and star configurations.
  • Maximum Stages (Chain): 2 hops.
  • Maximum Connections: 8 (combined chain and star type).

Yokogawa SAI143-H63 HART Analog Input Module

  • Product Introduction: The Yokogawa SAI143-H63 is a high - performance analog input module belonging to Yokogawa's industrial automation product line. It is mainly used to collect analog signals from field devices, convert them into digital signals that the control system can process, and provide accurate and reliable data support for industrial process control. It is compatible with Yokogawa's CENTUM VP and other related control systems, and can be flexibly configured according to actual engineering needs.
  • Technical Specifications
    • Input Channels: 16 isolated channels.
    • Input Signal Types and Ranges: Voltage: -10 to 10 V, 0 to 10 V, 1 to 5 V; Current: 4 to 20 mA.
    • Resolution: 16 - bit (1/32767).
    • Accuracy: ±0.2% of full scale.
    • Data Update Frequency: 40 ms.

Yokogawa SEC401-11 Safety Bus Coupler Module

  • Product Introduction: It is a safety bus coupler module for Yokogawa's ProSafe - RS safety instrumented system. It is used to connect the safety field bus (ESB) and the safety I/O module, realize the data transmission between the safety controller and the field safety instrument, and meet the safety communication requirements of SIL 2/SIL 3 systems.
  • Technical Specifications:
    • Safety bus: ESB bus, communication speed 1 Mbps.
    • Number of connected modules: Up to 32 safety I/O modules can be connected.
    • Working voltage: 24V DC, current consumption ≤ 600mA.
    • Isolation: 2kV AC between the bus and the system for 1 minute.
