Yokogawa SC41-SP43 Digital Input Module

  • Product Introduction: An 8-channel digital input module for Yokogawa’s industrial control systems, designed for high-speed acquisition of digital signals from field devices like limit switches, pushbuttons, and proximity sensors.
  • Technical Specifications:
    • Number of Channels: 8 isolated channels
    • Input Type: Dry contact, 24V DC (sinking/sourcing)
    • Input Voltage: 24V DC (19.2-28.8V DC)
    • Response Time: ≤1ms

Yokogawa SCP401-11 Processor Module

  • Product Introduction: A high-performance processor module for Yokogawa’s SSC10S/D safety instrumented systems, executing safety control logic, managing I/O modules, and coordinating communication for functional safety applications.
  • Technical Specifications:
    • CPU: 32-bit RISC processor, 500 MHz clock speed
    • Memory: 256MB RAM, 128MB Flash memory
    • Communication Interfaces: Vnet S1, H1, H2, F1-F4 fieldbus ports
    • Safety Integrity Level: SIL 3 (per IEC 61508)

Yokogawa SNB10D-245 ESB Bus Interface Module

  • Product Introduction: An ESB bus interface module for connecting Yokogawa’s SSC safety controllers to SNB10D remote I/O stations, enabling communication between control units and distributed I/O modules in safety instrumented systems.
  • Technical Specifications:
    • Communication Protocol: ESB bus, 1 Mbps data rate
    • Number of ESB Ports: 1
    • I/O Capacity: Supports up to 16 I/O modules per station

Yokogawa FU20-05-T1-FSM Flow Computer

  • Product Introduction: A compact flow computer designed for custody transfer and process control applications, featuring a T1 communication interface and FSM (Flow Sequential Measurement) function for accurate flow calculation and data logging.
  • Technical Specifications:
    • Input Signals: 4-20mA DC (flow, pressure, temperature), pulse inputs
    • Communication: T1 (E1) interface, RS-485 (Modbus RTU)
    • Flow Calculation: Compensated flow using AGA, ISO, and API standards
    • Memory: 8MB non-volatile memory for data storage

Yokogawa EB511-10 Terminal Board

  • Product Introduction: A 10-point terminal board for Yokogawa’s I/O modules, providing secure and organized wiring connections for field devices, with screw terminals for easy installation and maintenance.
  • Technical Specifications:
    • Number of Terminals: 10 screw terminals
    • Terminal Type: Screw-clamp, suitable for 0.5-2.5 mm² wires
    • Rated Voltage: 250V AC
    • Rated Current: 10A per terminal

Yokogawa ADV151-P00 S2 I/O Analog Input Module

  • Product Introduction: A 16-channel analog input module for Yokogawa’s S2 I/O system, designed for high-precision measurement of process variables with HART communication capability for smart sensor integration.
  • Technical Specifications:
    • Number of Channels: 16 differential channels
    • Input Signal: 4-20mA DC, HART protocol compatible
    • Measurement Accuracy: ±0.04% of full scale
    • Sampling Rate: 10 ms per channel

Yokogawa SEC402-51 ESB Bus Controller Module

  • Product Introduction: An ESB (Enhanced Serial Bus) controller module for Yokogawa’s SSC10S/D safety instrumented systems, enabling communication between safety controllers and I/O modules for functional safety applications.
  • Technical Specifications:
    • Communication Protocol: ESB bus, 1 Mbps data rate
    • Number of ESB Ports: 2 (redundant)
    • I/O Capacity: Supports up to 32 I/O modules
    • Power Supply: 24V DC, 3W power consumption

Yokogawa NFPW442-10 Power Supply Module

  • Product Introduction: A high-reliability power supply module for Yokogawa’s FCN-RTU autonomous control systems, delivering stable 24V DC power to I/O modules and controllers, with a 10A output rating for distributed control applications.
  • Technical Specifications:
    • Input Voltage: 100-240V AC, 50/60Hz
    • Output Voltage: 24V DC, 10A maximum output current
    • Ripple Noise: ≤100mV peak-to-peak
    • Efficiency: ≥85%

Yokogawa AAR181-S00 RTD Input Module

  • Product Introduction: A 12-channel isolated RTD input module for Yokogawa’s industrial control systems, dedicated to high-precision temperature measurement via RTD sensors, ensuring reliable data acquisition in industrial processes.
  • Technical Specifications:
    • Number of Channels: 12 isolated channels
    • Input Type: Pt100, Pt500, Pt1000, Ni100, Ni200 RTD (IEC 60751, DIN 43760)
    • Measurement Accuracy: ±0.05% of full scale
    • Sampling Cycle: 100 ms per channel

Yokogawa DL750P Digital Oscilloscope

  • Product Introduction: A portable digital oscilloscope with high sampling rate and bandwidth, designed for troubleshooting and analyzing electrical signals in industrial electronics, automotive systems, and research laboratories.
  • Technical Specifications:
    • Number of Channels: 4 analog channels, 16 digital channels (optional)
    • Bandwidth: 500 MHz
    • Sampling Rate: 2.5 GS/s per channel (interleaved mode: 5 GS/s)
    • Memory Depth: 128 Mpoints per channel

Yokogawa DX2040 Paperless Recorder (Base Model)

  • Product Introduction: A modular paperless recorder with configurable input/output options, serving as a flexible data logging solution for industrial processes, with expandable channels and communication interfaces.
  • Technical Specifications:
    • Input Channels: Up to 16 channels (expandable via modules)
    • Input Types: Thermocouple, RTD, 4-20mA, 0-10V, digital signals
    • Display: 10.4-inch color LCD with touchscreen
    • Data Storage: 4GB internal memory, SD card slot for additional storage

Yokogawa ZR22G-150-S-E-C-R-M-E-A Zirconia Oxygen Analyzer

  • Product Introduction: An in-situ zirconia oxygen analyzer designed for continuous measurement of oxygen concentration in flue gases, enabling efficient combustion control and emissions monitoring in industrial boilers and furnaces.
  • Technical Specifications:
    • Measurement Range: 0.1 to 25 vol% O₂
    • Accuracy: ±0.2 vol% O₂
    • Response Time: ≤5 seconds (90% of step change)
    • Operating Temperature: Probe: 600 to 1400°C; Converter: 0 to 50°C
