Yokogawa FX112-4-2 Digital Input Module

  • Product Introduction: An 8 - channel digital input module for Yokogawa’s FX series, designed for high - speed acquisition of dry contact or DC voltage signals from field devices, ensuring reliable monitoring in industrial automation.
  • Technical Specifications:
    • Channels: 8 isolated
    • Input: Dry contact, 24V DC (sinking/sourcing)
    • Voltage: 19.2-28.8V DC
    • Response Time: ≤1ms

Yokogawa AFM10S Field Control Unit

  • Product Introduction: A compact, modular field control unit designed for distributed control in industrial automation, part of Yokogawa’s CENTUM VP system, supporting Vnet/IP communication and FIO I/O modules for real-time process control and monitoring.
  • Technical Specifications:
    • Communication: Vnet/IP (1000BASE - T), FIO bus
    • Processor: 32 - bit RISC, 133 MHz
    • I/O Capacity: 8 FIO modules, 128 I/O points
    • Power: 24V DC, 10W

Yokogawa SE115MJ Electromagnetic Flowmeter

  • Product Introduction: A compact electromagnetic flowmeter for measuring conductive fluid flow, featuring a PFA  and 316L stainless steel electrodes, designed for accurate and reliable flow measurement in industrial processes.
  • Technical Specifications:
    • Pipe Diameter: DN15 (1/2 inch)
    • Flow Range: 0-10 m/s
    • Accuracy: ±0.5% of measured value
    • Lining Material: PFA
    • Electrode Material: 316L stainless steel
    • Output Signal: 4-20mA DC, pulse, alarm

Yokogawa PW702 Power Supply Module

  • Product Introduction: A reliable 24V DC power supply module for Yokogawa’s industrial control systems, delivering stable power to I/O modules and field devices, with overcurrent and overvoltage protection for system safety.
  • Technical Specifications:
    • Input Voltage: 100-240V AC, 50/60Hz
    • Output Voltage: 24V DC, 2A maximum output current
    • Ripple Noise: ≤50mV peak - to - peak
    • Efficiency: ≥80%

Yokogawa ASI533-H00 Analog Input Module

  • Product Introduction: An 8 - channel analog input module for Yokogawa’s digital recording and control systems, providing high - precision data acquisition from field sensors with Modbus communication for industrial process monitoring.
  • Technical Specifications:
    • Number of Channels: 8 isolated channels
    • Input Signal: 4-20mA DC, 0-10V DC
    • Measurement Accuracy: ±0.05% of full scale
    • Sampling Rate: 100 ms per channel

Yokogawa UB5C-015N-1AB-2C1-2/CE/CN/Z/02S0022

  • Product Introduction: A glass - body pH electrode for industrial process pH measurement, designed for reliable operation in harsh chemical environments, with a KCl reference system for stable measurement accuracy.
  • Technical Specifications:
    • Measurement Range: 0-14 pH
    • Accuracy: ±0.02 pH
    • Temperature Range: 0 to 100°C
    • Pressure Rating: 0-1.0 MPa

Yokogawa AIP412-S1 Analog Input Module

  • Product Introduction: A 16 - channel analog input module for Yokogawa’s CENTUM VP DCS, dedicated to high - precision measurement of process variables with universal input compatibility and HART communication capability.
  • Technical Specifications:
    • Number of Channels: 16 isolated channels
    • Input Types: Thermocouple, RTD, 4-20mA, 0-10V
    • Measurement Accuracy: ±0.04% of full scale
    • Sampling Cycle: 10 ms per channel

Yokogawa TM50501640-3SN Linear Servo Actuator

  • Product Introduction: A precision linear servo actuator for high - speed and high - accuracy linear motion control, featuring a non - contact linear encoder for position feedback and a ball screw drive for smooth motion.
  • Technical Specifications:
    • Stroke Length: 1640mm
    • Maximum Speed: 1000 mm/s
    • Positioning Accuracy: ±0.01mm
    • Thrust Force: 300N continuous, 900N peak

Yokogawa 760304-40-MV-F-/EC/C5/DT Power Analyzer Input Module

  • Product Introduction: A high - precision voltage input module for Yokogawa’s WT series power analyzers, designed for accurate measurement of AC/DC voltage signals in power electronics testing and energy monitoring applications.
  • Technical Specifications:
    • Input Voltage Range: 40V (MV), 10-40V AC/DC
    • Accuracy: ±0.02% of reading
    • Bandwidth: DC, 0.1Hz - 1MHz
    • Input Impedance: 10 MΩ

Yokogawa SR1045B62 DYNASERV DD Servo Actuator

  • Product Introduction: A high - torque direct - drive servo actuator for precision motion control applications, eliminating mechanical transmission components for zero - backlash and high - accuracy positioning.
  • Technical Specifications:
    • Torque Rating: 4.5 Nm continuous, 13.5 Nm peak
    • Resolution: 1,000,000 pulses per revolution
    • Maximum Speed: 300 rpm
    • Input Voltage: 230V AC, 50/60Hz

Yokogawa AFM10S-H4120 Field Control Unit

  • Product Introduction: A compact field control unit for Yokogawa’s industrial automation systems, designed for distributed control applications with Vnet/IP communication and FIO I/O module support, enabling real-time process monitoring and control in industrial environments.
  • Technical Specifications:
    • Communication Protocol: Vnet/IP (1000BASE - T), FIO bus
    • Processor: 32 - bit RISC processor, 133 MHz
    • I/O Capacity: Up to 8 FIO modules, 128 I/O points
    • Power Supply: 24V DC, 10W power consumption

Yokogawa ABC11D-V2123 Communication Interface Module

  • Product Introduction: A communication interface module for Yokogawa’s CENTUM VP DCS, providing a Vnet/IP connection for data exchange between field control units and operator stations, with advanced network redundancy for high availability.
  • Technical Specifications:
    • Communication Protocol: Vnet/IP (1000BASE-T)
    • Number of Ports: 2 (redundant)
    • Data Transfer Rate: 1 Gbps
    • Operating Temperature: -20 to 70°C
    • Power Supply: 24V DC, 3W power consumption
