GE IC697PWR710

Technical Specifications

  • Input Voltage:
    • AC: 90–264 VAC (47–63 Hz)
    • DC: 100–150 VDC
  • Output Voltage:
    • Nominal: 5.1 VDC
    • Range: 4.90–5.25 VDC
  • Power Capacity:
    • Maximum Input Power: 90 W (at full load)
    • Maximum Output Power: 56 W
    • Output Current: Up to 11 A

GE IC693MDL240G

  • nput Voltage: 0 - 132 VAC, with a nominal voltage of 120 VAC.
  • Input Current: 12 mA per channel at rated voltage.
  • Input Frequency: 47 - 63 Hz.
  • Number of Channels: 16.
  • Isolation: 1500 volts RMS between field side and logic side.
  • On - State Voltage: 74 - 132 VAC.
  • Off - State Voltage: 0 - 20 VAC.
  • On - Response Time: Maximum 30 ms.
  • Off - Response Time: Maximum 45 ms.

GE IC693MDL240E

  • Input Voltage: 0 - 132 VAC, with a nominal voltage of 120 VAC.
  • Input Current: 12 mA per channel.
  • Input Frequency: 47 - 63 Hz.
  • Number of Channels: 16.
  • Isolation: 1500 volts RMS between field side and logic side.
  • On - State Voltage: 74 - 132 VAC.
  • Off - State Voltage: 0 - 20 VAC.
  • On - Response Time: Maximum 30 ms.
  • Off - Response Time: Maximum 45 ms.

GE IC693374-FN

  • Processor: Embedded 586, with a speed of 133 MHz.
  • Memory: User memory is 240 KB configurable, and system memory is 512 KB. The memory type is RAM and Flash.
  • I/O Points: 2048 discrete fixed points (1024 input, 1024 output). The configurable register memory is 128 to 32,640 words, and the configurable analogue inputs and outputs are also 128 to 32,640 words each.
  • Communication Ports: It has 2 built - in Ethernet 10/100 Base - T/TX ports with auto - sensing, and an RJ - 45 connection. There are no built - in serial ports.
  • Power Requirements: Requires 7.4 watts from a 5 - volt DC supply.
  • Operating Temperature: 0 to 55 °C (32 to 131 °F).
  • Storage Temperature: - 40 °C to + 85 °C.
  • Certifications: UL 508, c - UL (Class I, Div II, A, B, C, D), CE mark.

GE IC693363-D

  • Processor: 32 - bit processor, with a main frequency of 200MHz.
  • Memory: Program memory capacity is 512KB, and data memory capacity is 256KB.
  • I/O Capacity: Supports up to 4096 discrete I/O points and 2048 analog I/O points.
  • Communication Interfaces: Built - in Ethernet, RS - 232, and RS - 485 interfaces.
  • Power Consumption: Requires 890 milliamps from a 5V DC power supply.
  • Operating Temperature: 0 to 60°C (32 to 140°F).

GE IC693360-BA

  • Processor: Not explicitly mentioned, but it is a 32 - bit - compatible processor.
  • Clock Speed: Not explicitly mentioned.
  • User Program Memory: 240 K bytes (configurable).
  • I/O Capacity: Supports up to 4096 discrete I/O points and 2048 analog I/O points (configurable).
  • Rack Support: Can support up to 8 racks.
  • Serial Ports: No built - in serial ports.
  • Power Supply: Requires 670 milliamps from a +5 VDC supply.
  • Memory Type: RAM and Flash.
  • Battery Life: With the original cache RAM component, the battery life was 6.5 years. The battery for the CPU is included in the CPU backplane box.

GE IC693352-OH

  • Processor Type: 80386ex
  • Clock Speed: 25 MHz
  • User Program Memory: Up to 240 Kbytes (for firmware version 9.0 and later)
  • Discrete Inputs: 2048
  • Discrete Outputs: 2048
  • Analog Inputs/Outputs: Configurable in increments of 128 words
  • Serial Ports: 3
  • Power Supply: 5V DC
  • Power Consumption: 890 milliamps load required from 5V DC power supply
  • Operating Temperature: 0°C to 60°C
  • Storage Temperature: - 40°C to 85°C

GE IC693351-KT

  • Processor Type: 80386ex
  • Clock Speed: 25 MHz
  • User Program Memory: 240 Kbytes (for firmware version 9.0 and later); 80 Kbytes for earlier firmware versions
  • Register Memory: Up to 32,640 words
  • Discrete Inputs: 2048
  • Discrete Outputs: 2048
  • Analog Inputs/Outputs: Up to 32,640 words (configurable)
  • Serial Ports: 3
  • Power Supply: 5V DC
  • Power Consumption: 890 milliamps load required from 5V DC power supply
  • Operating Temperature: 0°C to 60°C

GE Ic693351-ek

  • Processor Type: 80386ex
  • Clock Speed: 25 MHz
  • User Program Memory: 240 Kbytes (for firmware version 9.0 and later; 80 Kbytes for earlier firmware versions)
  • Register Memory: Up to 32,640 words
  • Discrete Inputs: 2048
  • Discrete Outputs: 2048
  • Analog Inputs: Up to 32,640 words (configurable)

GE IC693351-DG

  • Processor Type: 80386ex
  • Clock Speed: 25 MHz
  • User Program Memory: 240 Kbytes
  • Register Memory: Configurable from 128 to 32,640 words in 128 - word increments
  • Power Supply: 5V DC
  • Power Consumption: 890 milliamps load required from 5V DC power supply
  • Operating Temperature: 0°C to 60°C (32°F to 140°F)
  • Scan Rate: 0.22 ms per 1K of logic (Boolean contacts)
  • Serial Ports: 3 serial ports, supporting SNP slave and RTU slave

GE IC693350-DH

  • Processor Type: 80386ex
  • Clock Speed: 25 MHz
  • Memory: 32 KB of user - programmable memory with 19.9 K of register memory
  • I/O Ports: 8 analog inputs & 8 analog outputs
  • Communication Interface: RS - 485
  • Power Supply: DC 24V
  • Power Consumption: 670 milliamps load required from 5V DC power supply
  • Operating Temperature: 32°F to 140°F (0°C to 60°C)
  • Scan Rate: 0.22 ms typical scan rate per 1K of logic (Boolean contacts)

GE IC693331W

  • Processor Type: 80188
  • Clock Speed: 10 MHz
  • User Program Memory: 16 Kbytes
  • Register Memory: 4 Kbytes
  • Discrete Inputs: 512
  • Discrete Outputs: 512
  • Analog Inputs: 128 words
  • Analog Outputs: 64 words
  • Serial Port: 1, supporting SNP/SNP - X slave protocols
  • Scan Rate: 0.4 ms typical per 1 k of logic (Boolean contacts)
