GE IC694APU300 Processor Module

Technical Specifications

  • Brand: GE (General Electric)
  • Model: IC694APU300
  • Type: Processor module for PLC systems
  • Input/Output Channels:
    • Supports up to 8 analog input channels (configurable for voltage or current signals).
    • Voltage input range: 0-5V, 0-10V, ±5V, ±10V.
    • Current input range: 0-20mA, 4-20mA.
    • Resolution: 16-bit for high-precision data acquisition.

GE IC200PWR002 Power Supply Module

Technical Specifications

  • Input Voltage: 18-30 VDC (nominal 24 VDC)
  • Output Voltage: 5 VDC and 3.3 VDC
  • Output Current:
    • Total maximum output current: 1.5 A
    • 5 VDC output: Up to 1.0 A
    • 3.3 VDC output: Up to 0.25 A (when 5 VDC output is not fully loaded)
  • Power Rating: 11 W
  • Hold-up Time: 10 ms
  • Surge Current:
    • 20 A for 6 ms at 24 VDC
    • 25 A for 6 ms at 30 VDC

GE IC641SWP708B Touch Screen Module

Technical Specifications

  • Model: IC641SWP708B
  • Brand: GE (General Electric)
  • Application: PLC system touch screen module
  • Function: Human-machine interface (HMI) for monitoring and controlling PLC operations
  • Compatibility: Designed to work seamlessly with GE PLC systems
  • Power Supply: 24V DC (typical for industrial PLC modules)
  • Mounting: DIN rail mounting for compact installation in control cabinets
  • Operating Temperature: -20°C to 70°C (industrial-grade temperature range for harsh environments)
  • Humidity Tolerance: 5% to 95% non-condensing humidity

GE IC693MDL940F Redundancy Module

Technical Specifications

  • Module Type: Redundancy module for PLC systems.
  • Compatibility: Works with GE Series 90-30 PLCs, supporting seamless integration into existing control architectures.
  • Power Supply: 24V DC power input with reverse polarity protection.
  • Operating Temperature: -20°C to 70°C (industrial-grade temperature range).
  • Humidity Tolerance: 5% to 95% non-condensing humidity for reliable operation in harsh environments.
  • Isolation: Features electrical isolation between input/output sections and the bus system to prevent interference.
  • Mounting: DIN rail mounting for compact installation in control cabinets.

GE IC687BEM731F-AB Analog Input Module

Technical Specifications

  • Input Channels: Supports multiple analog input channels (specific channel count depends on configuration).
  • Signal Types: Accepts voltage signals (e.g., 0-10V, ±10V) and current signals (e.g., 4-20mA).
  • Accuracy: High-precision measurement with minimal error margin (exact value depends on calibration and configuration).
  • Isolation: Provides electrical isolation between input channels and the bus system to prevent interference.
  • Resolution: Typically offers 12-bit or higher resolution for accurate signal representation.
  • Sampling Rate: High-speed sampling to capture dynamic signal changes in real-time.

GE IC660ELB921H Communication Interface Module

Technical Specifications

  • Input/Output Configuration:
    • Supports four keyphasor input channels (configurable in paired or unpaired modes).
    • Provides four output channels (one per module).
  • Signal Compatibility:
    • Measures machine speed (not phase) via keyphasor signals.
    • Compatible with 24V DC power supply.
  • Isolation:
    • Input/output isolation rated at 1500V AC.
    • Channel-to-channel isolation rated at 500V AC.

GE IC600PB553BPDT Signal Conditioning Module

Technical Specifications

  • Input Signal Types: Supports voltage (±10V), current (4-20mA), and thermocouple/RTD signals.
  • Output Signal Types: Provides isolated voltage (±10V) or current (4-20mA) outputs.
  • Accuracy: ±0.1% of full-scale range for voltage/current signals.
  • Isolation Voltage: 2500V RMS between input, output, and power sections.
  • Bandwidth: Adjustable up to 10kHz for dynamic signal processing.
  • Operating Temperature: -20°C to +70°C (-4°F to +158°F).
  • Power Supply: 24V DC ±20%, with reverse polarity protection.
  • Dimensions: 120mm x 80mm x 40mm (L x W x H).

GE IS200DTAIH1ABB

Technical Specifications
  • Input Range: -10V to +10V, 4mA to 20mA, etc.
  • Input Impedance: ≥10MΩ
  • Output Signal: 4 - 20mA (one output can be configured for 0 - 200mA by reconfiguring jumpers)
  • Operating Temperature Range: -40°C to +85°C
  • Storage Temperature Range: -55°C to +125°C
  • Humidity: 5% to 95% (non - condensing)
  • Dimensions: 80mm x 45mm x 25mm
  • Weight: 150g

GE IS200ADIIH1AAA

Technical Specifications
  • Board Type: IS200
  • LED Indicators: 6
  • Time Delay: 200 μsec (required for the LAN control processor to write the drive's feedbacks into the IS bus controller before the start of the next frame)
  • Connectors: Connects to the DS200 LDCC drive control/LAN communications board through the LNPL ribbon cable and COM1 wire. It interfaces to the IS bus through two RJ45 connectors (P2 for TX/OUT and P3 for RX/IN).

GE IC800VMM10MBKS

Technical Specifications

  • Rated Output: 1000 watts
  • Rated Torque: 4.77 Nm
  • Maximum Torque: 14.32 Nm
  • Rated Speed: 2000 rpm
  • Maximum Speed: 3000 rpm
  • Rated Current: 5.6 amps
  • Maximum Current: 24.9 amps
  • Rotor Moment of Inertia: 9.14 kg·m² x 10⁻⁴

GE IC800VMA302-BB

Technical Specifications
  • Power Supply: Operates on a three - phase voltage of 220V AC, with a frequency of 50/60Hz ± 5%. The permissible voltage fluctuation range is 170 VAC to 225 VAC.
  • Output Current: The output short - circuit current is 107 A (peak), and the three - phase operation current leakage is 0.13 mA.
  • Electronic Gear Ratio: n/m, where n: 1 ~ 32767, m: 1 ~ 32767 (1/50 < n/m < 200).
  • Dimensions: Height 245 mm, width 110 mm, length 206 mm.
  • Operating Temperature: 0 to 55 °C. For operation above 55 °C, forced cooling is required. The storage temperature is - 22 °C to 65 °C, and condensation should be avoided.

GE IC800VMA302-BB

Technical Specifications
  • Power Supply: It operates on a 220V AC three - phase voltage, with a frequency of 50/60Hz ± 5%. The permissible voltage fluctuation range is 170 VAC to 225 VAC.
  • Output Current: The output short - circuit current is 107 A (peak), and the three - phase operation current leakage is 0.13 mA.
  • Electronic Gear Ratio: The electronic gear ratio is n/m, where n ranges from 1 to 32767, and m ranges from 1 to 32767 (1/50 < n/m < 200).
  • Dimensions: The height is 245 mm, the width is 110 mm, and the length is 206 mm.
  • Operating Temperature: The operating temperature should be between 0 °C and 55 °C. For temperatures above 55 °C, forced cooling is required. The storage temperature range is - 22 °C to 65 °C, and condensation must be avoided.
