Moog D664-4747 L05HRBW6NET2-E Servo Proportional Valve

  • Product Introduction: It is a product of the Moog D664 series servo proportional valves, which are pilot-operated proportional valves with integrated electronics and analog interfaces. The valve is designed for high-flow hydraulic control scenarios, with a two-stage or three-stage configuration. It has excellent dynamic performance and flow control accuracy, and can meet the control needs of large-scale hydraulic systems. The valve is widely used in various industrial fields due to its reliable performance and flexible configuration.

Moog D061-9321 J09HOAA4HN1 Servo Valve

  • Product Introduction: It is a member of the Moog D061/J061 series servo valves, which are high-pressure servo valves. The integrated control circuit of the valve adopts SMD technology and is powered by 24 VDC. It is designed for electro-hydraulic position, speed, pressure, or force control systems requiring high dynamic response, and can convert electrical signals into precise hydraulic actions to meet the control requirements of various complex systems.

Moog D663Z4711 L03HXAP6NEA2-K Servo Proportional Valve

  • Product Introduction: It is a high-quality hydraulic control valve belonging to the Moog D663 series servo proportional valves. It is designed to achieve precise and efficient control of hydraulic systems. With advanced technology and reliable performance, the valve can accurately control the flow in proportion to the input electrical signal, ensuring smooth and precise operation of the hydraulic system. Its compact design and easy installation make it an ideal choice for various hydraulic control occasions.

Moog D684Z4857G Pilot-Operated Proportional Valve

  • Product Introduction: It is a proportional valve of the Moog D68x series, which adopts pilot-operated hydraulic control and integrates electronic components and analog interfaces. The valve uses Mini DDV as the pilot, which has the advantages of fast response and high efficiency. It is designed for industrial applications requiring large flow and high-precision control, and can stably regulate the flow of the hydraulic system, ensuring the smooth operation of the equipment.

Moog D661-4203 Pilot-Operated Servo Valve

  • Product Introduction: As part of the Moog D661 series, it is a pilot-operated servo valve with integrated electronics and analog interfaces. The spool of the valve slides in the sleeve and is controlled by hydraulic pilot operation. The design ensures high precision, excellent static and dynamic performance, and is suitable for the most demanding application scenarios, providing high dynamic performance to meet the precise control needs of hydraulic systems.

Moog D663-Z4307K/P0 Servo Proportional Valve

  • Product Introduction: It belongs to the Moog D660 series servo proportional valves and is a pilot-operated proportional valve for analog signals. The valve can be configured as a two-stage or three-stage valve according to the dynamic performance requirements of the application. It has the characteristics of high rated flow, excellent dynamic response, and reliable operation, and can be applied to various electro-hydraulic control systems to achieve precise control of flow, position, speed, pressure, or force.

Moog D684Z4826 Pilot-Operated Proportional Valve

  • Product Introduction: It is a member of the Moog D68x series proportional valves, which are pilot-operated proportional valves integrating electronics and analog interfaces. The spool of this valve is directly installed in the valve housing and controlled by hydraulic pilot operation. It adopts Mini DDV as the pilot valve, which has excellent dynamic performance and high efficiency. The valve is designed for high-demand industrial applications, with high functional flexibility and excellent dynamic response, and can meet the precise control requirements of various complex hydraulic systems.

MOOG D682Z4805 Electro-Hydraulic Servo Valve

Technical Specifications

  • Nominal Flow Rate: The valve typically offers a nominal flow rate ranging from 10 to 60 liters per minute (l/min), depending on the specific model and operating conditions. This ensures sufficient hydraulic power for a wide range of applications.
  • Pressure Rating: It is designed to operate at pressures up to 350 bar (5,075 psi), allowing it to handle high-pressure hydraulic systems commonly found in heavy machinery and industrial equipment.
  • Input Signal: The valve accepts standard electrical input signals, such as ±10 mA or ±20 mA, for precise control of valve position and hydraulic output.
  • Hysteresis: It exhibits low hysteresis, typically less than 1%, ensuring minimal deviation between increasing and decreasing input signals and consistent performance.
  • Frequency Response: The valve has a high-frequency response, often exceeding 100 Hz, enabling rapid and accurate adjustments to changing load conditions.
  • Leakage: Internal leakage is minimized, usually less than 1% of the nominal flow rate, reducing energy losses and improving system efficiency.
  • Environmental Protection: It is built to withstand harsh environmental conditions, with options for corrosion-resistant materials and seals to prevent contamination and extend service life.

Moog D662Z766B Pilot-Operated Proportional Valve

  • Product Introduction: This product belongs to the Moog D662 series, which is a pilot-operated proportional valve. Similar to other products in the D66x series, it has integrated electronics and an analog interface. The valve adopts a pilot-operated structure, which can achieve higher flow rates and has a variety of fail-safe options, designed to meet the needs of industrial applications.

Moog D661-4594C G75KXAA5VSX2HA

  • Product Introduction: This is a high-performance proportional flow control servo valve belonging to the Moog D661 series. It has an ultra-large flow valve body flow channel design, and the pilot stage can be externally controlled and drained using ports X and Y. The valve adopts a fail-safe design, which ensures that the spool can still operate in cases such as short circuits, power failures, or oil source pressure loss, thus ensuring system reliability.

Moog D633-322B Direct-Driven Servo Valve

  • Product Introduction: This product is part of the Moog D633 series of direct-operated servo valves. It has the same basic design concept and structural characteristics as the Moog D633-342B. It integrates electronics and an analog interface, adopts a permanent magnet linear motor for direct drive, and has the advantages of high precision, high efficiency, and high reliability.

Moog D633-342B Direct-Driven Servo Valve

  • Product Introduction: It belongs to the Moog D633 series, which is a direct-operated servo valve with integrated electronics and an analog interface. The servo valve adopts a direct drive method with a permanent magnet linear motor, which directly drives the spool to move without the need for pilot oil. It is designed to meet the high-demand requirements of customers, with high functional flexibility, pressure-independent dynamic performance, high driving force, and low power consumption.
