GE IC660ELB921H Communication Interface Module

Technical Specifications

  • Input/Output Configuration:
    • Supports four keyphasor input channels (configurable in paired or unpaired modes).
    • Provides four output channels (one per module).
  • Signal Compatibility:
    • Measures machine speed (not phase) via keyphasor signals.
    • Compatible with 24V DC power supply.
  • Isolation:
    • Input/output isolation rated at 1500V AC.
    • Channel-to-channel isolation rated at 500V AC.

GE IC600PB553BPDT Signal Conditioning Module

Technical Specifications

  • Input Signal Types: Supports voltage (±10V), current (4-20mA), and thermocouple/RTD signals.
  • Output Signal Types: Provides isolated voltage (±10V) or current (4-20mA) outputs.
  • Accuracy: ±0.1% of full-scale range for voltage/current signals.
  • Isolation Voltage: 2500V RMS between input, output, and power sections.
  • Bandwidth: Adjustable up to 10kHz for dynamic signal processing.
  • Operating Temperature: -20°C to +70°C (-4°F to +158°F).
  • Power Supply: 24V DC ±20%, with reverse polarity protection.
  • Dimensions: 120mm x 80mm x 40mm (L x W x H).

GE IS200DTAIH1ABB

Technical Specifications
  • Input Range: -10V to +10V, 4mA to 20mA, etc.
  • Input Impedance: ≥10MΩ
  • Output Signal: 4 - 20mA (one output can be configured for 0 - 200mA by reconfiguring jumpers)
  • Operating Temperature Range: -40°C to +85°C
  • Storage Temperature Range: -55°C to +125°C
  • Humidity: 5% to 95% (non - condensing)
  • Dimensions: 80mm x 45mm x 25mm
  • Weight: 150g

GE IS200ADIIH1AAA

Technical Specifications
  • Board Type: IS200
  • LED Indicators: 6
  • Time Delay: 200 μsec (required for the LAN control processor to write the drive's feedbacks into the IS bus controller before the start of the next frame)
  • Connectors: Connects to the DS200 LDCC drive control/LAN communications board through the LNPL ribbon cable and COM1 wire. It interfaces to the IS bus through two RJ45 connectors (P2 for TX/OUT and P3 for RX/IN).

GE IC800VMM10MBKS

Technical Specifications

  • Rated Output: 1000 watts
  • Rated Torque: 4.77 Nm
  • Maximum Torque: 14.32 Nm
  • Rated Speed: 2000 rpm
  • Maximum Speed: 3000 rpm
  • Rated Current: 5.6 amps
  • Maximum Current: 24.9 amps
  • Rotor Moment of Inertia: 9.14 kg·m² x 10⁻⁴

GE IC800VMA302-BB

Technical Specifications
  • Power Supply: Operates on a three - phase voltage of 220V AC, with a frequency of 50/60Hz ± 5%. The permissible voltage fluctuation range is 170 VAC to 225 VAC.
  • Output Current: The output short - circuit current is 107 A (peak), and the three - phase operation current leakage is 0.13 mA.
  • Electronic Gear Ratio: n/m, where n: 1 ~ 32767, m: 1 ~ 32767 (1/50 < n/m < 200).
  • Dimensions: Height 245 mm, width 110 mm, length 206 mm.
  • Operating Temperature: 0 to 55 °C. For operation above 55 °C, forced cooling is required. The storage temperature is - 22 °C to 65 °C, and condensation should be avoided.

GE IC800VMA302-BB

Technical Specifications
  • Power Supply: It operates on a 220V AC three - phase voltage, with a frequency of 50/60Hz ± 5%. The permissible voltage fluctuation range is 170 VAC to 225 VAC.
  • Output Current: The output short - circuit current is 107 A (peak), and the three - phase operation current leakage is 0.13 mA.
  • Electronic Gear Ratio: The electronic gear ratio is n/m, where n ranges from 1 to 32767, and m ranges from 1 to 32767 (1/50 < n/m < 200).
  • Dimensions: The height is 245 mm, the width is 110 mm, and the length is 206 mm.
  • Operating Temperature: The operating temperature should be between 0 °C and 55 °C. For temperatures above 55 °C, forced cooling is required. The storage temperature range is - 22 °C to 65 °C, and condensation must be avoided.

GE IC800VMA202

Technical Specifications
  • Power Supply: Requires a three - phase voltage of 220V AC, 50/60Hz ± 5%. The permissible voltage fluctuation range is 170 VAC to 255 VAC.
  • Electronic Gear Ratio: n/m, where n: 1 ~ 32767, m: 1 ~ 32767 (1/50 < n/m < 200).
  • Cooling Method: Fan - cooled.
  • Dimensions: Height 245 mm, width 110 mm, length 206 mm. An additional 70 mm should be allowed for connected cables to prevent bending.
  • Operating Temperature: 0 to 55 °C. For operation above 55 °C, forced cooling is required.
  • Storage Temperature: - 20 °C to 65 °C.
  • Humidity: 0 to 90% non - condensing.

GE IC800S107RS1-DE

Technical Specifications

  • Power Supply: Usually, it may support a wide - range power input, such as 90 - 250 VAC, 1 or 3 - phase, 50 - 440 Hz.
  • Output Current: Similar models can provide 4.3 A continuous full - load current and 8.6 A peak full - load current for 3 - phase output at 90 - 250 VAC.
  • Operating Temperature: The operating temperature range is generally 0 - 40 °C.

GE IC800SSD107RS1-DC

Technical Specifications
  • Power Input: 90 - 250 VAC, 1 or 3 phase, 50 - 440 Hz, 1.6 kVA max cont.（Note: The power input specification is similar to that of the related IC800 series modules, and there may be slight differences in the actual product.）
  • Output Current: 4.3 A continuous full load, 8.6 A peak full load for 3 - phase output at 90 - 250 VAC, 0 - 1000 Hz.（Note: The output current specification is for reference only according to the similar model IC800SSD104RS1 - CC.）
  • Operating Temperature: 0 - 40 °C.

GE IC800SSD104RS1-DC

Technical Specifications
  • Power Input: 90 - 250 VAC, 1 or 3 phase, 50 - 440 Hz, 1.6 kVA max cont.
  • Output Current: 4.3 A continuous full load, 8.6 A peak full load for 3 - phase output at 90 - 250 VAC, 0 - 1000 Hz.
  • Operating Temperature: 0 - 40 °C.

GE IC755CSS15CDA-AG

Technical Specifications
  • Processor: Freescale i.MX 535 based on ARM Cortex A8, with a clock speed of 1 GHz.
  • Memory: 1 GB DDR3 SDRAM, 512 MB SLC NAND flash memory, 512 KB battery - backed SDRAM.
  • Display: 15 - inch projected capacitive multi - touch TFT LCD display, with a resolution of 1024 x 768 pixels.
  • Operating System: Windows Embedded Compact 7.
  • Communication Interfaces: Two Ethernet interfaces, one RS232 port, one RS485 port, and three USB interfaces (2x USB 2.0 Type - A, 1x USB 2.0 Mini Type - B).
  • Power Supply: 12/24 VDC.
  • Power Consumption: 30 watts.
  • Dimensions: 399 x 323 x 70 millimeters (15.7 x 12.7 x 2.7 inches).
  • Weight: Approximately 5 kg.
