GE IC693MDL742 Digital Output Module

Technical Specifications

  • Output Points: 16 digital outputs (grouped in two sets of 8 points each).
  • Output Type: Sourcing (positive logic), providing current from the module’s positive power bus to connected loads.
  • Voltage Range: 12–30V DC (compatible with both 12V and 24V DC systems).
  • Current per Point: 0.5A maximum per output point; 2A maximum per common (group).
  • Response Time:
    • On-time: ≤2ms
    • Off-time: ≤2ms
  • Surge Current: 4.78A for 10ms (during initial energization).

GE IC693MDL645 Digital Input Module

Technical Specifications

  • Input Points: 32 digital inputs (configurable in groups).
  • Input Type: Supports 24V DC positive/negative logic.
  • Voltage Range: 10–30V DC (nominal 24V DC).
  • Current Consumption: 15mA from backplane at 5V DC.
  • Response Time:
    • On: ≤0.2ms
    • Off: ≤1.0ms
  • Thermal Derating: Operates at 24/30V DC with reduced current capacity.
  • Mounting: DIN rail or panel mounting.
  • Compliance: UL, CUL, CE, Class I Division 2, ATEX Zone 2.
  • LED Indicators: Per-point status visualization for real-time monitoring.

GE IC200MDL740 Discrete Output Module

Technical Specifications

  • Output Points: 16 discrete points (1 group of 16).
  • Output Type: Positive logic (sourcing type).
  • Voltage Range: 10.2–30V DC (nominal 12/24V DC).
  • Current per Point: 0.5A (maximum).
  • Response Times:
    • On: 0.2ms (maximum).
    • Off: 1.0ms (maximum).
  • Power Consumption: 45mA from backplane.
  • LED Indicators: Per-point status visualization.
  • Thermal Derating: Supported at 24/30V DC.

GE IC693CBL305A Communication Cable

Technical Specifications

  • Brand: GE (General Electric)
  • Model: IC693CBL305A
  • Cable Type: Communication cable for PLC systems
  • Length: Varies based on configuration (common lengths include 1m, 2m, 5m, etc.)
  • Connector Type: D-subminiature (D-sub) or other industrial-grade connectors (specific type depends on configuration)
  • Voltage Rating: Typically supports low-voltage communication signals (e.g., 5V, 12V, 24V)
  • Current Rating: Designed for low-current signal transmission
  • Shielding: Features shielding to minimize electromagnetic interference (EMI) and ensure signal integrity

GE IC693PBS201 Power Module

Technical Specifications

  • Brand: GE (General Electric)
  • Model: IC693PBS201
  • Type: Power module for PLC systems
  • Output Type: Transistor-based output
  • Output Points: 16 points
  • Output Voltage: DC 5-24V
  • Output Current: Maximum 0.5A per point
  • Isolation Method: Optical isolation
  • Operating Temperature Range: -20°C to 60°C

GE IC200MDL742D Analog Output Module

Technical Specifications

  • Brand: GE (General Electric)
  • Model: IC200MDL742D
  • Type: Analog output module for PLC systems
  • Output Channels: Supports multiple analog output channels (specific channel count depends on configuration, typically ranging from 2 to 8 channels).
  • Output Signal Type: Voltage or current output (configurable based on application requirements).
  • Voltage Output Range: 0-5V, 0-10V, ±5V, ±10V (configurable).
  • Current Output Range: 0-20mA, 4-20mA (configurable).

GE IC200ALG325H Logic Module

Technical Specifications

  • Brand: GE (General Electric)
  • Model: IC200ALG325H
  • Type: Logic module for PLC systems
  • Input/Output Channels:
    • Supports up to 8 analog input channels (configurable for voltage or current signals).
    • Voltage input range: 0-5V, 0-10V, ±5V, ±10V.
    • Current input range: 0-20mA, 4-20mA.
    • Resolution: 16-bit for high-precision data acquisition.

GE IC694APU300 Processor Module

Technical Specifications

  • Brand: GE (General Electric)
  • Model: IC694APU300
  • Type: Processor module for PLC systems
  • Input/Output Channels:
    • Supports up to 8 analog input channels (configurable for voltage or current signals).
    • Voltage input range: 0-5V, 0-10V, ±5V, ±10V.
    • Current input range: 0-20mA, 4-20mA.
    • Resolution: 16-bit for high-precision data acquisition.

GE IC200PWR002 Power Supply Module

Technical Specifications

  • Input Voltage: 18-30 VDC (nominal 24 VDC)
  • Output Voltage: 5 VDC and 3.3 VDC
  • Output Current:
    • Total maximum output current: 1.5 A
    • 5 VDC output: Up to 1.0 A
    • 3.3 VDC output: Up to 0.25 A (when 5 VDC output is not fully loaded)
  • Power Rating: 11 W
  • Hold-up Time: 10 ms
  • Surge Current:
    • 20 A for 6 ms at 24 VDC
    • 25 A for 6 ms at 30 VDC

GE IC641SWP708B Touch Screen Module

Technical Specifications

  • Model: IC641SWP708B
  • Brand: GE (General Electric)
  • Application: PLC system touch screen module
  • Function: Human-machine interface (HMI) for monitoring and controlling PLC operations
  • Compatibility: Designed to work seamlessly with GE PLC systems
  • Power Supply: 24V DC (typical for industrial PLC modules)
  • Mounting: DIN rail mounting for compact installation in control cabinets
  • Operating Temperature: -20°C to 70°C (industrial-grade temperature range for harsh environments)
  • Humidity Tolerance: 5% to 95% non-condensing humidity

GE IC693MDL940F Redundancy Module

Technical Specifications

  • Module Type: Redundancy module for PLC systems.
  • Compatibility: Works with GE Series 90-30 PLCs, supporting seamless integration into existing control architectures.
  • Power Supply: 24V DC power input with reverse polarity protection.
  • Operating Temperature: -20°C to 70°C (industrial-grade temperature range).
  • Humidity Tolerance: 5% to 95% non-condensing humidity for reliable operation in harsh environments.
  • Isolation: Features electrical isolation between input/output sections and the bus system to prevent interference.
  • Mounting: DIN rail mounting for compact installation in control cabinets.

GE IC687BEM731F-AB Analog Input Module

Technical Specifications

  • Input Channels: Supports multiple analog input channels (specific channel count depends on configuration).
  • Signal Types: Accepts voltage signals (e.g., 0-10V, ±10V) and current signals (e.g., 4-20mA).
  • Accuracy: High-precision measurement with minimal error margin (exact value depends on calibration and configuration).
  • Isolation: Provides electrical isolation between input channels and the bus system to prevent interference.
  • Resolution: Typically offers 12-bit or higher resolution for accurate signal representation.
  • Sampling Rate: High-speed sampling to capture dynamic signal changes in real-time.
