GE IC693MDL753F

Technical Specifications

  • Output Type: Discrete digital output (solid-state, positive logic)
  • Number of Output Points: 32 channels, divided into 4 isolated groups (8 points per group)
  • Output Voltage Range: 10.2 VDC to 28.8 VDC
  • Output Current: 0.5 A maximum per output point; 4 A maximum per isolated group
  • Isolation: 1,500 VAC (rms) between field side and logic side; 250 VAC (rms) between adjacent output groups
  • Response Time: 0.5 ms maximum (on-time and off-time)
  • Power Consumption: 260 mA maximum from the Series 90-30 backplane (5 VDC bus); power draw includes 13 mA base current + 3 mA per active output point + 4.7 mA per active LED
  • Operating Temperature Range: -10°C to +55°C

GE IC693MDL645C

  • Input Voltage: 24 VDC, with an input voltage range of 0 - 30 VDC.
  • Number of Input Points: 16.
  • Input Current Rating: 7 mA at rated voltage.
  • Logic Type: Supports both positive and negative logic.
  • Isolation: 1500 V isolation between the field side and logic side.
  • On - State Voltage: 11.5 - 30 VDC.
  • Off - State Voltage: 0 - 5 VDC.
  • On and Off Response Time: 7 ms for both on and off.
  • Power Consumption: 80 mA from the 5 V bus on the backplane (all inputs on), 125 mA from the isolated 24 V backplane bus or user - supplied power.
  • Dimensions: Approximately 11.2 cm x 4.5 cm x 5.7 cm.
  • Weight: About 0.5 kg.

GE IC200MDL740C

  • Number of Input Channels: 8 differential analog input channels
  • Input Signal Types: Supports 4-20 mA DC (current) and 0-10 V DC (voltage) signals
  • Input Range Accuracy:
    • For 4-20 mA: ±0.1% of full scale (FS)
    • For 0-10 V DC: ±0.1% of full scale (FS)
  • Resolution: 16-bit ADC (Analog-to-Digital Converter)
  • Sampling Rate: 10 samples per second (SPS) per channel
  • Isolation: 250 V AC continuous isolation between input channels and backplane; 1500 V AC isolation for 1 minute (dielectric strength)
  • Operating Temperature Range: -20°C to 60°C
  • Storage Temperature Range: -40°C to 85°C

GE IC200MDL650D

  • Number of Output Points: 32.
  • Output Type: Relay output.
  • Rated Voltage: Typically 24VDC.
  • Operating Temperature Range: -20°C to 60°C.
  • Storage Temperature Range: -40°C to 85°C.
  • Relative Humidity: 5% to 95% (non - condensing).
  • Protection Level: IP67.
  • Size: 146.1mm x 82.5mm x 23.9mm.
  • Weight: Approximately 340g.

GE IC200MDL940G

  • Output Voltage: 0 - 125VDC (nominal values of 5V, 24V, 125VDC); 0 - 265VAC (47 - 63Hz), with nominal values of 120VAC and 240VAC.
  • Load Current per Point: 2.0A for 5 - 265VAC; 2.0A for 5 - 30VDC; 0.2A for 31 - 125VDC. The minimum load current per point is 10mA.
  • Response Time: The on - time and off - time are both 10ms.
  • Isolation: Input to logic isolation is 250VAC continuous and 1500VAC for 1 minute; group - to - group isolation is 250VAC continuous and 1500VAC for 1 minute. Each output is individually isolated.
  • Power Consumption: The maximum 5V backplane current consumption is 490mA.
  • Dimensions: 5 cm x 11 cm x 6.68 cm (excluding the height of the carrier or the mating connectors).

GE IC694MDL940A

  • Rated Voltage: 24VDC.
  • Operating Voltage Range: 5 - 30VDC, 5 - 250VAC.
  • Maximum Load per Output: 2A.
  • Minimum Load per Output: 10mA.
  • Maximum Inrush Current: 5A.
  • Response Time: On - 15ms, Off - 15ms.
  • Power Consumption: 7mA from 5V bus, 135mA from 24V relay.
  • Frequency: 50/60Hz.
  • Number of Outputs: 16.
  • Isolation: The module has 1500V AC isolation between field and backplane, and 250V AC continuous isolation between channels.

GE IC200PBI001-BE

  • Interface Type: PROFIBUS DP.
  • Communication Rate: Supports various communication rates including 960 kbps, 1.5 Mbps, 3 Mbps, and 6 Mbps.
  • Node Address: Ranges from 0 to 127.
  • Operating Temperature Range: -25°C to +60°C (-13°F to +140°F).
  • Protection Level: IP67.
  • Dimensions: 80 mm x 30 mm x 25 mm (3.15 inches x 1.18 inches x 0.98 inches).

GE IC200MDL650E

  • Output Points: 32 output points.
  • Output Type: Relay output.
  • Rated Voltage: The output can support a wide range of voltages, typically compatible with both AC and DC voltages. For example, it can handle voltages such as 5 to 265VAC and 5 to 30VDC.
  • Rated Current: Each point has a rated current. For instance, at 5 to 265VAC, the rated current is 2.0A for resistive loads, and at 5 to 30VDC, the rated current is also 2.0A for resistive loads.
  • Response Time: The module has a relatively fast response time, which allows for quick switching of the output states. The on - to - off and off - to - on response times are typically short, enabling timely control of the connected devices.
  • Isolation Voltage: It has isolation between channels, with a rated isolation voltage of 250VAC (continuous) and 1500VAC (for 1 minute) between groups.

GE IC200CHS003H

  • Communication Protocol: Supports RS-485 serial communication (half-duplex mode) as the primary interface
  • Data Transfer Rate: Adjustable baud rates including 1200 bps, 2400 bps, 4800 bps, 9600 bps, 19200 bps, 38400 bps, 57600 bps, and 115200 bps
  • Communication Distance: Up to 1200 meters (4000 feet) at lower baud rates (e.g., 1200 bps) when using shielded twisted-pair (STP) cables
  • Number of Nodes: Supports up to 32 devices on a single RS-485 network (compliant with EIA/TIA-485 standards)
  • Interface Type: Removable terminal block (3-pin) for RS-485 connections (A, B, GND)
  • Power Supply: Derived from the VersaMax Micro base unit; operates on 5 VDC (backplane power), with a maximum power consumption of 0.5 W

GE IC694MDL754

  • Input Type: Digital input (dry contact or voltage-based signals)
  • Number of Input Points: 16 isolated input channels, configured for redundant operation
  • Input Voltage Range: 24 VDC (typical); supports 19.2 VDC to 30 VDC (operating range)
  • Input Current: 7 mA maximum per channel at 24 VDC
  • Isolation: Channel-to-channel isolation (500 VAC RMS for 1 minute); module-to-backplane isolation (1500 VAC RMS for 1 minute)
  • Response Time: 1 ms maximum for input signal detection
  • Redundancy Support: Compatible with RX3i system-level redundancy (e.g., dual CPU, redundant backplane) to ensure no data loss during module or component failures
  • Operating Temperature Range: -25°C to +60°C
  • Storage Temperature Range: -40°C to +85°C
  • Relative Humidity: 5% to 95% (non-condensing, per IEC 61131-2)
  • Certifications: UL 508, CSA C22.2 No. 14, CE (EN 61010-1, EN 61326-1), ATEX (for hazardous locations, where applicable)
  • Power Consumption: 1.2 W maximum (from RX3i backplane, 5 VDC)

GE IC695CMM002

  • Communication Ports: It has 2 isolated serial ports, which can be configured as RS - 232 or RS - 485/422.
  • Protocol Support: Supports multiple protocols, including Modbus RTU, DF1, ASCII, Modbus Master/Slave, DNP3 Master/Slave, CCM Slave, and Serial I/O.
  • Baud Rate: The baud rate is configurable, up to 115200 bps.
  • Data Bits: Usually 7 or 8 bits, configurable.
  • Stop Bits: 1 or 2 bits, configurable.
  • Parity Bits: None, odd parity, or even parity.
  • Power Requirements: Powered by the PLC main unit.
  • Operating Temperature Range: - 25°C to + 60°C.
  • Storage Temperature Range: - 40°C to + 85°C.
  • Relative Humidity: 5% to 95% (non - condensing).
  • Certifications: CE, UL, CSA, etc.

GE IC200CHS006E

  • Compatibility: Designed to work with VersaMax communication modules such as IC200BEM002 (Profibus - DP network slave module), IC200BEM103 (DeviceNet network control module).
  • Dimensions: 66.8 mm x 133.4 mm x 70 mm (excluding the height of the DIN rail).
  • Operating Temperature: 0 to 60 °C.
  • Storage Temperature: - 40 to 85 °C.
  • Network Data Rate: For modules like IC200BEM002 connected to it, the network data rate can range from 9.6 Kbaud to 12 Mbaud.
  • Power Consumption: For the connected communication modules, the power consumption is up to 460 mA at 5 V output and up to 5 mA at 3.3 V output.
