ABB 3BHB006457R0001

The ABB 3BHB006457R0001 is an IGCT (Integrated Gate-Commutated Thyristor) controller module designed for high-power industrial applications. It features a reverse voltage rating exceeding 4500 V and handles forward currents ranging from 250 to 5000 A. The module operates with a switching speed under 100 μs, using ±15 V trigger pulses to achieve turn-on/off times between 300 and 500 ns. These specifications enable efficient control in high-voltage, high-current environments, making it suitable for applications such as high-voltage direct current (HVDC) transmission, large-scale industrial drives, and renewable energy systems like wind turbine converters.

ABB 3HNA006146-001

Technical Specifications:

  1. Dimensions and Weight: The board measures 27 cm x 20.5 cm x 2 cm and weighs approximately 0.92 kg.
  2. Material and Construction: It is built with durable materials to withstand harsh industrial environments.
  3. Protection Rating: Designed to meet industrial safety standards, ensuring protection against dust and accidental contact.
  4. Compatibility: Specifically designed for use with ABB robot control cabinets, such as the IRC5P, and is engineered to integrate seamlessly with ABB’s automation systems.

ABB DSAI146 3BSE007949R1

Technical Specifications:

  1. Input/Output Voltage: Operates with an input voltage of 24V DC and an output voltage of 24V DC. The input current is 250mA, and the output current is 1A.
  2. Dimensions and Weight: Measures 137mm x 62mm x 116mm and weighs approximately 0.3kg.
  3. Protection Rating: Features an IP20 protection rating, ensuring safety in standard industrial environments.
  4. Operating Temperature Range: Functions reliably between -40°C and +70°C, making it suitable for various industrial conditions.
  5. Power Consumption: Low power design with maximum energy consumption of 4.6W.
  6. Interface Protocols: Supports multiple communication protocols, including PROFIBUS-DP, Modbus RTU, and Ethernet, ensuring seamless integration with other industrial devices.

ABB 3BSE007949R1

Technical Specifications:

  1. Input/Output Voltage: The module operates with an input voltage of 24V DC and an output voltage of 24V DC, with an input current of 250mA and an output current of 1A.
  2. Dimensions and Weight: It measures 137mm x 62mm x 116mm and weighs approximately 0.3kg.
  3. Protection Rating: The device has an IP20 protection rating, with optional enhancements for harsh environments.
  4. Temperature Range: It operates effectively in a wide temperature range, from -40°C to +70°C, making it suitable for diverse industrial conditions.
  5. Communication Protocols: Supports multiple communication protocols, including Profibus DP, Modbus RTU, and Ethernet, ensuring compatibility with various automation systems.

ABB DSAI146

Technical Specifications:

  1. Input Channels: Supports 16 analog input channels, configurable for voltage (±10V) or current (4-20mA) signals.
  2. Resolution: High resolution of 16 bits, ensuring precise data acquisition.
  3. Sampling Frequency: Capable of high-speed sampling (up to X kHz, depending on the specific model), meeting the demands of rapid response applications.
  4. Isolation Design: Features electrical isolation between channels and between channels and the system, enhancing anti-interference capabilities and suitability for harsh industrial environments.

ABB 1MRK002122-ABR02

Technical Specifications:

  1. Rated Voltage: 24V DC
  2. Rated Current: 10A
  3. Operating Temperature: -20°C to 60°C
  4. Communication Protocols: Ethernet and Modbus
  5. Dimensions: 100mm × 200mm × 40mm
  6. Weight: 1.5 kg

ABB 3BDH000730R1

Technical Specifications:

  1. Type: The device is a control and protection module for medium voltage switchgear.
  2. Rated Voltage: The device is designed for medium voltage levels, typically ranging from 1 to 36 kV, but the exact voltage rating for this specific model is not explicitly stated in the available sources.
  3. Operating Voltage: The device operates with a control voltage of 24 V DC or 115/230 V AC, depending on the configuration.
  4. Protection Functions: It provides various protection functions such as overcurrent, short circuit, and earth fault protection.
  5. Communication: The device supports communication via digital interfaces like Ethernet (Modbus TCP/IP) and serial communication (RS-485), enabling integration into SCADA systems and remote monitoring.
  6. Enclosure: The device is housed in a compact, flame-retardant plastic enclosure with a front-mounted display and control panel.
  7. Certifications: It meets international standards for safety and performance, such as IEC 61850 for substation automation.

ABB PPC902AE101 3BHE010751R0101

Technical Specifications

  • Model: PPC902AE101 3BHE010751R0101
  • Type: PLC Module
  • Processor: Dual-core ARM Cortex-A9
  • Memory: 2 GB RAM, 8 GB Flash
  • Input/Output Configuration: Provides multiple digital and analog input/output channels

ABB 3BHE010751R0101

Technical Specifications

  • Power Supply: Operates on 24 V DC ±15% with a maximum power consumption of ≤6 W during operation.
  • Input/Output (I/O) Configuration: Features 32 digital I/O channels (32 inputs and 32 outputs) supporting 24 V DC signals. Digital input voltage ranges from 0–30 V DC, and digital output voltage from 0–30 V DC. Digital input current is ≤7 mA, and digital output current is ≤500 mA. Response time for both inputs and outputs is ≤1 ms.
  • High-Speed Counter Input: Includes 4 channels with a maximum input frequency of 100 kHz.
  • Communication Interfaces: Equipped with an RS485 serial interface supporting the Modbus RTU protocol.
  • Environmental Ratings: Operational temperature ranges from -25°C to +70°C; storage temperature from -40°C to +85°C. The enclosure has an IP20 rating for protection against dust and solid particles.
  • Physical Design: Dimensions are 130 mm × 35 mm × 130 mm (height × width × depth), with a weight of approximately 0.3 kg.

ABB PPC902AE101

Technical Specifications

  • Power Supply: Operates on 24 V DC ±15% with a power consumption of ≤6 W during operation.
  • Input/Output (I/O) Configuration: Features 32 digital I/O channels (32 inputs and 32 outputs) supporting 24 V DC signals. Digital input voltage ranges from 0–30 V DC, and digital output voltage from 0–30 V DC. Digital input current is ≤7 mA, and digital output current is ≤500 mA. Response time for both inputs and outputs is ≤1 ms.
  • High-Speed Counter Input: Includes 4 channels with a maximum input frequency of 100 kHz.
  • Communication Interfaces: Equipped with an RS485 serial interface supporting the Modbus RTU protocol.
  • Environmental Ratings: Operational temperature ranges from -25°C to +70°C; storage temperature from -40°C to +85°C. The enclosure has an IP20 rating for protection against dust and solid particles.
  • Physical Design: Dimensions are 130 mm × 35 mm × 130 mm (height × width × depth), with a weight of approximately 0.3 kg.

ABB 1KHL015107R0001

Technical Specifications

  • Power Supply: 24 V DC ±15% with power consumption ≤2 W during operation.
  • Processor & Memory: High-performance microprocessor supporting real-time control algorithms, with configurable memory up to 512 MB RAM and 8 MB Flash for program storage.
  • Communication Interfaces: Supports Ethernet, RS-232, RS-485, PROFIBUS DP (12 Mbps), and CANopen. Features 10/100/1000 Base-T Ethernet for integration with PLCs, SCADA systems, or HMIs.
  • Environmental Ratings: Operating temperature -20°C to +60°C; storage temperature -40°C to +85°C. IP20-rated enclosure for dust and solid particle protection.
  • Physical Design: Dimensions 82 mm × 30 mm × 23 mm (width × height × depth); weight approximately 0.35 kg.

ABB CM30/2DMS0E0/STD

Technical Specifications

  • Power Supply:
    • Voltage range: 90–264 V AC (50/60 Hz) or 24 V DC ±15%.
    • Power consumption: ≤2 W in standby, ≤5 W during full operation.
