GE VMIVME-7751-76003

Technical Specifications

Core Architecture

  • Processor:
    • Intel Pentium III processor at 1.26 GHz minimum, with 512 KB L2 cache.
    • 32-bit addressing and 64-bit data bus support.
  • Memory:
    • 512 MB PC133 SDRAM (expandable via SODIMM slots).
    • 32 KB battery-backed SRAM for critical data retention.
  • Storage:
    • 1 GB IDE CompactFlash for boot/OS storage.
  • Bus Standard:
    • VME64x/VME320 compliant with A16/A24/A32/D32 addressing and BLT32/BLT64 block transfers.

GE VME7807RC

  1. Core Architecture:
    • Processor: Intel Pentium M (1.1 GHz, 1.4 GHz, or 1.8 GHz variants) with up to 2 MB L2 cache .
    • Memory: 1.5 GB DDR SDRAM (expandable), 32 KB battery-backed SRAM for critical data retention .
    • Storage: Up to 2 GB bootable CompactFlash; supports SATA drives .
    • Bus Standard: VME64x/VME320 with A16/A24/A32/D32 addressing and BLT32/BLT64 block transfers .

GE VMIVME-7750-74

Comprehensive Technical Specifications of GE VMIVME-7750-74 Series

1. Core Architecture

  • Processor:
    • PowerPC 7447A at 1.267 GHz (aligned with Freescale PowerPC architecture) .
    • FPGA Coprocessor: Xilinx Virtex-5 SX95T for hardware-accelerated signal processing .
  • Memory:
    • 512 MB DDR2 SDRAM (onboard), expandable to 4 GB .
    • 256 MB Flash for firmware and critical data storage .
  • Data Bus:
    • VME64x backplane interface with A16/A24/A32/D32 addressing modes .
    • Support for BLT32/BLT64 block transfers.

GE VMIVME-7805

Technical Specifications of GE VMIVME-7805

  1. Core Architecture:
    • Processor: Intel Pentium 4 Processor-M (NetBurst microarchitecture) at 2.2 GHz, 478-pin Micro-FCPGA packaging .
    • Chipset: Intel 852GM with 400 MHz front-side bus .
    • Memory: Up to 1 GB PC2100 DDR SDRAM .
    • Graphics: Integrated SVGA controller with 4 MB DRAM display cache; supports resolutions up to 1,600 × 1,200 pixels .

GE PCIE-5565PIORC-100000

Technical Specifications

  • Interface: PCI Express (PCIe) x3.
  • Memory: 128 MByte onboard SDRAM.
  • Data Transfer Rates:
    • Minimum: 43 MB/s (4-byte packets).
    • Peak: 170 MB/s (64-byte packets).
    • Serial Baud Rate: 2.12 Gbaud.
  • Fiber Optic Support:
    • Multimode Range: 300 meters.
    • Single-Mode Range: 10 kilometers.
    • Network Capacity: Supports 256 nodes.
    • Operating Temperature:
      • Standard: 0°C to +65°C.
      • Industrial: -40°C to +85°C.
    • Cooling: Passive (fanless).
    • Compliance: RoHS, VCCI Class A, CISPR 22 EMC.

GE VMIPC4-7301

1. Technical Specifications

  • Form Factor: CompactPCI (cPCI) compatible module, designed for industrial backplane integration .
  • Processor Architecture: Intel x86-based processor (exact model unspecified, but aligned with GE's embedded computing platforms) .
  • Memory:
    • Supports onboard SDRAM (capacity not explicitly stated in evidence; comparable GE cPCI modules typically range from 64 MB to 1 GB) .
  • Interfaces:
    • Network: Integrated Fast Ethernet (10/100 Mbps) controller for industrial communication .
    • Expansion: Likely includes PCI Mezzanine Card (PMC) sites for I/O customization .
  • Operating Temperature: Industrial-grade range (0°C to +55°C inferred from similar VMIVME modules) .
  • Compliance: RoHS (Restriction of Hazardous Substances) certified .

GE VMIVME-7698

1. Technical Specifications

  • Processor:
    • Intel Celeron socket 370 processor (366 MHz PPG model) .
    • Supports 32-bit addressing and 64-bit data bus .
  • Memory:
    • SDRAM: 64 MB onboard (expandable up to 256 MB via 144-pin SODIMM) .
    • Flash Storage: 64 MB CompactFlash (optional) .
  • Graphics:
    • 64-bit Intel AGP SVGA controller with 2 MB SGRAM .
    • Supports resolutions up to 1,280 × 1,024 pixels (256 colors) .

GE VMIVME-5532S

1. Technical Specifications

  • Form Factor: 6U VMEbus module, compliant with VME64x standards .
  • Operating Temperature: Industrial-grade range, likely 0°C to 55°C (inferred from VMIVME-2532A ).
  • Power Requirements:
    • Input Voltage: +5VDC ±5% .
    • Power Consumption: Approximately 30W (based on VMIVME-2532A ).
  • Interfaces:
    • Primary Bus: VMEbus for backplane integration .
    • Additional Ports: Likely includes Gigabit Ethernet or PCI Express (inferred from VMIVME-2532A ).
  • Memory: Not explicitly stated for 5532S, but comparable VMIVME-5565 models support 94 MB to 1.1 GB SDRAM .

GE CPCI-5565PIORC-210000

1. Technical Specifications

  • Memory Capacity: 256 MByte SDRAM .
  • Form Factor: CompactPCI (CPCI), compliant with PICMG 2.0 standards .
  • Transmission Mode: Multimode fiber optic .
  • Transmission Distance: Up to 300 meters .
  • Data Transfer Rate:
    • Peak: 174 MB/s (for 64-byte packets) .
    • Minimum: 43 MB/s (for 4-byte packets) .
    • Serial Baud Rate: 2.12 Gbaud .

GE PMC-5565PIORC-210000

1. Technical Specifications

  • Memory Capacity: 256 MByte SDRAM .
  • Interface Type: PMC (PCI Mezzanine Card) .
  • Transmission Mode: Multimode fiber optic .
  • Transmission Distance: Up to 300 meters .
  • Data Transfer Rate:
    • 43 MB/s (for 4-byte packets) to 174 MB/s (for 64-byte packets) .
    • Serial baud rate: 2.12 Gbaud .
  • Network Scalability: Supports up to 256 nodes .
  • Compliance: RoHS (Restriction of Hazardous Substances) certified .
  • Error Handling: Includes error detection and redundant transfer mode for reliability .

GE VMIVME-7751

GE VMIVME-7751 is a VME single-board computer based on the Intel® Pentium® III processor, widely used in industrial control, aerospace, defense, and scientific research fields. It offers high performance, reliability, and flexibility with various I/O interfaces and expansion slots.

GE 332-006015-000

GE 332-006015-000 is a VMEbus processor card, which is part of the GE Fanuc product line. This type of card is used in industrial control systems and is designed to provide high-performance computing capabilities. It supports the VMEbus standard, which allows for compatibility with a wide range of VME-based systems .
