Kollmorgen CE0326012
-
Product Name: SERVOSTAR S300 / CE Series Enhanced Servo Drive
-
Introduction: Compact digital servo amplifier, 3 A class, extended I/O and motion-task firmware (“12” suffix denotes expanded config).
Kollmorgen
You are here:
Kollmorgen AKD-P00306-NBER
-
Product Name: AKD Series Low-Voltage Servo Drive
-
Introduction: Ethernet-based pulse-width modulated servo drive, 120/240 VAC class, 3 A rating, NBER = no regen resistor / Ethernet IP / basic indexing / resolver-less SFD capable.
Kollmorgen CH043A-13-3105
-
Product Name: Cartridge DDR (Direct Drive Rotary) Motor, high-dissipation version
-
Introduction: Modular permanent-magnet synchronous torque motor for direct-drive rotary axes; eliminates gearbox, coupling and bearing stack. CH prefix denotes enhanced heat dissipation variant.
Kollmorgen B-206-B-24
-
Product Name: B-Series Permanent Magnet DC Servo Motor
-
Introduction: Legacy brushed DC servo motor, 2-inch frame, 6-stack, 24 V winding.
-
Specifications:
-
Frame B approx 50 mm diameter
-
Kollmorgen AKD-B00606-NBA
-
Product Name: AKD Series Servo Drive, 120/240 VAC, 6 A, Base Version, No Bus
-
Introduction: Low-voltage AKD drive, 2000 W continuous, base firmware, analog command control.
-
Specifications:
-
Supply 85–265 VAC 1/3-phase
-
Kollmorgen AKM43G-EKCNR-01
-
Product Name: AKM4 Series Brushless Servo Motor, size 43, stack G
-
Introduction: AKM43 frame with G winding, 16-bit resolver, keyed sealed shaft, IP65.
-
Specifications:
-
84×84 mm IEC flange
-
Kollmorgen AKM51L-HCGNC-00
-
Product Name: AKM5 Series Brushless Servo Motor, size 51, stack L
-
Introduction: Mid-frame AKM motor, high-energy winding, resolver feedback, keyed shaft, no brake, IP65.
-
Specifications:
-
118 mm class flange, stack L
-
Kollmorgen PRD-LC30030Z-57
-
Product Name: SERVOSTAR CD Mains Reactor / EMC Filter Module
-
Introduction: Line reactor or LC filter accessory for SERVOSTAR CD drives to reduce harmonics and meet EMC.
-
Specifications:
-
Rated current up to 80 A, leakage 35 mA
-
Kollmorgen AKD-P00307-NBCC-I000
-
Product Name: AKD Series Servo Drive, 240/480 VAC, 3 A, CANopen, Indexer
-
Introduction: AKD digital servo drive with internal regen resistor, motion indexer, CANopen interface.
-
Specifications:
-
Supply 187–528 VAC 3-phase
-
Kollmorgen CR10704
-
Product Name: SERVOSTAR CD Amplifier Module (ASIC current loop, 4 A class)
-
Introduction: SERVOSTAR CD variant with ASIC-controlled current loop, resolver/encoder capable.
-
Specifications:
-
Continuous 4.0 A, peak 8.0 A
-
Kollmorgen AKM43B-ANCNR-00
-
Product Name: AKM4 Series Brushless Servo Motor, size 43, stack B
-
Introduction: Standard AKM synchronous servo motor, resolver feedback, smooth shaft, no brake, IP65.
-
Specifications:
-
84×84 mm flange, stack B
-
Kollmorgen CR10551
-
Product Name: SERVOSTAR CD Servo Amplifier (4 A class)
-
Introduction: Digital PWM brushless servo drive from the SERVOSTAR CD family with resolver/encoder support.
-
Specifications:
-
Input 115/230 VAC auto-select single/three-phase
-
