Model Series: PRD Series (Precision Rotary Devices) Product Introduction: The PRD-B040ASIB-6 is a sin/cos resolver from the PRD product family with ASI (Actuator Sensor Interface) output compatibility. The "B040" identifies the specific resolver model variant, "ASI" indicates the output interface type, "B" denotes the electrical configuration revision, and "6" is the firmware/hardware revision level.
Model Series: PRD Series (Precision Rotary Devices) Product Introduction: The PRD-0019000z-0 is a high-resolution sin/cos resolver from the PRD product family. Resolvers provide absolute angular position feedback without the need for a battery or multi-turn counter. The "0019000" indicates 19-bit single-turn resolution (524,288 counts per revolution). The "z" suffix denotes a specific electrical output configuration, and "0" indicates standard factory configuration.
Model Series: SM56 Series (Ironless Linear Motors) Product Introduction: The 6SM-56-L-3000 is an ironless (coreless) linear servo motor from the SM56 product family. The "L" designation confirms linear configuration, and "3000" indicates a 3,000 mm (3 meter) stroke length. Ironless construction eliminates cogging force and eddy current losses, enabling ultra-smooth motion at very low speeds.
Model Series: S600 Series AC Servo Motors Product Introduction: The S61401-560 is a brushless AC servo motor from the S600 product family, designed for high-dynamic motion control applications. It features a laminated steel stator with concentrated windings and a high-energy NdFeB permanent magnet rotor. The "560" suffix denotes a specific winding/feedback configuration.
Model Series: S200 Series Digital Servo Amplifiers Product Introduction: The SR20200-000000 is a 2-axis digital servo drive from the S200 product family. It provides sinusoidal commutation control for brushless servo motors with integrated current regulation, velocity loop, and position loop capabilities. The "000000" suffix indicates a standard configuration with no optional modules installed.
Model Series: QT Series (Frameless DC Torque Motors) Product Introduction: The QT-4702-A is a frameless brushless DC torque motor designed for direct-drive applications requiring high torque density and zero cogging torque. It integrates seamlessly into customer-supplied mechanical structures, eliminating the need for couplings, gearboxes, or bearings.
Product Introduction: The B-604-G-99-G-2 is an economy-class AC servo motor from Kollmorgen's B-Series product line. It is designed for cost-sensitive applications that still require reliable servo performance. The model number decodes as: B (B-Series), 604 (frame size: ~60 mm OD), G (winding code), 99 (feedback variant), G (shaft variant), 2 (revision). This motor offers solid performance at a lower price point compared to M, S, or AKD-paired motors.
Model Number: MAG05-25041-00 Product Introduction: The MAG05-25041-00 is a high-resolution magnetic absolute encoder from Kollmorgen's MAG product line. It uses magnetic sensing technology (Hall-effect or magnetoresistive) to read a multi-pole magnetic ring, providing absolute position feedback without contact. This encoder is designed for harsh environments where optical encoders would fail due to dust, oil, vibration, or moisture.
Model Number: S74801-NA-024 Product Introduction: The S74801-NA-024 is a high-performance AC servo motor designed specifically for use with Kollmorgen's S700 series servo drives. The model number decodes as: S7 (S700 series), 48 (frame size S748), 01 (stack length 01), NA (standard winding), 024 (24 V brake or specific variant). This motor delivers high torque at high speed with an integrated multi-turn absolute encoder.
Product Introduction: The S71202-NANANA-NA is a high-end servo drive from Kollmorgen's S700 product line — the company's most advanced motion control platform. The model number decodes as: S7 (series), 1 (single-axis), 20 (20 A continuous), 2 (revision). The "NANANA-NA" suffix indicates a standard configuration without optional modules, for North American market. This drive delivers 20 A continuous output with EtherCAT primary communication and full functional safety integration.
Model Number: QT-3832-C Product Introduction: The QT-3832-C is a frameless (hollow-shaft) direct-drive torque motor from Kollmorgen's QT product line. It is designed for direct integration into customer mechanical structures, eliminating the need for gearboxes, couplings, and bearings. The "3832" indicates a 3.8-inch outer diameter with 3.2-inch axial length, and "C" denotes a specific winding/sensor variant.
Model Number: S61400-550 Product Introduction: The S61400-550 is a high-power AC servo motor from Kollmorgen's S600 product line. The "S614" denotes the frame size, "00" denotes the stack length, and "550" denotes the winding code. This motor is designed for high-torque, high-speed applications in demanding industrial environments.
