Kollmorgen B-606-DD-99-TS-268

The B-606-DD-99-TS-268 is a high-resolution multi-turn absolute encoder from Kollmorgen's B-600 encoder family, designed for direct mounting on Kollmorgen AKM/AKM2G series servo motors. The model code decodes as: B-606 (B-600 series, 60 mm flange) + DD (Differential Driver output — RS-422 / EIA-485 compatible) + 99 (high resolution variant, typically 2048 lines/rev × 4096 turns) + TS (Electrical interface: RS-422 differential) + 268 (Mechanical configuration: specific shaft coupling, housing, and mounting for AKM52/AKM63 motors). This encoder provides absolute position on power-up with no homing required.

Kollmorgen B-204-C-31-B3

Overview: The B-204-C-31-B3 is a regenerative braking unit (brake chopper) from the Kollmorgen B-200 product series. Unlike a passive braking resistor (B-600 series), the B-204 is an active electronic module that switches the DC bus energy to an external braking resistor with precise duty-cycle control. The model code: B-204 (B-200 series, 4 kW class) + C (configuration variant) + 31 (specific electrical rating) + B3 (terminal/connector variant). This unit is used in applications with high regeneration duty cycles where precise DC bus voltage clamping is required.

Kollmorgen B-604-C-A1-B2

Overview: The B-604-C-A1-B2 is a fully specified variant of the B-604 braking resistor with two configuration modifiers: "A1" denotes a specific mounting/mechanical option (e.g., particular bracket or flange style), and "B2" denotes a specific electrical connection option (e.g., different terminal block or lead style). This is a custom-ordered part number for OEMs requiring a non-standard mechanical or electrical interface while retaining the core B-604 electrical performance.

Kollmorgen B-604-C-A3

Overview: The B-604-C-A3 is a variant within the Kollmorgen B-604 braking resistor product line. The "C" suffix denotes a specific configuration option (typically a different terminal style or mounting arrangement compared to the "B" variant), while "A3" specifies the connector/terminal type. This resistor serves the same core function as the B-604-B-A3 — dissipating regenerative energy — but with configuration differences suited to specific drive or cabinet layouts.

Kollmorgen CE03250

Overview: The CE03250 is a pre-manufactured cable assembly from Kollmorgen's CE cable series, designed for connecting Kollmorgen servo drives to AKM/AKM2G series frameless or housed servo motors, specifically carrying power, encoder signals, and brake signals in a single shielded assembly. The model code indicates: CE (Cable Ensemble) + 032 (32 conductors or specific pin configuration) + 50 (5.0 meter length or 50-series variant). This cable is a factory-terminated, tested assembly that guarantees signal integrity and mechanical reliability.

Kollmorgen AKM52G-ANC2EJN

Overview: The AKM52G-ANC2EJN is a frameless (slotless) brushless servo motor from Kollmorgen's AKM product family, designed for direct integration into the mechanical structure of the machine (no bearing housing, no shaft). The model code decodes as: AKM (AKM Series) + 52 (52 mm outer diameter) + G (slotless/frameless variant) + A (with holding brake) + N (standard winding) + C2 (EnDat 2.2 encoder, 128 sine/cosine periods) + E (electrical connector) + J (connector style) + N (natural/standard configuration). This motor is engineered for applications where zero cogging, smooth torque, and compact radial integration are critical.

Kollmorgen AKD-B02407-NBA

Overview: The AKD-B02407-NBA is a compact, high-performance servo drive from the Kollmorgen AKD product family. The model code decodes as: AKD (AKD Series) + B (240 VAC input) + 024 (240 VAC nominal) + 07 (7 A continuous) + N (no line filter) + B (base functionality) + A (standard configuration). This drive is designed for OEM integration into machines requiring precise motion control with a small footprint.

Kollmorgen B-604-B-A3

Overview: The B-604-B-A3 is a dynamic braking resistor module from the Kollmorgen B-series product line, engineered to dissipate regenerative energy generated during motor deceleration or overhauling loads. The resistor converts excess kinetic energy into thermal energy, protecting the servo drive from DC bus overvoltage faults. The "B" suffix denotes the base configuration, and "A3" specifies the terminal/connector variant.

Kollmorgen S71201-US

Overview: The S71201-US is a single-axis digital AC servo drive from the Kollmorgen S700 product family, designed for high-performance motion control applications requiring precise torque, velocity, and position regulation. The "US" suffix denotes United States market compliance, including NEMA-rated input and UL/cUL certification. The drive features advanced current-mode control with a 20 kHz servo update rate, delivering exceptional dynamic response for industrial automation, packaging, printing, and material handling systems

Kollmorgen AKM64L-AN9NGE0

Product Name: Kollmorgen AKM64L-AN9NGE0 AKM Series Brushless Servo Motor Product Series: AKM Series — Compact Brushless DC Servo Motors (Framed) Product Type: Brushless Permanent Magnet Synchronous Servo Motor with Integrated Encoder and Drive Electronics Model Number: AKM64L-AN9NGE0

Kollmorgen AKD-B02407-NCA

Product Name: Kollmorgen AKD-B02407-NCA Servo Drive Product Series: AKD-B Series — Basic Performance Servo Drive Product Type: Digital AC Servo Drive (Economy Configuration) Model Number: AKD-B02407-NCA

Kollmorgen AKD-T02407-NBA

Product Name: Kollmorgen AKD-T02407-NBA Servo Drive Product Series: AKD-T Series — High-Performance Servo Drive Product Type: Digital AC Servo Drive with Advanced Motion Controller Model Number: AKD-T02407-NBA
