Kollmorgen AKM53M-ANC21-00

  • Product Name:​ AKM Series Brushless AC Servo Motor (Frame AKM5, stack M)
  • Product Introduction:​ Part of the AKM modular synchronous servo motor family offering high power density, low cogging and plug-and-play feedback recognition with AKD/S700 drives.

Kollmorgen AKD-P1207-NBPN-0000

Product Name:​ AKD Series High-Current Ethernet Servo Drive
Model Decode:​ P1207 = 12 Arms, 480 VAC family; NBPN-0000 = no safety, base firmware, panel connectors, standard option
Technical Specifications
  • Supply:​ 3 × 240–480 VAC

Kollmorgen AKD-P00607-NBC12

Product Name:​ AKD Series Ethernet Servo Drive
Model Decode:​ P = panel/book style, 006 = 6 Arms continuous, 07 = 480 VAC (240–480) family, N = no safety option, B = base firmware, C = connector type (M23/feedback options), 1 = option card bay, 2 = specific connector/firmware revision, NBC12 = ordering suffix

Kollmorgen 6181P-15TPXPHX

Product Name:​ Allen-Bradley 6181P Industrial Computer / Operator Interface
Clarification:​ This is Rockwell Automation (Allen-Bradley), not Kollmorgen. Often bundled in Kollmorgen motion systems as HMI.
Introduction:​ Panel-mounted industrial PC with touch screen for machine supervision.

Kollmorgen MFDHTB3A2NA1

Product Name:​ Panasonic MINAS A-series Drive (NOT Kollmorgen native)
Clarification:​ “MFDHTB3A2NA1” is a Panasonic​ servo drive model, frequently cross-listed by motion distributors alongside Kollmorgen because it competes in same 400 V class. Kollmorgen does not manufacture MFDHTB.

Kollmorgen N33HRLG-LEK-M2-00

Product Name:​ AKM-derived Special/Modified Servo Motor (N-prefix special build)
Interpretation:​ N33H = AKM33 frame with H winding geometry; RLG = resolver/feedback/shaft modification; LEK = connector/brake/voltage modification; M2 = custom mechanical variant; 00 = base

Kollmorgen AKM33H-ANCNC-00

Product Name:​ AKM Series PM Synchronous Servo Motor
Model Decode:​ AKM33 = size 33 (70 mm flange), H = winding H, A = no brake, N = smooth shaft no seal, C = resolver, N = M23 connectors, C = stack 2, 00 = standard
Technical Specifications (AKM33H reference)
  • Flange:​ 70 × 70 mm

Kollmorgen AKM22G-CKB22-00

Product Name:​ AKM Series Brushless Permanent-Magnet Servo Motor
Model Decode:​ AKM22 = size 22 (58 mm flange), G = winding G, C = resolver feedback, K = M23 angled rotatable connectors, B = stack 2, 2 = 115 VAC/230 V class winding variant, 2 = no brake/option, 00 = standard

Kollmorgen B-104-A-22

Product Name:​ Goldline B-Series AC Brushless Servo Motor
Family:​ Goldline B (low-inertia permanent-magnet synchronous servo)
Introduction:​ Compact 230 VAC brushless servo motor for rapid accel/decel cycles, compliant loads and large inertia mismatch.

Kollmorgen PRD-B040AAIB-A2

  • Product Name:​ AKD Platform Servo Drive, 40 A, 3-phase 230 VAC, Indexer + Brake Transistor, STO
  • Introduction:​ Variant of above with B = brake transistor/chopper onboard for dynamic braking on shared DC bus.
  • Technical Specifications:
    • Same electrical core as PRD-B040AAIZ-A2

Kollmorgen PRD-B040AAIZ-A2

  • Product Name:​ AKD Platform Servo Drive, 40 A, 3-phase 230 VAC, Indexer, STO
  • Introduction:​ High-current AKD-family drive (PRD prefix on some regional labels) for large AKM2G/AKM3G motors.
  • Technical Specifications:
    • Supply: 3 x 200–240 VAC (AAI = voltage/class code)

Kollmorgen S620-FAN

  • Product Name:​ SERVOSTAR 620 Servo Drive with Forced-Cooling Fan Option
  • Introduction:​ 20 A class AC servo amplifier from SERVOSTAR 600 family, FAN suffix indicates integrated cooling fan for high-duty cycles.
