Gasonics 2000-LL AWD-D-2-8-7 Load Lock Wiring Harness

Product Description: This is a complex assembly specific to the Gasonics 2000 Series Load Lock (LL) chamber. It likely combines a heavy-duty wiring harness for the load lock robot and gates with a pneumatic tubing bundle or a cable carrier (drag chain) assembly. The "AWD-D-2-8-7" suffix indicates a specific configuration for the load lock door mechanism and wafer transfer robot. Technical Specifications:

  • Type: Integrated Cable/Hose Carrier Assembly
  • Components: Bundled power cables, signal wires, and pneumatic tubes

Gasonics AWD-D-2-3 Vacuum Chamber Feedthrough Flange

Product Description: This part number typically refers to a specific feedthrough assembly or a wiring bundle that passes through the vacuum wall (chamber wall) to connect internal sensors (like thermocouples or pressure gauges) to the external control system. The "D-2-3" code often specifies a 3-pin or 3-channel configuration in the "D" series of feedthroughs. Technical Specifications:

  • Type: Vacuum Feedthrough / Hermetic Seal
  • Material: Stainless Steel 316L body, Ceramic or Glass insulators

Gasonics AWD-1-6 RF Sensor

Product Description: This is a specialized coaxial or multi-conductor cable used to transmit low-power RF signals or analog sensor data from the chamber or match network back to the control electronics. It is designed to handle sensitive signals without degradation or introducing noise into the measurement. Technical Specifications:

  • Type: Shielded Coaxial or Triaxial Cable
  • Impedance: 50 Ohms (RF) or High Impedance (Sensors)

Gasonics AWD-1-1 Main Controller

Product Description: This cable assembly serves as the primary communication link between the operator interface station (HMI/PC) and the tool's main processing controller or PLC. It is often a serial communication cable or an Ethernet patch cable specifically cut and shielded for the industrial environment of a semiconductor fab. Technical Specifications:

  • Type: Data Communication Cable / Serial Cable

Gasonics AWD-1-5 Pneumatic Solenoid Valve Manifold Harness

Product Description: This specific wiring harness connects the machine's central controller to a manifold of pneumatic solenoid valves. It is a critical interface for the tool's gas and vacuum control system. The AWD-1-5 typically routes 24VDC signals to actuate specific valves that control gas injection, chamber isolation, or venting. Technical Specifications:

  • Type: Multi-pair Signal Cable for Pneumatics

Gasonics AWD-1-8 Power Distribution Cable Assembly

Product Description: This is a heavy-duty electrical wiring harness designed for distributing AC or DC power within the Gasonics tool. Unlike signal cables, the AWD-1-8 is engineered to carry higher current loads required by actuators, heaters, or vacuum pumps. It is a pre-fabricated assembly that ensures proper grounding and isolation for high-power components. Technical Specifications:

  • Type: Power Cable / Mains Lead

Gasonics AWD-1-9 Internal Wiring Harness

Product Description: This part number identifies a specific internal electrical cable assembly used within Gasonics semiconductor equipment. "AWD" designations typically refer to "Assembly Wiring Documentation" or specific wire harness configurations. The "1-9" suffix denotes a specific routing path, length, and connector pinout. This harness is typically used to route low-voltage control signals or sensor data between the main equipment rack and peripheral subsystems. Technical Specifications:

  • Type: Multi-conductor Shielded Cable Assembly

Gasonics RA93-021-04/C RF Impedance Match Network

Product Description: This unit is a critical RF subsystem assembly designed for Gasonics plasma processing equipment. It functions as the impedance match network situated between the RF generator and the plasma chamber. The "RA" prefix typically denotes a specific rack-mount or chassis configuration, while the "C" revision indicates an upgraded circuit board or tuning algorithm. Its primary role is to maximize power transfer efficiency by matching the generator output impedance to the dynamic plasma load impedance. Technical Specifications:

  • Type: Automatic or Manual RF Impedance Match

Gasonics A95-053-02 C Electrode

Product Description: This is a critical wear part, specifically an electrode or a component of the electrostatic chuck (ESC) assembly. The "C" revision typically indicates a material upgrade or a specific geometry change. It is the surface upon which the wafer sits and is often responsible for clamping the wafer electrostatically or mechanically and providing RF bias or cooling. Technical Specifications:

  • Material: Single-crystal Silicon (for RF uniformity) or Aluminum Nitride (for thermal conductivity), coated with dielectric.

Gasonics AWD-D-2-8-4-001 PCB Assembly

Product Description: Similar to the AWD-D-3-4-001 but with a different configuration, this is likely a specific printed circuit board assembly serving as an interface or distribution board. It may route signals from the main CPU to peripheral devices, or act as a breakout board for a specific module like a gas panel or RF sensor. Technical Specifications:

  • Board Type: FR4 or High-Frequency Laminate (Rogers)

Gasonics AWD-D-3-4-001 Assembly

Product Description: This part number identifies a specific wiring harness or cable assembly used within the Gasonics tool. "AWD" often relates to assembly/wiring documentation. The code "D-3-4-001" specifies the exact configuration, length, connector types, and wire gauge for a specific sub-system connection (e.g., between the RF generator and the match network, or between the controller and the chuck). Technical Specifications:

  • Type: Custom Electrical Cable Assembly

Gasonics A95-075-01 Chamber Liner

Product Description: This component is a consumable or semi-consumable shield, typically made of a dielectric or conductive material, that lines the interior walls of the plasma chamber. Its primary purpose is to protect the expensive chamber hardware (usually Aluminum or Stainless Steel) from plasma erosion, chemical corrosion, and deposition of byproducts. Technical Specifications:

  • Material: Quartz (SiO2), Aluminum Oxide (Al2O3), Yttrium Oxide, or Anodized Aluminum
  • Shape: Cylindrical sleeve or dome-shaped cover
