GE DS200GGIAG1B

The GE DS200GGIAG1B is a GTO AC2000 Bridge Interface Board in the EX2000 series, designed for integration within GE steam and gas Speedtronic Mark V turbine control systems. It is a static-sensitive board and is stored and shipped in anti-static packaging. Detailed installation, operation, and maintenance guidance is provided in manual GEH-6120B.
Technical Specifications
  • Part Number:​ DS200GGIAG1B

GE AMCB6GB

The GE AMCB6GB is a circuit breaker mounting hardware strap kit, designed as a direct replacement kit for GE Spectra Series APN-B bolt-on style panelboards. It provides secure installation support for molded case circuit breakers in dual/twin branch (double) G-frame configurations.
Technical Specifications
  • Catalog Number:​ AMCB6GB

GE 6KG1143025X1B1

The GE 6KG1143025X1B1 is a 25-horsepower variable frequency drive in the AF-300 G11 family (GE Fuji Electric). It is a 3-phase VFD designed for industrial motor control applications requiring precise speed regulation and energy efficiency.
Technical Specifications
  • Power Rating:​ 25 HP

GE 0273B0220704

The GE 0273B0220704 is a relay output module for the GE Mark V / Mark VI distributed control system (DCS), providing multi-channel relay contact outputs for driving field actuators such as solenoid valves, contactors, and indicator lamps.
Technical Specifications
  • Channels:​ 8 (0273B family standard)

GE DS3800NDAC

Documented DS3800NDAC1B1C Specifications​ (representative of the DS3800NDAC family)
  • Product Type:​ Digital-to-Analog Output Card (DAC)
  • System Compatibility:​ Speedtronic Mark IV (6BA06 slot)
  • Resolution:​ 12-bit monotonic, ±½ LSB INL

GE SGLC3604L4XX

The GE SGLC3604L4XX is a 3-pole solid-state molded case circuit breaker in the SGLC Series, rated for 400 amps continuous current and 600 VAC. It is built for heavy-duty industrial circuit protection and integrates into GE Spectra Series panelboards and switchboards as a unit-mount MCCB with bolt-on connection.
Technical Specifications
  • Amperage:​ 400 A

GE 173C8413BDG02

The GE 173C8413BDG02 is a 4-channel analog input module for the GE Mark VI / Mark VIe distributed control system (DCS). It receives standard 4-20 mA or 0-10 V signals with independent galvanic isolation per channel, used for acquiring process variables such as temperature, pressure, flow, and level.
Technical Specifications
  • Channels:​ 4

GE 531X140CCHATM2

The GE 531X140CCHATM2 is a control board in the 531X Series, categorized under Drives as a drive board / control-interface board. It was originally associated with the AC500 drive platform and is now discontinued by the manufacturer.
Technical Specifications
  • Brand:​ General Electric

GE IC3600SSVD1

Product Overview
The board is built around a manually adjustable control architecture. Five blue potentiometers are aligned along the left edge for fine control-parameter tuning. A large central inductor with a round wire coil and black plastic cover manages electromagnetic fields and supports stable control and filtering. Two red metal oxide varistors on the right side protect the circuitry from voltage transients. The PCB also carries numerous banded resistors, silver or yellow capacitors, and small transistors in both silver circular and black half-circle packages. A large red LED near the top of a long metal plate provides visual operational feedback, and two orange operator-adjustable knobs at the bottom of the metal plate are connected to the PCB by white wires.

GE DS3800HXPD1B1D

Overview:​ The DS3800HXPD1B1D is a specialized high-speed counter/accumulator board manufactured by GE for Mark IV and Mark V Speedtronic turbine control systems. The "X" in the base model DS3800HXPD denotes a custom or prototype configuration with specialized PLD firmware and component selection for non-standard turbine applications or OEM-specific requirements. The suffix "1B1D" indicates Revision B, a specific component population, and D-type conformal coating. The board conditions and counts pulse signals from magnetic speed pickups or proximity probes, delivering accurate rotational speed data essential for turbine startup sequencing, fuel control, synchronization, and over-speed protection logic.

GE DS3800NDAC1E1F

Product Name:​ GE Mark IV Speedtronic DS3800NDAC1E1F — Analog Output Board
Overview:​ The DS3800NDAC1E1F is an analog output board within GE's Mark IV Speedtronic turbine control system. Its primary function is converting digital control commands from the Mark IV controller into precise analog output signals that drive downstream field devices such as actuators, I/P converters, and process control elements.

GE K116LSIGZ2PMR

Product Name:​ GE K116LSIGZ2PMR — MicroVersa PM Trip Unit / 16-Channel Relay Output Module
Overview:​ The K116LSIGZ2PMR is a General Electric protective trip module belonging to the MicroVersa PM (Low Voltage) family, rated for 1600 A applications and compatible with P427 & WavePro low-voltage systems. Supplier catalogs also identify this part number as a K-Series 16-channel relay output module for GE Fanuc PLC systems. Source documents present both identities; the MicroVersa PM trip unit classification is reflected in the original catalog reference.
