GE IC695ALG626RS - CA Analog Input Module

  • Input Channels: 16 single - ended inputs or 8 differential input channels.
  • Signal Types: Compatible with current signals such as 0 - 20mA, 4 - 20mA, ±20mA and voltage signals such as ±10V, 0 - 10V, ±5V, 0 - 5V, 1 - 5V.
  • ADC Resolution: 24 - bit ADC conversion resolution.
  • HART Communication: Each channel provides HART 5.0 communication function.
  • Operating Temperature Range: 0℃ - 60℃ (32℉ - 140℉).
  • Storage Temperature Range: - 40℃ - 85℃ (- 40℉ - 185℉).

GE IC3601A105A Power Supply Module

  • Input Voltage: Not explicitly mentioned in the available resources.
  • Output Voltage: 50V DC
  • Output Current: 0.15A
  • Output Power Rating: 7.5W (calculated as 50V x 0.15A)
  • Operating Temperature Range: -40°C to 85°C (inferred from general GE power module specifications)
  • Dimensions: Approximately 152.4mm x 152.4mm x 127mm (6.00 x 6.00 x 5.00 inches)
  • Weight: About 1.81kg (4.00 lbs)

GE IC670MDL740H Digital Output Module

  • Output Channels: 16 channels.
  • Output Voltage Range: 9.2 - 29.5V DC.
  • Output Current: 0.5A per channel, 4A in total.
  • Contact Resistance: <1Ω.
  • Switching Time: <2ms.
  • Common - Mode Rejection Ratio: >60dB.
  • Noise Immunity: >10V RMS.
  • Operating Temperature Range: - 40°C to 85°C.
  • Power Supply Voltage: 24V DC.
  • Dimensions: Approximately 120mm x 90mm x 60mm.
  • Weight: About 0.5kg.

GE IC693UDR001GP1 Universal Data Router Communication Module

  • Protocol Support:
    • Modbus RTU (Master/Slave)
    • Modbus TCP/IP (Client/Server)
    • GE SRTP (Series 90-30 Remote Transport Protocol)
    • DF1 (Full Duplex/Half Duplex)
  • Communication Ports:
    • 1 x 10/100 Mbps Ethernet port (RJ45 connector, supports Auto-MDI/MDI-X)
    • 2 x RS-232/RS-485 serial ports (terminal block connections, switch-selectable for RS-232 or RS-485 mode)
  • Data Transfer Rate:
    • Ethernet: Up to 100 Mbps (full duplex)
    • RS-232: 300 bps to 115.2 kbps
    • RS-485: 300 bps to 115.2 kbps (supports up to 32 nodes per bus)

GE IC693MDL753F

Technical Specifications

  • Output Type: Discrete digital output (solid-state, positive logic)
  • Number of Output Points: 32 channels, divided into 4 isolated groups (8 points per group)
  • Output Voltage Range: 10.2 VDC to 28.8 VDC
  • Output Current: 0.5 A maximum per output point; 4 A maximum per isolated group
  • Isolation: 1,500 VAC (rms) between field side and logic side; 250 VAC (rms) between adjacent output groups
  • Response Time: 0.5 ms maximum (on-time and off-time)
  • Power Consumption: 260 mA maximum from the Series 90-30 backplane (5 VDC bus); power draw includes 13 mA base current + 3 mA per active output point + 4.7 mA per active LED
  • Operating Temperature Range: -10°C to +55°C

GE IC693MDL645C

  • Input Voltage: 24 VDC, with an input voltage range of 0 - 30 VDC.
  • Number of Input Points: 16.
  • Input Current Rating: 7 mA at rated voltage.
  • Logic Type: Supports both positive and negative logic.
  • Isolation: 1500 V isolation between the field side and logic side.
  • On - State Voltage: 11.5 - 30 VDC.
  • Off - State Voltage: 0 - 5 VDC.
  • On and Off Response Time: 7 ms for both on and off.
  • Power Consumption: 80 mA from the 5 V bus on the backplane (all inputs on), 125 mA from the isolated 24 V backplane bus or user - supplied power.
  • Dimensions: Approximately 11.2 cm x 4.5 cm x 5.7 cm.
  • Weight: About 0.5 kg.

GE IC200MDL740C

  • Number of Input Channels: 8 differential analog input channels
  • Input Signal Types: Supports 4-20 mA DC (current) and 0-10 V DC (voltage) signals
  • Input Range Accuracy:
    • For 4-20 mA: ±0.1% of full scale (FS)
    • For 0-10 V DC: ±0.1% of full scale (FS)
  • Resolution: 16-bit ADC (Analog-to-Digital Converter)
  • Sampling Rate: 10 samples per second (SPS) per channel
  • Isolation: 250 V AC continuous isolation between input channels and backplane; 1500 V AC isolation for 1 minute (dielectric strength)
  • Operating Temperature Range: -20°C to 60°C
  • Storage Temperature Range: -40°C to 85°C

GE IC200MDL650D

  • Number of Output Points: 32.
  • Output Type: Relay output.
  • Rated Voltage: Typically 24VDC.
  • Operating Temperature Range: -20°C to 60°C.
  • Storage Temperature Range: -40°C to 85°C.
  • Relative Humidity: 5% to 95% (non - condensing).
  • Protection Level: IP67.
  • Size: 146.1mm x 82.5mm x 23.9mm.
  • Weight: Approximately 340g.

GE IC200MDL940G

  • Output Voltage: 0 - 125VDC (nominal values of 5V, 24V, 125VDC); 0 - 265VAC (47 - 63Hz), with nominal values of 120VAC and 240VAC.
  • Load Current per Point: 2.0A for 5 - 265VAC; 2.0A for 5 - 30VDC; 0.2A for 31 - 125VDC. The minimum load current per point is 10mA.
  • Response Time: The on - time and off - time are both 10ms.
  • Isolation: Input to logic isolation is 250VAC continuous and 1500VAC for 1 minute; group - to - group isolation is 250VAC continuous and 1500VAC for 1 minute. Each output is individually isolated.
  • Power Consumption: The maximum 5V backplane current consumption is 490mA.
  • Dimensions: 5 cm x 11 cm x 6.68 cm (excluding the height of the carrier or the mating connectors).

GE IC694MDL940A

  • Rated Voltage: 24VDC.
  • Operating Voltage Range: 5 - 30VDC, 5 - 250VAC.
  • Maximum Load per Output: 2A.
  • Minimum Load per Output: 10mA.
  • Maximum Inrush Current: 5A.
  • Response Time: On - 15ms, Off - 15ms.
  • Power Consumption: 7mA from 5V bus, 135mA from 24V relay.
  • Frequency: 50/60Hz.
  • Number of Outputs: 16.
  • Isolation: The module has 1500V AC isolation between field and backplane, and 250V AC continuous isolation between channels.

GE IC200PBI001-BE

  • Interface Type: PROFIBUS DP.
  • Communication Rate: Supports various communication rates including 960 kbps, 1.5 Mbps, 3 Mbps, and 6 Mbps.
  • Node Address: Ranges from 0 to 127.
  • Operating Temperature Range: -25°C to +60°C (-13°F to +140°F).
  • Protection Level: IP67.
  • Dimensions: 80 mm x 30 mm x 25 mm (3.15 inches x 1.18 inches x 0.98 inches).

GE IC200MDL650E

  • Output Points: 32 output points.
  • Output Type: Relay output.
  • Rated Voltage: The output can support a wide range of voltages, typically compatible with both AC and DC voltages. For example, it can handle voltages such as 5 to 265VAC and 5 to 30VDC.
  • Rated Current: Each point has a rated current. For instance, at 5 to 265VAC, the rated current is 2.0A for resistive loads, and at 5 to 30VDC, the rated current is also 2.0A for resistive loads.
  • Response Time: The module has a relatively fast response time, which allows for quick switching of the output states. The on - to - off and off - to - on response times are typically short, enabling timely control of the connected devices.
  • Isolation Voltage: It has isolation between channels, with a rated isolation voltage of 250VAC (continuous) and 1500VAC (for 1 minute) between groups.
