AEG AS-B855-016

  • Product Introduction: AEG AS-B855-016 is a high-density 16-channel digital input module designed for the Modicon 800 series PLC systems, engineered for discrete signal acquisition from industrial field devices in factory automation and process control applications. The module features sinking (NPN) input logic, 24 V DC operation, and optical isolation between channels and the backplane bus, delivering reliable detection of dry contact and voltage signals from limit switches, proximity sensors, pushbuttons, and other discrete field devices even in high-noise industrial environments. It integrates seamlessly with the Modicon 800 series backplane bus, with individual LED status indicators for each channel and built-in surge protection, making it an ideal solution for high-volume discrete signal acquisition in automotive manufacturing, packaging, material handling, and municipal infrastructure applications requiring scalable digital input expansion.
  • Technical Specifications:
    • Number of Input Channels: 16 independent digital input channels, 2-wire connection
    • Input Logic: Sinking (NPN), dry contact compatible
    • Input Voltage: 24 V DC (18–30 V DC operating range)
    • Input Current: 2.5 mA per channel at 24 V DC
    • Response Time: <1 ms (on/off), configurable delay (0–100 ms) for noise filtering

AEG BKF112 Industrial Miniature Circuit Breaker (MCB)

  • Product Introduction: AEG BKF112 is a compact miniature circuit breaker designed for overcurrent and short-circuit protection of low-voltage residential, commercial, and light industrial electrical circuits. The single-pole MCB features a thermal-magnetic trip mechanism, high breaking capacity, and a space-saving DIN rail mount design, delivering reliable protection for lighting, power, and control circuits in electrical panels and control cabinets. It is built with a rugged plastic enclosure, corrosion-resistant internal components, and compliance with global safety standards, making it suitable for use in both indoor and semi-outdoor installations. The BKF112 provides fast fault clearing, easy installation, and visual status indication, serving as a cost-effective protection solution for low-current electrical circuits in commercial buildings, industrial control systems, and municipal infrastructure applications.
  • Technical Specifications:
    • Pole Configuration: Single-pole (1P)
    • Rated Operational Voltage (Ue): 230 V AC (50/60 Hz), 400 V AC (cross-pole)
    • Rated Incoming Current (In): 12 A (fixed trip rating)
    • Rated Short-Circuit Breaking Capacity (Icu): 6 kA @ 230 V AC, 4.5 kA @ 400 V AC
    • Trip Unit Type: Thermal-magnetic (B-curve trip characteristic)
    • B-Curve Trip Characteristic: Trips at 3–5 In (instantaneous) for short-circuits, thermal overload protection for long-time overcurrents

AEG MEF002 Industrial Molded Case Circuit Breaker (MCCB)

  • Product Introduction: AEG MEF002 is a high-performance molded case circuit breaker engineered for overcurrent and short-circuit protection of low-voltage industrial power distribution systems, motor control circuits, and automation equipment. The breaker features a thermomagnetic trip unit, adjustable current settings, and a rugged molded case construction, delivering reliable overcurrent protection for electrical systems in industrial, commercial, and municipal applications. It supports both fixed and plug-in mounting configurations, with high interrupting capacity and compliance with global safety standards, making it suitable for use in power distribution panels, motor control centers (MCCs), and control cabinets. The MEF002 provides selective protection to minimize system downtime during electrical faults, with easy operation and maintenance, serving as a critical component for ensuring the safety and reliability of low-voltage electrical systems in harsh industrial environments.
  • Technical Specifications:
    • Pole Configuration: 3-pole, 4-pole available
    • Rated Operational Voltage (Ue): 400 V AC (50/60 Hz), 690 V AC optional
    • Rated Incoming Current (In): 16 A, 20 A, 25 A, 32 A, 40 A, 50 A, 63 A (adjustable)
    • Rated Short-Circuit Interrupting Capacity (Icu): 25 kA @ 400 V AC, 15 kA @ 690 V AC
    • Rated Service Short-Circuit Breaking Capacity (Ics): 100% Icu (symmetrical)

AEG AS-BADU-205

  • Product Introduction: AEG AS-BADU-205 is a versatile 8-channel universal analog input module designed for the Modicon 800 series PLC systems, engineered to acquire a wide range of analog signals from industrial field sensors and transmitters in process control and automation applications. The module supports software-configurable input types (current, voltage, resistance, thermocouple, RTD) on a per-channel basis, eliminating the need for multiple dedicated analog input modules and reducing system complexity. It features high-precision signal conditioning, full channel-to-channel optical isolation, and advanced noise rejection, delivering accurate and stable analog data even in high-noise industrial environments. The module integrates seamlessly with the Modicon 800 series backplane bus, with built-in fault detection and LED status indicators, making it an ideal solution for multi-parameter process monitoring in chemical, pharmaceutical, manufacturing, and municipal infrastructure applications requiring flexible analog signal acquisition.
  • Technical Specifications:
    • Number of Input Channels: 8 fully isolated channels, software-configurable per channel
    • Supported Input Types: 4-20 mA, 0-20 mA, 0-10 V DC, 0-5 V DC, 1-5 V DC, Pt100/Pt1000 RTD, J/K/T/E/R/S/N thermocouple, 0-1000 Ω resistance
    • Resolution: 16-bit ADC for all input types, 0.01°C resolution for temperature measurements
    • Measurement Accuracy: ±0.1% of full scale (current/voltage), ±0.2°C (RTD), ±0.3°C (thermocouple @25°C)

AEG 557VCM74210

  • Product Introduction: AEG 557VCM74210 is a high-performance color touchscreen HMI panel belonging to the Modicon Magelis series, engineered for intuitive human-machine interaction in industrial automation and process control systems. The panel features a high-resolution display, multi-touch capacitive screen, and seamless integration with Modicon PLCs and third-party industrial control devices via multiple communication protocols. It is built with a rugged industrial design, wide environmental tolerance, and IP65 front protection, making it suitable for direct installation on factory floors, machinery enclosures, and control panels in harsh industrial environments. The HMI delivers real-time process visualization, data logging, alarm management, and remote control capabilities, serving as a central operator interface for monitoring and controlling complex automation systems in manufacturing, process control, and municipal infrastructure applications.
  • Technical Specifications:
    • Display Type: 7-inch WSVGA color TFT LCD, capacitive multi-touch screen
    • Resolution: 800 × 480 pixels, 16.7 million colors
    • Brightness: 500 cd/m², contrast ratio 1000:1, viewing angle 170° (horizontal)/150° (vertical)
    • Touch Operation: Multi-touch (2 points), scratch-resistant tempered glass surface (3H hardness)
    • Communication Interfaces: 1×Ethernet (Modbus TCP/IP, Ethernet/IP), 1×RS-485 (Modbus RTU/ASCII), 1×USB 2.0 (host/device)

AEG 043 506 711

  • Product Introduction: AEG 043 506 711 is a rugged, high-reliability chassis-mounted power supply module designed for legacy Modicon PLC systems, serving as the primary power source for PLC CPUs, I/O modules, and communication modules in industrial automation and process control applications. The module features a regulated dual DC output (5 V DC logic power + 24 V DC I/O power), wide AC input range, and comprehensive electrical protection, engineered to deliver stable power to sensitive PLC electronics even in unstable industrial power grids. It is built with a heavy-duty metal enclosure, passive cooling, and direct chassis mounting, ensuring reliable 24/7 operation in harsh industrial environments while maintaining compatibility with legacy Modicon PLC chassis hardware, making it a critical replacement component for retrofitting and maintaining existing Modicon automation systems.
  • Technical Specifications:
    • Input Voltage: 115/230 V AC (selectable, 50/60 Hz), 85–264 V AC universal input range
    • Output Voltage: 5 V DC (regulated, ±0.5% accuracy) + 24 V DC (regulated, ±1% accuracy), dual isolated outputs
    • Output Current: 5 V DC @ 10 A continuous (50 W), 24 V DC @ 5 A continuous (120 W), 170 W total power
    • Conversion Efficiency: >88% at full load, >85% at 50% load
    • Ripple & Noise: <30 mV peak-to-peak (5 V DC), <50 mV peak-to-peak (24 V DC)
    • Isolation: 3000 V AC (input-to-output), 2500 V AC (5 V DC output-to-24 V DC output)
    • Protection Features: Overvoltage protection (OVP), overcurrent protection (OCP), overtemperature protection (OTP), short-circuit protection (SCP), input surge protection

AEG AS-B875-200

  • Product Introduction: AEG AS-B875-200 is a high-precision 8-channel analog input module designed for the Modicon 800 series PLC systems, optimized for temperature measurement via thermocouples and direct millivolt (mV) signal acquisition from low-level analog sensors. The module features built-in cold junction compensation (CJC), advanced signal conditioning, full channel-to-channel optical isolation, and wide thermocouple type support, delivering accurate and stable temperature/mV data even in high-noise industrial environments. It supports high-speed sampling, configurable digital filtering, and seamless integration with the Modicon 800 series backplane bus, making it an ideal solution for multi-point temperature monitoring and low-level signal acquisition in chemical processing, food manufacturing, pharmaceutical production, and metalworking applications requiring precise process control.
  • Technical Specifications:
    • Number of Input Channels: 8 fully isolated channels (thermocouple/mV, software-configurable per channel)
    • Supported Thermocouple Types: J, K, T, E, R, S, B, N (8 industrial standards, software-selectable per channel)
    • mV Input Range: 0–50 mV, -25–+25 mV (software-configurable, 16-bit resolution)
    • Temperature Measurement Range: Dependent on thermocouple type (J: -210°C–+1250°C, K: -270°C–+1372°C, B: 400°C–+1820°C)

AEG DR-1010-000 Industrial DIN Rail Mount DC Power Supply

  • Product Introduction: AEG DR-1010-000 is a high-efficiency, compact DIN rail mount DC power supply engineered for providing stable, regulated 24 V DC power to industrial automation equipment, including PLCs, I/O modules, HMIs, and field sensors. The module features a wide AC input voltage range, high power conversion efficiency, and comprehensive electrical protection, making it suitable for use in global industrial applications with unstable power grids. It is designed with a rugged metal enclosure, passive cooling, and space-saving DIN rail mounting, ensuring reliable operation in harsh industrial environments while minimizing control panel space requirements. As a dedicated industrial power supply, it is the primary power source for low-voltage DC control systems in factory automation, process control, and building automation applications.
  • Technical Specifications:
    • Input Voltage: 85–264 V AC (1-phase, 50/60 Hz), 120–370 V DC (universal input)
    • Output Voltage: 24 V DC (regulated, ±1% accuracy)
    • Output Current: 10 A continuous (240 W total power), 12 A peak for 5 seconds
    • Conversion Efficiency: >94% at full load, >90% at 20% load
    • Ripple & Noise: <50 mV peak-to-peak (at full load)

AEG 110CPU31100

  • Product Introduction: AEG 110CPU31100 is a high-performance compact CPU module designed as the core of the Modicon Premium 110 series PLC systems, optimized for small to medium-scale industrial automation and process control applications. The module features a 32-bit processor, integrated I/O, on-board communication, and support for IEC 61131-3 programming standards, delivering fast program execution and seamless integration with Modicon Premium I/O modules and industrial networks. It is engineered with a rugged industrial design, wide environmental tolerance, and built-in diagnostics, making it an ideal solution for discrete control, sequential process control, and small-scale analog control in factory automation, building automation, and municipal infrastructure applications.
  • Technical Specifications:
    • Processor: 32-bit industrial RISC processor, 40 MHz clock speed
    • Program Execution Speed: 0.2 μs per boolean instruction, 1.0 μs per floating-point instruction
    • On-Board Memory: 512 KB Flash program memory (non-volatile), 256 KB RAM data memory (battery-backed)
    • Integrated I/O: 16 digital inputs (24 V DC sinking), 16 digital outputs (24 V DC sourcing, 0.5 A per channel)
    • Expandable I/O Capacity: Up to 1024 digital I/O points, up to 128 analog I/O points (via Premium I/O modules)

AEG 170-BDI-344-00

  • Product Introduction: AEG 170-BDI-344-00 is a compact, high-density 16-channel DC digital input module engineered for the Modicon Momentum series of modular industrial automation controllers, optimized for discrete signal acquisition in factory automation, building control, and process monitoring applications. The module is designed to detect dry contact and DC voltage signals from field devices such as limit switches, pushbuttons, and proximity sensors, with built-in surge protection and optical isolation to ensure reliable operation in high-noise industrial environments. It features a space-saving DIN rail mount design, plug-and-play connectivity, and real-time status diagnostics, making it a cost-effective solution for scalable digital input expansion in small to medium-scale automation systems.
  • Technical Specifications:
    • Number of Input Channels: 16 independent DC digital input channels, 2-wire connection
    • Input Voltage Range: 24 V DC (18–30 V DC operating range)
    • Input Type: Sinking (NPN) logic, dry contact compatible
    • Input Current: 3 mA per channel at 24 V DC
    • Response Time: <2 ms (on/off), configurable delay (0–100 ms) for noise filtering
    • Isolation: 2500 V AC optical isolation (channel-to-backplane, channel-to-channel)

AEG ALU130236017

  • Product Introduction: AEG ALU130236017 is a legacy central processing unit module belonging to the Modicon ALU130 series, serving as the core processing unit for early Modicon automation systems. It is designed to execute control logic, process data, and coordinate system operations in industrial automation applications, particularly suited for retrofitting older production lines and maintaining legacy equipment. The CPU features a 16-bit processor, on-board memory, and support for Modbus communication, ensuring compatibility with legacy I/O modules and control systems, making it a reliable solution for extending the service life of existing automation infrastructure.
  • Technical Specifications:
    • Processor: 16-bit industrial microprocessor, 16 MHz clock speed
    • Program Memory: 128 KB EPROM (non-volatile)
    • Data Memory: 32 KB RAM (battery-backed)
    • I/O Capacity: Up to 1024 digital I/O points, 64 analog I/O points (via expansion modules)
    • Communication Interface: RS-485 (Modbus RTU), 9600 bps baud rate

AEG AS-E785-904 Industrial Ethernet Communication Module

  • Product Introduction: AEG AS-E785-904 is a high-speed industrial Ethernet communication module designed for the Modicon M340 series PLC systems, enabling seamless integration into Ethernet/IP and Modbus TCP networks. The module supports real-time data transfer, TCP/IP communication, and built-in security features, making it ideal for connecting Modicon M340 PLCs to SCADA systems, HMIs, and other industrial devices in factory automation and process control applications. It features a rugged design with wide temperature tolerance, ensuring reliable operation in harsh industrial environments where continuous network connectivity is essential.
  • Technical Specifications:
    • Communication Protocol: Ethernet/IP, Modbus TCP
    • Network Interface: 10/100 Mbps RJ45 port (auto-sensing)
    • Data Transfer Rate: 100 Mbps (full-duplex)
    • Communication Distance: 100 m (copper cable), extendable via switches
    • IP Address Configuration: Static IP, DHCP
    • Connection Capacity: Up to 64 simultaneous TCP/IP connections
