AEG Modicon AS-B840-108 Analog Input Module

  • Product Introduction: This analog input module is used to collect analog signals (such as temperature, pressure, and flow) from on - site sensors and transmit them to the PLC for processing, providing data support for the control and monitoring of the production process.
  • Technical Specifications:
    • Number of Input Channels: 8 channels
    • Input Types: Thermocouple (J, K, T, E, R, S, B types), RTD (PT100, PT1000)
    • Input Range: For thermocouple: -200°C to +1800°C; for RTD: -200°C to +850°C
    • Accuracy: ±0.2% of full scale
    • Resolution: 16 bits
    • Working Voltage: 24V DC

AEG ALU150 Analog Output Module

  • Product Introduction: It is an analog output module used to convert the digital control signals from the PLC into analog signals (current or voltage) to control analog - controlled equipment in the industrial field, such as frequency converters and regulators.
  • Technical Specifications:
    • Number of Output Channels: 4 channels
    • Output Types: 4-20mA DC current output, 0-10V DC voltage output (switchable per channel)
    • Output Accuracy: ±0.1% of full scale
    • Resolution: 16 bits
    • Load Capacity: 500Ω for current output, 10kΩ for voltage output

AEG 110CPU62200 Programmable Logic Controller (PLC) CPU Module

  • Product Introduction: As the core component of the AEG 110 series PLC, it is responsible for executing user programs, processing input and output signals, and communicating with other modules and devices to realize the centralized control of the industrial automation system.
  • Technical Specifications:
    • Processor: 32 - bit RISC processor with a main frequency of 800MHz
    • Memory: 16MB RAM, 32MB Flash memory
    • Number of I/O Points: Up to 8192 points can be expanded
    • Communication Interfaces: Ethernet (TCP/IP), RS232, RS485
    • Programming Language: Ladder Diagram (LD), Function Block Diagram (FBD), Structured Text (ST)

AEG 6051-042.23602 Digital Output Module

  • Product Introduction: It is a digital output module for industrial automation control systems, which is used to convert the control signals from the controller into on - site executable actions to drive various actuators.
  • Technical Specifications:
    • Number of Output Channels: 16 channels
    • Output Type: Relay output
    • Rated Voltage: 230V AC, 24V DC
    • Rated Current: 5A per channel, 32A for the whole module (total current)
    • Response Time: ≤10ms
    • Working Voltage: 24V DC

AEG DEA156 Digital Encoder Module

  • Product Introduction: It is a digital encoder module designed for precise position and speed detection in industrial motion control systems, providing high - precision position and speed feedback signals for servo motors and stepping motors.
  • Technical Specifications:
    • Resolution: 156 pulses per revolution
    • Output Signal: A, B, Z three - channel square wave signals
    • Output Voltage: 5V DC
    • Output Current: 20mA per channel

AEG Modicon AS-B827-032 24V DC Digital Input Module

  • Product Introduction: This is a high - performance digital input module belonging to the AEG Modicon series, which is specially used to collect digital input signals in industrial automation control systems and transmit them to the main controller for processing, so as to realize the monitoring and control of on - site equipment.
  • Technical Specifications:
    • Number of Input Channels: 32 channels
    • Input Type: 24V DC sinking input
    • Input Voltage Range: 18-30V DC
    • Input Current: 5mA per channel

AEG MM-PM10-20S Power Monitoring Module

  • Product Introduction: It is a dedicated power monitoring module designed for industrial power distribution systems to provide real-time and accurate monitoring of electrical parameters, ensuring the stable and efficient operation of the power system.
  • Technical Specifications:
    • Input Voltage: 3-phase 400V AC, 50/60Hz
    • Current Measurement Range: 0-100A
    • Accuracy Class: 0.5S for current and voltage, 1.0 for power
    • Communication Interface: RS485, Modbus RTU protocol
    • Working Voltage: 24V DC

AEG AS-C951-009 Industrial PLC Chassis Expansion Backplane

  • Product Introduction: AEG AS-C951-009 is a high-reliability 9-slot industrial PLC chassis expansion backplane exclusively designed for the Modicon 900 series PLC systems, engineered to provide a secure, high-speed interconnect for Modicon 900 series CPU, I/O, communication, and power supply modules in medium to large-scale industrial automation and process control applications. The backplane features a proprietary high-speed data bus, dedicated isolated power distribution rails, and rugged mechanical construction, delivering stable 10 Mbps data transfer between modules and reliable 24 V DC/5 V DC power distribution to all installed PLC components. It is built with corrosion-resistant metal framing, gold-plated contact slots, and vibration-resistant mounting hardware, with compliance with Modicon 900 series mechanical and electrical specifications. The expansion backplane enables scalable system expansion for Modicon 900 series PLCs, supporting the addition of I/O, communication, and special function modules to meet the growing requirements of complex industrial automation systems in manufacturing, process control, and municipal infrastructure applications.
  • Technical Specifications:
    • Slot Quantity: 9 standard Modicon 900 series module slots, compatible with all Modicon 900 series I/O, communication, CPU, and power modules
    • Backplane Data Bus: Proprietary Modicon 900 series high-speed bus, 10 Mbps synchronous data transfer rate, <0.5 ms module-to-module latency
    • Bus Topology: Linear daisy-chain, support for up to 4 cascaded expansion backplanes (36 total slots) per CPU
    • Power Distribution Rails: 3 isolated power rails (5 V DC logic power, 24 V DC I/O power, 24 V DC auxiliary power), individually fused

AEG AS-J890-101

Product Introduction: AEG AS-J890-101 is a compact multi-protocol industrial communication gateway module designed for the Modicon 800 and 900 series PLC systems, engineered to enable seamless data exchange between Modicon PLCs and third-party industrial control devices, HMIs, SCADA systems, and industrial networks. The module features a single configurable communication port (RS-485/Ethernet) and support for mainstream industrial communication protocols, delivering bi-directional real-time data transfer and protocol conversion with ultra-low latency. It is built with a rugged industrial design, wide environmental tolerance, and built-in fault detection, with seamless integration into Modicon 800/900 series PLC chassis via the proprietary backplane bus. The gateway module eliminates the need for multiple dedicated communication modules, reducing system complexity and enabling Modicon PLC integration into multi-vendor industrial automation networks in factory automation, process control, and municipal infrastructure applications. Technical Specifications (Continued):

  • Connection Capacity: Up to 32 simultaneous Modbus connections, 16 Ethernet TCP/IP connections, 8 Profibus-DP slave connections
  • Data Transfer Latency: <1 ms (protocol conversion), <5 ms (cross-network data transfer)
  • Backplane Interface: Modicon 800/900 series proprietary bus, 10 Mbps data transfer rate, plug-and-play integration

AEG 0771553800032

  • Product Introduction: AEG 0771553800032 is a high-reliability backplane connector module designed for legacy Modicon PLC chassis systems, serving as the critical interconnect component for establishing electrical and communication links between PLC CPUs, I/O modules, power supply modules, and communication modules. The module features gold-plated contact pins, rugged mechanical construction, and compliance with legacy Modicon backplane bus specifications, delivering stable power distribution and high-speed data transfer between all installed PLC modules in industrial automation and process control applications. It is engineered for 24/7 continuous operation in harsh industrial environments, with corrosion-resistant components and vibration-resistant mounting, making it an essential replacement and repair component for maintaining and retrofitting legacy Modicon PLC infrastructure in manufacturing, process control, and municipal infrastructure applications where legacy chassis hardware is still in use.
  • Technical Specifications:
    • Compatibility: Modicon Legacy Series PLC chassis (8-slot/12-slot configurations), compatible with legacy Modicon CPU, I/O, power, and communication modules
    • Contact Pins: Gold-plated copper alloy pins (5 μm plating thickness), low contact resistance (<5 mΩ)
    • Number of Contacts: 96 pins (power + communication), dual row configuration
    • Power Distribution Pins: 24 V DC (16 pins), 5 V DC (16 pins), GND (24 pins)
    • Communication Bus Pins: 40 pins (legacy Modicon proprietary backplane bus)

AEG ALU130 Central Processing Unit (CPU) Module

  • Product Introduction: AEG ALU130 is a legacy compact CPU module belonging to the Modicon ALU130 series, engineered as the core processing unit for small to medium-scale industrial automation systems and legacy Modicon control infrastructure. The CPU features a 16-bit industrial microprocessor, on-board non-volatile memory, and integrated Modbus communication, delivering reliable execution of discrete control logic and sequential process control for retrofitting existing production lines and maintaining legacy automation equipment. It supports a wide range of Modicon ALU130 series I/O modules, with a rugged industrial design, wide environmental tolerance, and built-in diagnostics, making it a cost-effective solution for extending the service life of legacy Modicon automation systems in manufacturing, process control, and municipal infrastructure applications where full system replacement is not feasible.
  • Technical Specifications:
    • Processor: 16-bit industrial microprocessor, 16 MHz clock speed
    • Program Execution Speed: 1.0 μs per boolean instruction, 5.0 μs per arithmetic instruction
    • On-Board Memory: 128 KB EPROM (non-volatile program memory), 32 KB RAM (battery-backed data memory)
    • Battery Backup: 3 V lithium battery, 5-year data retention for RAM
    • I/O Capacity: Up to 1024 digital I/O points, up to 64 analog I/O points (via ALU130 series expansion I/O modules)

AEG AS-B825-016

  • Product Introduction: AEG AS-B825-016 is a high-density 16-channel digital output module designed for the Modicon 800 series PLC systems, engineered for switching low-current 24 V DC field devices in factory automation and process control applications. The module features sourcing (PNP) output logic, transistor outputs (MOSFET), and optical isolation between channels and the backplane bus, delivering fast and reliable switching of solenoid valves, indicator lights, small contactors, and other low-power discrete field devices even in high-noise industrial environments. It integrates seamlessly with the Modicon 800 series backplane bus, with individual LED status indicators for each channel and built-in overcurrent/short-circuit protection, making it an ideal solution for high-volume discrete output control in automotive manufacturing, packaging, material handling, and municipal infrastructure applications requiring scalable digital output expansion.
  • Technical Specifications:
    • Number of Output Channels: 16 independent digital output channels, grouped 8 channels per common
    • Output Logic: Sourcing (PNP), transistor (MOSFET) output
    • Output Voltage: 24 V DC (18–30 V DC operating range)
    • Output Current: 0.5 A per channel, 4 A per common group (resistive load)
    • Switching Response Time: <0.1 ms (on), <0.2 ms (off)
