AEG AS-S985-802

  • Technical Specifications:
    • Number of input channels: 8 channels (isolated)
    • Input signal type: 4 mA - 20 mA DC, 0 V - 10 V DC (configurable per channel)
    • Input resolution: 12 bits
    • Accuracy: ±0.1% of full scale
    • Response time: ≤10 ms
    • Isolation voltage: 1000 V AC between channels and between channels and ground
    • Operating temperature range: -25°C to +70°C
    • Degree of protection: IP20
    • Dimensions (W x H x D): 35 mm x 100 mm x 120 mm
    • Weight: 0.25 kg

AEG MM-PMC2-100

Technical Specifications:

  • Measurement parameters: Voltage (V), current (A), active power (kW), reactive power (kVAR), apparent power (kVA), power factor (PF), frequency (Hz), energy (kWh, kVARh)
  • Voltage range: 0 V - 500 V AC (phase - to - phase)
  • Current range: 0 A - 5 A AC (via current transformers)
  • Accuracy class: 0.5 for voltage and current, 1.0 for power and energy
  • Communication ports: 1 x RS - 485 (Modbus RTU)
  • Operating temperature range: -25°C to +70°C
  • Degree of protection: IP20
  • Dimensions (W x H x D): 35 mm x 100 mm x 120 mm
  • Weight: 0.2 kg

AEG TCCX1730LW

Technical Specifications:

  • Rated current range: 20 A - 30 A
  • Setting current range: 20 A - 30 A (adjustable)
  • Number of poles: 3 poles
  • Trip class: Class 10 (trips within 10 seconds at 6 x rated current)
  • Phase failure protection: Yes
  • Manual/auto reset: Both manual and automatic reset options
  • Operating temperature range: -25°C to +70°C
  • Degree of protection: IP20
  • Dimensions (W x H x D): 50 mm x 100 mm x 120 mm
  • Weight: 0.3 kg

AEG TSXSCM2222

Technical Specifications:

  • Communication protocol: Modbus RTU, Modbus ASCII, Ethernet/IP, Profinet
  • Communication ports: 1 x RS - 485, 1 x Ethernet (RJ45)
  • Transmission rate: RS - 485 up to 115.2 kbps, Ethernet up to 100 Mbps
  • Number of nodes: Up to 32 nodes on RS - 485 network, up to 256 nodes on Ethernet network
  • Operating temperature range: 0°C to +60°C
  • Degree of protection: IP20
  • Dimensions (W x H x D): 35 mm x 100 mm x 120 mm
  • Weight: 0.25 kg

AEG AS-509P-003

Technical Specifications:

  • Number of output channels: 8 channels (isolated)
  • Output signal type: DC 24 V
  • Output current: 2 A per channel (maximum 8 A per module)
  • Output voltage range: 22 V DC - 26 V DC
  • Response time: ≤1 ms
  • Isolation voltage: 500 V AC between channels and between channels and ground
  • Operating temperature range: -25°C to +70°C
  • Degree of protection: IP20
  • Dimensions (W x H x D): 35 mm x 100 mm x 120 mm
  • Weight: 0.25 kg

AEG AS-516P-008

Technical Specifications:

  • Number of input channels: 8 channels (isolated)
  • Input signal type: DC 24 V
  • Input voltage range: 15 V DC - 30 V DC
  • Input current: 5 mA per channel
  • Response time: ≤1 ms
  • Isolation voltage: 500 V AC between channels and between channels and ground
  • Operating temperature range: -25°C to +70°C
  • Degree of protection: IP20
  • Dimensions (W x H x D): 35 mm x 100 mm x 120 mm
  • Weight: 0.2 kg

AEG PC-A984-141

Technical Specifications:

  • Processor type: 32 - bit RISC processor
  • Instruction execution speed: 0.05 μs per basic instruction
  • User program memory: 32 KB Flash memory (expandable up to 128 KB)
  • Data memory: 16 KB RAM (expandable up to 64 KB)
  • Number of I/O points: Up to 1024 digital I/O points, 256 analog I/O points (expandable via I/O racks)
  • Communication ports: 2 x RS - 232, 1 x RS - 485 (Modbus RTU/ASCII), 1 x Ethernet (TCP/IP, Modbus TCP)
  • Programming language: LD, FBD, IL, Structured Text (ST)
  • Operating voltage: 24 V DC (18 V DC - 30 V DC)
  • Power consumption: 12 W
  • Operating temperature range: -10°C to +60°C
  • Degree of protection: IP20

AEG 110CPU612

Technical Specifications:

  • Processor type: 16 - bit microprocessor
  • Instruction execution speed: 0.1 μs per basic instruction
  • User program memory: 8 KB EEPROM (expandable up to 32 KB)
  • Data memory: 4 KB RAM
  • Number of I/O points: Up to 256 digital I/O points (expandable via I/O modules)
  • Communication ports: 1 x RS - 232 (for programming and communication with HMI/devices), 1 x Modbus RTU (for network communication)
  • Programming language: Ladder Diagram (LD), Function Block Diagram (FBD), Instruction List (IL)

AEG CGC07-80T

Technical Specifications:

  • Rated operational voltage (Ue): 400 V AC
  • Rated operational current (Ie): 80 A at 400 V AC, 50 Hz
  • Making capacity (Icm): 10 x Ie (800 A) for 0.3 seconds
  • Breaking capacity (Ics): 8 x Ie (640 A) for 0.3 seconds
  • Coil voltage options: 24 V AC, 48 V AC, 110 V AC, 220 V AC, 380 V AC, 50/60 Hz
  • Number of poles: 3 poles (3 NO)
  • Mechanical lifespan: 10 million operations
  • Electrical lifespan: 1 million operations at rated current
  • Operating temperature range: -25°C to +70°C
  • Degree of protection: IP20 (front face)

AEG MEF001 Motor Protection Relay

  • Product Introduction: It is a dedicated motor protection relay designed to monitor and protect three-phase AC motors from overload, phase loss, phase imbalance, over-voltage, under-voltage, and other electrical faults, ensuring the safe and reliable operation of motors in industrial applications.
  • Technical Specifications:
    • Rated Current: 0.1-100A (adjustable)
    • Rated Voltage: 400VAC, 50/60Hz
    • Protection Functions: Overload, phase loss, phase imbalance, over-voltage, under-voltage, ground fault
    • Overload Protection Curve: Class 10, 20, 30 (adjustable)

AEG PC-A984-145 Advanced Communication and Programming Module for Modicon

  • Product Introduction: It is an enhanced communication and programming module for the AEG Modicon 984 series PLC, offering advanced features for data exchange, programming, and system integration in complex industrial automation environments.
  • Technical Specifications:
    • Communication Interfaces: Ethernet (TCP/IP), RS232, RS485
    • Communication Protocols: Modbus TCP/IP, Modbus RTU, ASCII
    • Data Transmission Rate: Ethernet/10/100Mbps, RS485/115.2kbps
    • Programming Software Compatibility: Modicon Concept, Unity Pro

AEG AS-1957-000 Digital Output Expansion Module

  • Product Introduction: It is a digital output expansion module designed to increase the number of digital output points in industrial automation systems, converting control signals from the PLC into executable actions to drive various field actuators.
  • Technical Specifications:
    • Number of Output Channels: 32
    • Output Type: Relay output
    • Rated Voltage: 230VAC, 24VDC
    • Rated Current: 3A per channel, 64A total
