AEG AS-S911-800

Technical Specifications:

  • Communication interfaces: 2 x RS - 232, 2 x RS - 485
  • Supported protocols: Modbus RTU, ASCII, DF1
  • Communication baud rate: 1200 bps - 115200 bps (configurable)
  • Number of connected devices: Up to 32 devices per RS - 485 port
  • Data transfer parity: None, Even, Odd (configurable)
  • Operating voltage: 24 V DC (18 V DC - 30 V DC)
  • Power consumption: 2 W

AEG PC-A984-146

Technical Specifications:

  • Number of I/O slots: 8 slots for connecting I/O modules
  • Data transfer rate: 1 Mbps for high - speed data exchange between the CPU and I/O modules
  • Supported I/O module types: Digital input/output modules, analog input/output modules, special function modules (counting, positioning, etc.)
  • Backplane current capacity: 5 A to supply power to the connected I/O modules
  • Operating voltage: 24 V DC (18 V DC - 30 V DC)
  • Power consumption: 3 W

AEG CPU 512 00

Technical Specifications:

  • Processor type: 16 - bit microcontroller
  • Instruction execution speed: 0.1 μs per basic instruction
  • User program memory: 8 KB EEPROM (expandable up to 16 KB)
  • Data memory: 4 KB RAM
  • Built - in I/O: 16 digital inputs, 16 digital outputs (relay type)
  • Expansion capability: Supports up to 8 I/O expansion modules, with a maximum of 256 I/O points
  • Communication ports: 1 x RS - 232, 1 x RS - 485 (Modbus RTU)

AEG PC-E984-385

Technical Specifications:

  • Processor type: 16 - bit microprocessor optimized for industrial control
  • Instruction execution speed: 3 ms per 1000 basic instructions
  • User program memory: 16 KB EEPROM (expandable up to 32 KB)
  • Data memory: 2 KB RAM for real - time data storage and processing
  • Maximum I/O capacity: 512 digital I/O points or 64 analog I/O points (expandable via I/O racks)
  • Communication ports: 1 x RS - 232 port for programming and HMI communication, 1 x Modbus RTU port for network communication

AEG AS-P371-002

Technical Specifications:

  • Output voltage: 24 V DC (23.5 V DC - 24.5 V DC)
  • Output current: 20 A (continuous)
  • Input voltage: 110 V AC - 240 V AC (50/60 Hz)
  • Redundancy: N+1 configuration (supports two modules for backup)
  • Efficiency: 92% at full load
  • Ripple voltage: <50 mV
  • Overload protection: 120% of rated current (shuts down after 10 seconds)

AEG A14411

Technical Specifications:

  • Rated operational voltage (Ue): 400 V AC
  • Rated operational current (Ie): 10 A at 400 V AC
  • Number of poles: 4 poles (2 NO + 2 NC)
  • Coil voltage: 24 V DC, 220 V AC
  • Mechanical lifespan: 20 million operations
  • Electrical lifespan: 2 million operations at rated current
  • Operating temperature range: -25°C to +70°C
  • Degree of protection: IP20
  • Dimensions (W x H x D): 30 mm x 80 mm x 60 mm
  • Weight: 0.2 kg

AEG A18318

Technical Specifications:

  • Rated current range: 23 A - 32 A
  • Setting current: Adjustable from 23 A to 32 A
  • Trip class: Class 10 (trips within 10 seconds at 6 x rated current)
  • Phase loss protection: Built-in (trips within 2 seconds of phase failure)
  • Reset type: Manual and automatic reset options
  • Number of poles: 3 poles
  • Operating temperature range: -25°C to +70°C
  • Degree of protection: IP20
  • Dimensions (W x H x D): 50 mm x 100 mm x 80 mm
  • Weight: 0.4 kg

AEG A18370

Technical Specifications:

  • Rated operational voltage (Ue): 400 V AC, 50 Hz
  • Rated operational current (Ie): 95 A at 400 V AC (AC-3 duty)
  • Making capacity (Icm): 12 x Ie (1140 A) for 0.3 seconds
  • Breaking capacity (Ics): 10 x Ie (950 A) for 0.3 seconds
  • Coil voltage options: 24 V AC, 110 V AC, 220 V AC, 380 V AC
  • Number of poles: 3 NO (normally open)
  • Mechanical lifespan: 15 million operations
  • Electrical lifespan: 1 million operations at rated current
  • Operating temperature range: -25°C to +70°C
  • Degree of protection: IP20
  • Dimensions (W x H x D): 80 mm x 150 mm x 100 mm
  • Weight: 1.2 kg

AEG AS-5120-000

Technical Specifications:

  • Number of input channels: 16 isolated channels
  • Input signal type: 24 V DC (sink/source configurable)
  • Input current: 5 mA per channel
  • Response time: ≤1 ms
  • Isolation voltage: 500 V AC between channels and backplane
  • Operating voltage: 24 V DC (18 V DC - 30 V DC)
  • Power consumption: 2.5 W
  • Operating temperature range: -25°C to +70°C
  • Degree of protection: IP20
  • Dimensions (W x H x D): 35 mm x 100 mm x 120 mm
  • Weight: 0.2 kg

AEG POS011

Technical Specifications:

  • Number of position channels: 4 channels
  • Input signal types: Incremental encoder (A/B/Z phase), absolute encoder (SSI protocol)
  • Maximum input frequency: 500 kHz per channel
  • Position resolution: 32-bit counter (0 to 4294967295 counts)
  • Position update rate: 1 ms
  • Operating voltage: 24 V DC (18 V DC - 30 V DC)
  • Power consumption: 4 W
  • Operating temperature range: -25°C to +70°C
  • Degree of protection: IP20
  • Dimensions (W x H x D): 35 mm x 100 mm x 120 mm
  • Weight: 0.3 kg

AEG 6051-042.167619

Technical Specifications:

  • Supported protocols: Modbus RTU, Modbus TCP, Ethernet/IP, Profinet
  • Communication ports: 1 x RS-485 (Modbus RTU), 1 x Ethernet (RJ45, 10/100 Mbps)
  • Data transmission rate: RS-485 up to 115.2 kbps; Ethernet up to 100 Mbps
  • Number of network nodes: Up to 32 nodes on RS-485; 256 nodes on Ethernet
  • Operating voltage: 24 V DC (18 V DC - 30 V DC)
  • Power consumption: 4 W

AEG ALU286

Technical Specifications:

  • Processor core: 32-bit RISC architecture optimized for logic operations
  • Instruction set: Supports LD, FBD, IL, and ST programming languages
  • Data processing speed: 0.08 μs per logic operation
  • Data word length: 16-bit and 32-bit data handling
  • Memory interface: Direct access to PLC system RAM/Flash memory
  • Operating voltage: 5 V DC (supplied by the PLC backplane)
  • Power consumption: 2 W
  • Operating temperature range: 0°C to +60°C
  • Degree of protection: IP20
  • Dimensions (W x H x D): 25 mm x 80 mm x 100 mm
  • Weight: 0.15 kg
