AEG S74D-PB0-F0V0 S74D Series Profibus-DP Dedicated Fieldbus Gateway Module

  • Product Introduction: This is a Profibus-DP dedicated intelligent fieldbus gateway module of AEG S74D series, optimized for the Profibus-DP fieldbus system, realizing the protocol conversion and data exchange between Profibus-DP and Modbus RTU/TCP, Ethernet/IP and other mainstream industrial communication protocols. It is specially designed to expand the connection range of the Profibus-DP system, connect non-Profibus-DP standard industrial equipment to the Profibus-DP bus, and is a core device for the integration of the Profibus-DP bus system with other industrial control networks.
  • Technical Specifications:
    • Main Bus Interface: Profibus-DP V1, support 9.6 kbps-12 Mbps adaptive baud rate, up to 126 slave stations connected.
    • Expansion Interfaces: 2×Ethernet (10/100 Mbps RJ45, Modbus TCP/Ethernet/IP), 2×RS-485 (Modbus RTU), all ports independent.
    • Processor: 32-bit ARM industrial processor, operating frequency 168 MHz, with Profibus-DP dedicated communication driver.
    • Data Processing Capacity: Up to 800 Profibus-DP data points for simultaneous transmission, data update rate ≤5 ms.

AEG S74D-V00-F0V0 S74D Series Intelligent Fieldbus Gateway Module

  • Product Introduction: This is a high-performance intelligent fieldbus gateway module of AEG S74D series, designed for protocol conversion and data exchange between different industrial fieldbuses and industrial Ethernet in industrial automation systems. It supports multiple mainstream industrial communication protocols, realizes seamless data transmission between heterogeneous bus systems, and is a key device for solving the communication incompatibility problem between different brands and types of industrial equipment in intelligent factories.
  • Technical Specifications:
    • Supported Protocols: Modbus RTU/TCP, Profibus-DP, CANopen, Ethernet/IP, RS-232/485, 6 mainstream industrial communication protocols.
    • Communication Ports: 2×Ethernet (10/100 Mbps RJ45), 2×RS-485, 1×RS-232, 1×Profibus-DP, 1×CANopen, all ports work independently.
    • Processor: 32-bit ARM industrial processor, operating frequency 168 MHz, with dedicated protocol conversion algorithm.

AEG PCE984785 Modicon 984 Series PLC Programming & Communication Processor

  • Product Introduction: This is an integrated programming and communication processor dedicated to AEG Modicon 984 series medium and large PLC systems, integrating PLC program download/upload, online debugging and multi-protocol communication functions. It acts as a communication bridge between the PLC system and upper-level monitoring equipment (SCADA, HMI), programming equipment and lower-level field devices, and is a core functional module for realizing the networking, remote monitoring and program maintenance of the 984 series PLC system.
  • Technical Specifications:
    • Programming Interface: RS-232 (DB9), support AEG Modicon 984 dedicated programming protocol, transmission rate up to 115200 bps.
    • Fieldbus Interfaces: Profibus-DP V1, Modbus TCP/IP, RS-485 (Modbus RTU), 3 independent communication ports for simultaneous multi-protocol communication.
    • Processor: 16-bit industrial RISC processor, operating frequency 80 MHz, dedicated to communication data processing and protocol conversion.
    • Data Buffer: 256 KB dual-port RAM, for real-time caching of communication data, preventing data loss during high-speed transmission.
    • Connection Capacity: Profibus-DP up to 32 slave stations, Modbus TCP/IP up to 16 concurrent TCP connections, RS-485 up to 248 slave nodes.

AEG 6390-042.708853 Industrial Grade PLC Backplane Bus Extender Module

  • Product Introduction: This is a high-performance backplane bus extender module for AEG Modicon medium and large PLC systems, engineered to extend the transmission distance of the PLC chassis backplane bus and realize reliable data communication between multiple cascaded PLC chassis. It optimizes bus signal transmission, reduces signal attenuation and interference in long-distance transmission, and is a core accessory for building large-scale distributed industrial control systems with multi-chassis expansion requirements.
  • Technical Specifications:
    • Bus Compatibility: AEG Modicon 984/884 series high-speed parallel backplane bus, support 10 Mbps original bus rate.
    • Extension Distance: Single segment maximum 5 meters, up to 4 segments cascaded with a total extension distance of 20 meters.
    • Connection Interface: D-sub 25-pin male/female industrial connectors, gold-plated pins for low contact resistance.

AEG AS-BDA0-21 Digital-to-Analog Conversion Module

  • Product Introduction: This is a high-precision digital-to-analog (D/A) conversion module of the AEG Modicon series, designed for industrial control systems that require the conversion of digital signals to standard analog signals. It can convert the digital signals from various industrial controllers (PLC, DCS, industrial computer) into standard 4-20 mA current signals, and is a key interface module for realizing the connection between digital control systems and analog field actuators.
  • Technical Specifications:
    • Conversion Channels: 1 independent D/A conversion channel, dedicated to 4-20 mA current signal output.
    • Input Digital Signal: 12-bit binary parallel digital signal, compatible with TTL/CMOS level.
    • Output Analog Signal: 4-20 mA DC current signal, load capacity ≤500 Ω.
    • Conversion Resolution: 12 bits; Conversion Accuracy: ±0.05% of full scale at 25°C, ±0.1% over the entire operating temperature range.
    • Conversion Time: ≤50 μs; Signal Drift: ≤50 ppm/°C (temperature drift), ≤0.01% FS/year (time drift).
    • Isolation: 2500 VAC isolation between input and output, between output and power supply.

AEG PC-0984-780 Modicon 984 Series Programming Terminal

  • Product Introduction: This is a dedicated industrial programming terminal for the AEG Modicon 984 series medium and large PLC systems, integrating a high-performance industrial computer, dedicated programming software, and human-machine interaction interface. It is designed for the programming, debugging, online monitoring and fault diagnosis of the Modicon 984 series PLC system, and is a professional engineering tool for the design and maintenance of large-scale industrial control systems.
  • Technical Specifications:
    • Processor: Intel 80486 industrial-grade processor, operating frequency 66 MHz.
    • Memory: 8 MB RAM (expandable to 16 MB) + 128 MB industrial hard disk (for software and program storage).
    • Display: 10.4-inch industrial color TFT LCD screen, resolution 800×600 pixels, backlight life ≥50,000 hours.
    • Input Device: Industrial membrane keypad + trackball mouse, dustproof and waterproof, suitable for industrial field operation.

AEG 91-00911-05 Industrial PLC Communication Cable

  • Product Introduction: This is a dedicated industrial communication cable for AEG Modicon series PLC systems, designed for the data transmission between the PLC CPU module and programming equipment (programming station, laptop) or HMI touch screen. It adopts high-quality shielded twisted pair and industrial-grade connectors, featuring strong anti-interference performance and high transmission reliability, and is an important accessory for the Modicon PLC system to realize programming, debugging and on-site monitoring.
  • Technical Specifications:
    • Cable Type: High-quality shielded twisted pair (STP), with tinned copper braid shielding + aluminum foil shielding, shielding effectiveness ≥85 dB at 1 MHz.
    • Conductor Material: Tinned copper wire, 2-core, cross-sectional area 0.75 mm², high conductivity and corrosion resistance.

AEG MM-P10-200 MM Series Process Control Module

  • Product Introduction: This is a dedicated process control module of the AEG MM series, designed for industrial continuous process control systems, integrating multiple high-precision PID control loops, analog signal processing, and logic control functions. It can be connected to the AEG Modicon PLC system through the backplane bus or fieldbus, and is a key functional module for the PLC system to realize high-precision and multi-loop industrial process control.
  • Technical Specifications:
    • Number of PID Control Loops: 8 independent closed-loop PID control loops, support cascade, ratio, and feedforward control.
    • Analog Input: 8 channels, 12-bit resolution, support 0-10 VDC, 4-20 mA signals, accuracy ±0.1% FS.
    • Analog Output: 8 channels, 12-bit resolution, support 0-10 VDC, 4-20 mA signals, accuracy ±0.1% FS.
    • Digital I/O: 16 digital input (24 VDC) + 8 digital output (24 VDC) channels for interlock control and status monitoring.

AEG ARG 120-166-305 120 Series High-Torque Brushless Servo Motor

  • Product Introduction: This is a high-torque brushless permanent magnet servo motor of the AEG ARG 120 series, designed for heavy-duty industrial motion control applications. It is matched with AEG 120 series servo drivers to form a high-performance servo control system, featuring high torque density, low inertia, and high reliability, and can provide stable and large torque output at low speeds, which is the core execution component for heavy-duty industrial equipment to realize precise motion control.
  • Technical Specifications:
    • Rated Power: 3.0 kW; Rated Voltage: 380 VAC three-phase, 50/60 Hz.
    • Rated Current: 6.5 A; Peak Current: 19.5 A (3 seconds).
    • Rated Speed: 1500 rpm; Maximum Speed: 3000 rpm.
    • Rated Torque: 19.1 N·m; Peak Torque: 57.3 N·m.
    • Rotor Inertia: 0.0012 kg·m²; Motor Constant: 15 N·m/√kW.

AEG M907-000 Modicon 900 Series Memory Module

  • Product Introduction: This is a dedicated non-volatile memory module for the AEG Modicon 900 series PLC CPU modules, used to store user control programs, system configuration parameters, and important process data. It adopts advanced EEPROM and battery-backed RAM dual memory design, ensuring that the stored data will not be lost for a long time even when the power is off, and is an important functional module for the PLC system to realize program storage and data retention.
  • Technical Specifications:
    • Memory Type: 512 KB EEPROM (for program storage) + 256 KB battery-backed RAM (for data storage).
    • EEPROM Erase/Write Times: ≥100,000 times; Data Retention Time: ≥10 years (without power supply).
    • RAM Battery Type: Lithium battery, built-in, battery life ≥5 years (at 25°C).
    • Data Transmission Interface: Parallel interface, compatible with Modicon 900 series CPU backplane bus, data transmission rate up to 1 Mbps.

AEG 120-085-001 120 Series Servo Driver

  • Product Introduction: This is a high-performance digital servo driver of the AEG 120 series, specially matched with AEG 120 series servo motors to form a complete servo control system. It adopts advanced vector control algorithm, which can realize high-precision position, speed and torque closed-loop control, and is the core drive component for industrial equipment to realize precise motion control.
  • Technical Specifications:
    • Input Voltage: 220 VAC single-phase/three-phase selectable, 50/60 Hz, voltage tolerance ±10%.
    • Rated Output Power: 1.5 kW; Rated Output Current: 7.0 A; Peak Output Current: 21.0 A (3 seconds).
    • Control Modes: Position control (pulse/direction, CW/CCW), speed control (analog voltage, communication), torque control (analog voltage, communication).
    • Positioning Accuracy: ±1 pulse; Speed Regulation Range: 1:10000 (0.1 rpm to 3000 rpm).

AEG AS-9584-000 Modicon 984 Series PLC Chassis

  • Product Introduction: This is a dedicated rack chassis and backplane bus module for the AEG Modicon 984 series medium and large PLC systems, providing a standardized mechanical installation space and high-speed data transmission bus for the 984 series CPU, I/O, communication, and functional modules. It adopts a modular backplane design, supports multi-chassis expansion, and is the core hardware carrier for building large-scale industrial control systems.
  • Technical Specifications:
    • Number of Module Slots: 8 standard slots, compatible with all Modicon 984 series I/O and functional modules.
    • Backplane Bus Type: High-speed parallel bus, data transmission rate up to 10 Mbps.
    • Bus Power Supply: 24 VDC, provided by an external dedicated power supply module (AS-S908 series recommended).
