AEG AS-9508-000 Modicon 9508 Series Main Chassis for High-Density I/O Control

  • Product Introduction: This is the main chassis of the AEG Modicon 9508 series PLC system, designed to accommodate multiple CPU, I/O, communication, and power supply modules for building large-scale, high-performance industrial automation control systems. It features a robust backplane bus, high-power distribution capacity, and hot-swappable module support, enabling flexible configuration and easy maintenance, making it a core component for large industrial control applications requiring high I/O density and reliable performance.
  • Technical Specifications:
    • Slot Configuration: 8 slots for modules (2 CPU slots, 6 I/O/communication slots), supporting mixed installation of various Modicon 9508 series modules.
    • Backplane Bus: 32-bit data bus, transmission rate 100 Mbps, ensuring fast data exchange between modules.
    • Power Distribution: 24 VDC input, 10 A total power output, with overvoltage, overcurrent, and reverse polarity protection.
    • Dimensions: 483mm × 356mm × 229mm (W×H×D); Mounting: 19-inch rack-mounted (13U height), compatible with standard industrial racks.

AEG 7628-042.244800 Modicon Secondary Electrical Supply Rack for I/O Expansion

  • Product Introduction: This is a secondary electrical supply rack designed for AEG Modicon DTA series PLC systems, serving as a dedicated mounting and power distribution unit for I/O modules and auxiliary components. It provides a stable power supply and a reliable backplane bus connection for expanding the I/O capacity of Modicon PLC systems, allowing seamless integration of additional I/O modules to meet the requirements of medium to large-scale industrial automation applications with high I/O density needs.
  • Technical Specifications:
    • Type: Secondary rack for DTA series, supporting up to 5 I/O modules for expansion.
    • Backplane Bus: Compatible with Modicon DTA series backplane protocol, ensuring high-speed data transfer between modules and the main PLC chassis.
    • Power Distribution: Input voltage 24 VDC, power output per slot 5 A, total power capacity 25 W.
    • Dimensions: 483mm × 178mm × 127mm (W×H×D); Mounting: 35mm DIN rail or rack-mounted, compatible with standard industrial control cabinet installation.

AEG 520VPU19200 Modicon Handheld Operator Module for Industrial Control

  • Product Introduction: This is a dedicated handheld operator module for AEG Modicon PLC systems, engineered to enable on-site personnel to perform real-time monitoring, parameter modification, program debugging, and fault diagnosis of Modicon PLC systems without relying on a fixed control station or desktop computer. It integrates a clear display, a durable keypad, and multiple communication interfaces, supporting direct connection to Modicon PLCs for seamless data exchange, making it an essential tool for field maintenance and operational control of industrial automation systems.
  • Technical Specifications:
    • Display: 4-line monochrome LCD with LED backlight, 20 characters per line, adjustable brightness, horizontal/vertical viewing angle ≥120°.
    • Input Device: 36-key industrial membrane keypad, including numeric, function, navigation, and confirmation/escape keys, dustproof and wear-resistant.
    • Communication Interfaces: 1×RS-232 (Modicon proprietary protocol), 1×RS-485 (Modbus RTU), transmission rate 300-115200 bps (configurable).

AEG 100-304 Industrial Grade Proximity Sensor

  • Product Introduction: This is an 8 mm sensing distance NPN normally open (NO) inductive proximity sensor of AEG, specially designed for the non-contact detection of metal objects in industrial automation systems. It adopts high-frequency oscillation induction technology, plastic enclosure and flush mounting design, with high detection precision, fast response speed and strong anti-interference performance, and is a core sensing component for realizing non-contact position detection, speed detection and counting of metal objects in industrial control systems.
  • Technical Specifications:
    • Detection Principle: High-frequency oscillation inductive, non-contact metal object detection, no contact wear.
    • Sensing Distance: 8 mm (nominal, steel S45C), repeat accuracy ±2% of nominal distance.
    • Detection Object: Ferromagnetic metals (steel, iron, nickel) with high sensitivity, non-ferromagnetic metals (copper, aluminum) with reduced distance (50% of nominal).
    • Output Type: NPN normally open (NO), transistor output, sinking type, output current 200 mA (rated), 500 mA (peak).

AEG MEF004 Industrial Grade Frequency Converter

  • Product Introduction: This is a 0.75 kW 3-phase 380 VAC small-power industrial grade frequency converter of AEG, specially designed for the speed control of small-power three-phase asynchronous motors in industrial automation systems. It adopts vector control technology, with high speed control precision, good dynamic performance and comprehensive protection functions, realizing the stepless speed regulation of the motor, energy saving and consumption reduction, and reducing the mechanical impact of the motor start and stop, and is a core speed control component for small-power motor speed control in industrial control systems.
  • Technical Specifications:
    • Rated Power: 0.75 kW; Input Voltage: 3-phase 380 VAC ±10%, 50/60 Hz.
    • Output Voltage: 3-phase 0-380 VAC (PWM modulation); Output Current: 2.5 A (rated), 5 A (1-minute overload).
    • Control Mode: V/F control, open-loop vector control (SV-PWM), torque control (optional), speed control precision ±0.5% of rated speed.
    • Frequency Range: 0.1-400 Hz, frequency resolution 0.01 Hz (digital), 0.1 Hz (analog).
    • Start Torque: 150% rated torque at 0.5 Hz (open-loop vector control), 200% rated torque at 5 Hz.
    • Acceleration/Deceleration Time: 0.1-3600 s (adjustable, linear/S-curve).

AEG 6051-042.23966 Industrial Grade Pressure Transmitter

  • Product Introduction: This is a high-precision industrial grade pressure transmitter of AEG, with a measured pressure range of 0-10 bar and a standard 4-20 mA current output signal, specially designed for the on-line measurement of gauge pressure of gas, liquid and steam media in industrial process control systems. It adopts a diffused silicon pressure sensor core, stainless steel measuring diaphragm and digital temperature compensation technology, with high measurement accuracy, good stability and strong anti-interference performance, and is a core sensing component for the pressure parameter detection of industrial process control systems.
  • Technical Specifications:
    • Measured Medium: Clean gas, liquid, steam (≤150°C), non-corrosive and non-crystallizing medium.
    • Measuring Range: 0-10 bar (gauge pressure), optional range 0-1 bar to 0-100 bar (customizable).
    • Output Signal: 4-20 mA DC two-wire system, load resistance 0-750 Ω (24 VDC power supply).
    • Measurement Accuracy: ±0.1% of full scale (FS) at 25°C, ±0.2% FS over -10°C to +80°C.
    • Zero/Span Adjustment: Digital adjustment (via HART protocol), no mechanical adjustment, high precision.
    • Temperature Compensation: -10°C to +80°C, digital temperature compensation technology, small temperature drift.

AEG 100-265-816 Industrial Grade Solenoid Valve

  • Product Introduction: This is a 2/2 way normally closed (NC) industrial grade solenoid valve of AEG, with 24 VDC solenoid coil, specially designed for the on-off control of gas, liquid and steam media in industrial fluid control systems. It adopts a stainless steel valve body, brass valve core and high-sealing rubber seal, with high pressure resistance, good sealing performance and long service life, and is a core fluid control component for realizing the on-off control of industrial fluid pipelines.
  • Technical Specifications:
    • Valve Type: 2/2 way normally closed (NC), direct-acting structure (no minimum pressure difference required).
    • Nominal Diameter (DN): 8 mm; Connection Method: G1/4 external thread (BSP), quick connection (optional).
    • Medium: Clean gas, water, oil, steam (≤180°C), non-corrosive liquid/gas, viscosity ≤20 cSt.
    • Working Pressure: 0-16 bar (liquid/gas), 0-10 bar (steam); Pressure Drop: ≤0.5 bar (full flow).
    • Flow Coefficient (Cv): 0.8; Response Time: ≤10 ms (open), ≤8 ms (close).

AEG PC-Z984-785 Modicon 984 Series Industrial Field Programming Terminal

  • Product Introduction: This is a portable industrial field programming terminal dedicated to AEG Modicon 984 series medium and large PLC systems, integrating program editing, online debugging, parameter setting, system status monitoring and fault diagnosis functions. It features a compact and lightweight handheld design, rugged industrial structure, and built-in multi-communication interface, realizing on-site offline programming and online real-time debugging of the Modicon 984 series PLC without the need for a desktop computer, and is a professional on-site maintenance and debugging tool for the Modicon 984 series PLC system in the industrial field.
  • Technical Specifications:
    • Display: 4-line monochrome LCD, 20 characters per line, LED backlight (dimmable), suitable for low-light field environment.
    • Input Device: 36-key industrial membrane keypad, including numeric keys, function keys, editing keys, navigation keys, dustproof, anti-wear and anti-vibration.
    • Communication Interfaces: 1×RS-232 (Modicon dedicated protocol), 1×RS-485 (Modbus RTU), 1×Ethernet (10/100 Mbps, Modbus TCP/IP), transmission rate up to 115200 bps.
    • Memory: 1 MB Flash for program and configuration storage, support up to 20 Modicon 984 PLC program files, battery-backed data storage.

AEG AS-J892-101 Modicon High-Speed Counter Module

  • Product Introduction: This is an 8-channel high-speed counter module for AEG Modicon 890 series PLC systems, specially designed for the high-speed counting, speed detection and position measurement of industrial field pulse signals from encoders, proximity sensors and other pulse generating devices. It supports a maximum counting frequency of 100 kHz per channel, multiple counting modes and high-speed comparison output, and is a core functional module for realizing high-precision motion control, speed control and position control of the Modicon PLC control system.
  • Technical Specifications:
    • Counting Channels: 8 independent high-speed counting channels, each channel supports single-ended pulse input.
    • Counting Frequency: Max 100 kHz per channel (5 VDC/24 VDC pulse signal), support low-frequency pulse (≥1 Hz) compatible counting.
    • Input Signal Type: 5 VDC TTL level, 24 VDC NPN/PNP level (configurable per channel), differential input (optional).
    • Counting Modes: Up counting, down counting, up/down counting (direction signal input), pulse/direction, A/B phase quadrature (1×/2×/4× multiplication).

AEG AS-P890-000 Modicon Process Control CPU Module

  • Product Introduction: This is a high-performance process control dedicated CPU module for AEG Modicon 890 series PLC systems, specially designed for complex industrial process control scenarios such as continuous production, batch production and multi-parameter collaborative control. It adopts a 32-bit high-speed industrial processor, large-capacity memory and dedicated process control algorithm library, supports high-precision analog signal processing and complex logic control, and is the core control component for building high-performance industrial process control systems with Modicon PLCs.
  • Technical Specifications:
    • Processor: 32-bit RISC industrial high-speed processor, operating frequency 200 MHz, dedicated for process control.
    • Memory: 2 MB user program memory (Flash, non-volatile), 1 MB data memory (RAM, battery-backed), 512 KB process data cache.
    • I/O Capacity: Max 8192 digital I/O points, 1024 analog I/O points, support hot swapping of I/O modules.
    • Analog Processing: 16-bit high-precision analog signal processing, support floating-point arithmetic, sampling rate ≤1 ms per channel.

AEG TXT122 Industrial Grade Text HMI Terminal

  • Product Introduction: This is a compact industrial grade text HMI terminal of AEG, with a 2-line monochrome LCD display and industrial membrane keypad, specially designed for on-site operation, parameter setting and status monitoring of AEG Modicon small and medium-sized PLC systems. It features a simple and intuitive operation interface, fast communication with PLC, and rugged industrial design, realizing the human-computer interaction of the PLC control system without the need for a large screen HMI, and is a cost-effective human-computer interaction device for small and medium-sized industrial control systems.
  • Technical Specifications:
    • Display: 2-line monochrome LCD, 16 characters per line, LED backlight (adjustable brightness), viewing angle ≥120° (horizontal/vertical).
    • Input Device: 20-key industrial membrane keypad, including numeric keys, function keys, confirmation/esc keys, dustproof and anti-wear.
    • Communication Interface: 1×RS-232, 1×RS-485 (Modbus RTU/AEG Modicon dedicated protocol), transmission rate 300-115200 bps (configurable).

AEG 120-082-005 Industrial Grade PLC Power Supply Module

  • Product Introduction: This is a dedicated industrial grade switching power supply module for AEG Modicon PLC chassis, with a rated output of 24 VDC/5 A, specially designed to provide stable and reliable DC power supply for Modicon PLC modules (I/O, communication, CPU). It adopts high-efficiency switching power supply technology, with comprehensive protection functions and wide input voltage range, adapting to the unstable power grid environment of industrial sites, and is an essential power supply component for ensuring the stable operation of Modicon PLC systems.
  • Technical Specifications:
    • Input Voltage: 115/230 VAC selectable (50/60 Hz), voltage tolerance ±20%, support DC 120/240 VDC input (optional).
    • Output Voltage: 24 VDC ±1%, rated output current 5 A, maximum output power 120 W.
    • Ripple and Noise: ≤50 mV p-p (20 MHz bandwidth), output voltage stability ≤0.5%.
    • Conversion Efficiency: ≥88% (full load), no-load power consumption ≤1 W.
    • Protection Functions: Overvoltage protection (OVP), overcurrent protection (OCP), short-circuit protection (SCP), overheating protection (OTP), all protection functions self-recovering.
