AEG 140CPS21400 Modicon 24 VDC Power Supply Module

  • Product Introduction: This is a high-capacity 24 VDC power supply module for AEG Modicon Quantum series PLC systems, delivering 10 A of continuous power to the PLC chassis and installed modules. It features redundant operation support, overvoltage/overcurrent protection, and a wide input voltage range, ensuring stable power delivery in critical industrial applications. It is designed to maintain system uptime in mission-critical environments like power generation, petrochemical refineries, and data centers.
  • Technical Specifications:
    • Input Voltage: 100-240 VAC (50/60 Hz), wide range for global compatibility.
    • Output Voltage: 24 VDC, adjustable ±5% (22.8-25.2 VDC), regulated for stable operation.
    • Output Current: 10 A continuous, 15 A peak (10 s), supporting multiple high-power modules.
    • Redundancy: N+1 redundant configuration support, with hot-swappable capability for zero downtime maintenance.
    • Protection: Overvoltage (30 VDC), overcurrent (12 A), short-circuit, and reverse polarity protection.
    • Efficiency: ≥90% at full load, reducing energy consumption and heat generation.

AEG ADU216 Modicon Analog Input/Output Universal Module

  • Product Introduction: This is a dual-function analog I/O module for AEG Modicon 800 series PLC systems, combining 8 analog input channels and 8 analog output channels in a single unit. It supports 4-20 mA/0-10 VDC signals for both input and output, with 16-bit resolution and channel isolation. It is designed to streamline system integration by reducing the number of modules needed, ideal for industrial automation systems requiring balanced analog I/O for monitoring and control, such as building management, process control, and material handling.
  • Technical Specifications:
    • Input Channels: 8 channels, configurable for 4-20 mA DC or 0-10 VDC, 16-bit resolution, accuracy ±0.05% FS.
    • Output Channels: 8 channels, configurable for 4-20 mA DC or 0-10 VDC, 16-bit resolution, accuracy ±0.05% FS.
    • Input Range: 4-20 mA (250 Ω impedance), 0-10 VDC (10 kΩ impedance); Output Range: 4-20 mA (750 Ω max load), 0-10 VDC (20 mA max load).
    • Isolation: 2500 VAC between I/O channels and backplane, 1500 VAC between channels.
    • Update Rate: 1 ms per channel (input/output), ensuring real-time data transfer.

AEG AS-B873-001 Modicon 8-Channel Analog Input Module

  • Product Introduction: This is an 8-channel universal analog input module for AEG Modicon 800 series PLC systems, designed to measure temperature via thermocouples (Type J/K/T/E/R/S/B/N) and RTDs (PT100/PT1000). It features 16-bit resolution, cold junction compensation, and channel isolation to convert temperature signals into digital data for the PLC CPU. It is optimized for industrial temperature monitoring in processes where precise thermal control is critical, such as chemical reactors, furnaces, and material processing lines.
  • Technical Specifications:
    • Input Channels: 8 independent channels, each configurable for thermocouple (J/K/T/E/R/S/B/N) or RTD (PT100/PT1000, 2/3/4-wire) inputs.
    • Resolution: 16-bit (65536 discrete values) for all input types, ensuring fine temperature measurement.
    • Thermocouple Range: -200°C to +1800°C (model-dependent), with cold junction compensation (CJC) accuracy ±0.5°C.
    • RTD Range: -200°C to +850°C (PT100), -50°C to +200°C (PT1000), 3-wire configuration to eliminate lead resistance error.
    • Accuracy: ±0.1°C at 0°C (PT100), ±0.2% FS for thermocouples, ±0.1% FS over -25°C to +70°C.

AEG AS-B881-001 Modicon 4-Channel Analog Output Module

  • Product Introduction: This is a 4-channel universal analog output module for AEG Modicon 800 series PLC systems, engineered to convert digital control signals from the PLC CPU into precise 0-10 VDC voltage or 0-20 mA current outputs. It delivers 16-bit resolution, channel isolation, and low drift performance to drive industrial actuators like variable frequency drives (VFDs), control valves, and positioners. It is designed for applications requiring fine-tuned analog control of process parameters such as flow, pressure, and speed in industrial environments.
  • Technical Specifications:
    • Output Channels: 4 independent channels, each configurable for 0-10 VDC or 0-20 mA output (per-channel selection).
    • Resolution: 16-bit (65536 discrete values) for both voltage and current outputs.
    • Accuracy: ±0.05% FS at 25°C, ±0.1% FS over -25°C to +70°C, ensuring precise signal conversion.
    • Voltage Output: 0-10 VDC, output impedance 10 Ω, maximum load current 20 mA.
    • Current Output: 0-20 mA, input impedance 250 Ω, maximum load resistance 750 Ω (at 24 VDC supply).
    • Isolation: 2500 VAC between channels and backplane, 1500 VAC between channels.

AEG AS-BDAP-218 Modicon 16-Channel Discrete Output Module

  • Product Introduction: This is a 16-channel discrete output module designed for AEG Modicon 800 series PLC systems, built to switch high-voltage AC loads in industrial automation processes. It uses triac switching elements for fast, solid-state control of 24-240 VAC circuits, with channel isolation and overload protection to drive contactors, solenoid valves, and other industrial actuators reliably in harsh environments. It integrates seamlessly with Modicon PLC backplanes for real-time output signal execution from the CPU, serving as a critical interface for PLC-to-field device control.
  • Technical Specifications:
    • Output Channels: 16 independent channels, each with triac switching for 24-240 VAC AC loads.
    • Switching Type: Triac (solid-state), zero-crossing switching to reduce electrical noise and inrush current.
    • Rated Current: 0.5 A per channel (continuous), 2 A peak (50 ms), resistive load.
    • Voltage Range: 24-240 VAC, 50/60 Hz, compatible with global industrial power standards.
    • Isolation: 2500 VAC between channels and backplane, 1500 VAC between adjacent channels to prevent cross-interference.

AEG 6065-042.244724 Industrial Grade Temperature Transmitter

  • Product Introduction: This is a high-precision industrial grade temperature transmitter from AEG, specially designed for on-line temperature measurement and signal conversion of industrial process media, supporting PT100 platinum thermal resistance input and standard 4-20 mA current output, with a measurable temperature range of -50°C to +200°C. It adopts a microprocessor-based intelligent signal processing circuit, digital temperature compensation technology and anti-interference design, with high measurement accuracy, good long-term stability and strong anti-interference performance, and is a core temperature sensing component for Modicon PLC and other industrial control systems to realize on-line temperature monitoring and control of industrial process parameters.
  • Technical Specifications:
    • Sensing Input: PT100 platinum thermal resistance (3-wire connection, eliminating lead resistance error), support PT1000 (optional) input.
    • Measuring Range: -50°C to +200°C (configurable via software, optional range -200°C to +600°C for high temperature type).
    • Output Signal: 4-20 mA DC two-wire system, proportional to the measured temperature, 4 mA corresponding to the lower limit of the range, 20 mA corresponding to the upper limit of the range.
    • Measurement Accuracy: ±0.1°C at 0°C, ±0.2% of measured value over the entire range (-50°C to +200°C), total error ≤0.3°C.

AEG KP1-C05 SEAB Industrial Grade Compact Push Button Station

  • Product Introduction: This is a 5-button compact industrial push button station from AEG, specially designed for on-site manual operation and control of industrial equipment and automation systems in harsh industrial environments. It features a rugged metal enclosure, IP65 high protection rating, and pre-wired internal wiring, with a variety of button function options (start/stop/emergency stop/reset), and is an essential on-site human-machine operation component for realizing local manual control, emergency operation and fault reset of industrial equipment.
  • Technical Specifications:
    • Button Configuration: 5 physical buttons (customizable function), including 4 standard push buttons (momentary/latching) + 1 emergency stop button (mushroom head, latching), button color optional (red/green/yellow/blue/black).
    • Button Type: Standard button: momentary (NO/NC contact) or latching (NO/NC contact), mechanical life ≥10 million times; Emergency stop button: mushroom head latching, red, mechanical life ≥5 million times, with one-key reset function.
    • Electrical Parameters: Rated voltage 24 VDC/250 VAC, rated current 5 A (resistive load), contact type: silver alloy contact, 1 NO + 1 NC per standard button, 2 NC for emergency stop button.

AEG 170-BDM-344-00 Modicon Momentum I/O Base Module

  • Product Introduction: This is a 4-slot industrial-grade I/O base module for AEG Modicon Momentum series distributed I/O systems, serving as the physical carrier and bus communication hub for Momentum series I/O modules, communication modules and functional modules. It features a compact modular design, high-speed internal bus, and multiple communication interface options, supporting flexible expansion of distributed I/O points and seamless connection with the main PLC system, and is a core hardware component for building Modicon Momentum decentralized I/O control networks in industrial field environments.
  • Technical Specifications:
    • Slot Configuration: 4 standard slots for Modicon Momentum series I/O modules (digital/analog), communication modules and special function modules, supporting hot swapping of modules.
    • Internal Bus: Modicon Momentum dedicated high-speed bus, transmission rate 1 Mbps, ensuring fast data exchange between installed modules.
    • Communication Interfaces: 1×RS-485 (Modbus RTU), 1×Ethernet (10/100 Mbps, Modbus TCP/IP), 1×PROFIBUS-DP (slave), supporting connection with main PLC and upper-level control system.
    • I/O Capacity: Max 128 digital I/O points or 16 analog I/O points per base module (depending on the installed I/O modules).

AEG AS-B883-01 Modicon 4-Channel Analog Output Module

  • Product Introduction: This is a 4-channel universal analog output module for AEG Modicon 800 series PLC systems, specially designed to convert the digital control signals of the PLC CPU into standard analog signals (4-20 mA DC/0-10 VDC) to drive industrial field actuators such as frequency converters, electric regulating valves, and servo drivers. It features 16-bit high-resolution D/A conversion, independent channel configuration, and high output stability, and is an essential analog control component for Modicon PLC systems to realize continuous regulation of industrial process parameters.
  • Technical Specifications:
    • Output Channels: 4 independent channels, each channel configurable for 4-20 mA DC current output or 0-10 VDC voltage output (one-to-one configuration).
    • Resolution: 16-bit for both current and voltage output, 65536 discrete output values for precise analog control.
    • Output Range Accuracy: ±0.05% of full scale (FS) at 25°C for 4-20 mA; ±0.1% FS at 25°C for 0-10 VDC; total error ≤0.2% FS over -25°C to +70°C.
    • Output Drive Capacity: 4-20 mA channel: maximum load resistance 750 Ω; 0-10 VDC channel: maximum load current 20 mA, output impedance ≤10 Ω.

AEG AS-MEEP-000 Modicon Ethernet Expansion Module for Remote I/O

  • Product Introduction: This is an industrial-grade Ethernet expansion module exclusively for AEG Modicon PLC systems, developed to build distributed industrial automation control networks by realizing high-speed, stable data transmission between the main PLC chassis and remote I/O stations via industrial Ethernet. It breaks through the spatial limitation of traditional wired I/O connections, supports large-scale remote I/O point access, and is a core networking component for Modicon PLC systems to realize decentralized control and centralized management in large industrial sites such as factory production lines, logistics parks and municipal engineering.
  • Technical Specifications (supplemented):
    • Data Transmission Latency: ≤5 ms for real-time data, ensuring the synchronicity of remote I/O control.
    • Network Topology Support: Star, daisy chain, ring (with redundant function), adapting to different industrial network layout requirements.
    • Redundancy Function: Support Ethernet port redundancy and network power supply redundancy, ensuring communication continuity after single point of failure.

AEG MPV 003 203608 Modicon Motor Protection Relay

  • Product Introduction: This is a 3-phase motor protection relay from AEG, engineered to safeguard three-phase asynchronous motors against common electrical faults including overload, phase loss, phase imbalance, and overheating. It utilizes advanced electronic sensing and microprocessor-based control to provide precise and fast protection, ensuring the longevity of motors and minimizing downtime in industrial applications.
  • Technical Specifications:
    • Protection Current Range: 0-30 A, adjustable in 1 A increments.
    • Protection Functions: Overload, phase loss, phase imbalance (≤20% difference), overheating, and short-circuit protection.
    • Trip Characteristics: No trip at 1.05×rated current (2 hours), trip at 1.2×rated current (2 minutes), instant trip at 6×rated current.
    • Contact Rating: 2 NC/1 NO auxiliary contacts, 250 VAC/5 A, 30 VDC/2 A.

AEG AS-B872-200 Modicon 8-Channel Analog Input Module

  • Product Introduction: This is an 8-channel analog input module for AEG Modicon 800 series PLC systems, specifically designed to accurately collect and convert analog signals from industrial sensors (such as temperature, pressure, flow, and level sensors) into digital data for processing by the PLC CPU. It features 16-bit high-resolution conversion, channel isolation, and advanced noise reduction capabilities, ensuring precise and reliable acquisition of analog process parameters in harsh industrial environments.
  • Technical Specifications:
    • Input Channels: 8 independent channels, each configurable for 4-20 mA DC current input.
    • Resolution: 16-bit, providing 65536 discrete values for precise signal measurement.
    • Input Range: 4-20 mA DC, input impedance 250 Ω per channel.
    • Accuracy: ±0.05% of full scale (FS) at 25°C, ±0.1% FS over -25°C to +70°C.
