AEG AS-02MP-000 Modicon Auxiliary Motion & Process Processing Module

• Product Introduction: This is a dedicated auxiliary processing and interface module for AEG Modicon 800 series PLC systems, engineered to offload specialized motion control and complex process calculation tasks from the main PLC CPU, enhancing the overall system’s processing efficiency and real-time performance. It integrates a dedicated motion processing core, analog/digital signal preprocessing circuits, and high-speed I/O interfaces, supporting simple motion control (single-axis positioning, speed regulation) and advanced process data analysis (filtering, scaling, PID pre-calculation). The module acts as a co-processor for the main CPU, enabling the Modicon 800 series to handle mixed control tasks of logic, motion, and process in industrial automation scenarios, and is a key expansion component for improving the PLC system’s multi-task processing capability.
• Technical Specifications:
  • Processing Core: 16-bit dedicated motion/process processor, operating frequency 40 MHz, independent of the main CPU.
  • Supported Control Tasks: Single-axis stepper/servo motor positioning, speed regulation (0-5000 RPM), analog signal preprocessing (filtering, linearization, scaling), PID loop pre-calculation (up to 8 loops).
  • High-Speed I/O Interfaces: 2×high-speed pulse output (PTO, 0-100 kHz) for motion control, 2×high-speed counter input (0-100 kHz, incremental encoder compatible).

AEG Modicon AS-02MP-000 Auxiliary Processing Circuit Board

Functional Features

• Stable Signal Processing: Capable of sorting, buffering, and distributing signals inside the industrial control system. It ensures smooth communication between controllers and accurate execution of instructions, reducing signal interference and transmission errors in complex industrial electromagnetic environments.
• Clear Functional Positioning: It can serve as an interface adapter, data transmission hub, or functional expansion unit according to actual application requirements. It can effectively connect the main control board with external devices, realizing data exchange and functional extension.
• Industrial - Grade Reliability: Adopting high - temperature - resistant and anti - interference electrical structure design. It can maintain stable performance in harsh industrial sites with strong electromagnetic interference, high temperature, and high humidity, and has a long service life.
• Compact and Easy Integration: The small - sized layout allows for easy installation inside the rack or next to other control modules. It can be seamlessly integrated with the Modicon series control system without occupying excessive space.
• Simple Maintenance: The modular design enables plug - and - play replacement. When a fault occurs, the board can be quickly replaced by plugging and unplugging it on the rack or motherboard, greatly improving maintenance efficiency and reducing system downtime.
• Low Power Consumption: The power consumption is less than 2W during operation, which helps to reduce the overall power consumption of the control system and meet the energy - saving requirements of modern industrial equipment.

AEG DAU104 Modicon 4-Channel Digital-to-Analog Conversion Module

• Product Introduction: This is a 4-channel digital-to-analog conversion module designed for AEG Modicon 800 series PLC systems, converting digital control signals from the PLC CPU into precise 4-20 mA current or 0-10 VDC voltage output signals. It features 16-bit resolution, channel isolation, and overload protection, ensuring accurate and stable signal transmission to field actuators, such as control valves, variable frequency drives (VFDs), and positioners. It integrates seamlessly with Modicon PLC backplanes, providing a reliable interface for continuous process parameter control in industrial automation applications.
• Technical Specifications:
  • Output Channels: 4 independent channels, each configurable for 4-20 mA DC current or 0-10 VDC voltage output.
  • Resolution: 16-bit (65536 discrete values), ensuring fine control of output signals.
  • Accuracy: ±0.05% full scale (FS) at 25°C, ±0.1% FS over the operating temperature range (-25°C to +70°C).
  • Current Output: 4-20 mA, maximum load resistance 750 Ω, ensuring no signal attenuation over long cable runs.
  • Voltage Output: 0-10 VDC, output impedance 10 Ω, maximum load current 20 mA.
  • Isolation: 2500 VAC between channels and backplane, 1500 VAC between adjacent channels to prevent cross-interference.

AEG 110CPU61210 Modicon Micro 612 Programmable Logic Controller (PLC) CPU Module

• Product Introduction: This is a high-performance CPU module designed for AEG Modicon 110 Micro series PLC systems, serving as the core processing unit for industrial automation control. It integrates a 32-bit microprocessor, 256 KB user memory, and multiple communication interfaces, supporting IEC 61131-3 programming languages (LD, FBD, ST, IL, SFC). It is built to execute control logic, process I/O signals, and communicate with external devices in real time, providing a reliable and scalable control solution for small to medium-sized industrial automation applications, such as machine control, material handling, and process monitoring.
• Technical Specifications:
  • Processor: 32-bit RISC microprocessor, operating frequency 50 MHz, ensuring fast logic execution and data processing.
  • Memory: 256 KB user program memory, 128 KB data memory, expandable to 512 KB via optional memory modules.
  • I/O Capacity: Supports up to 512 digital I/O points or 64 analog I/O points via expansion modules.
  • Communication Interfaces: 1×RS-232 (Modbus RTU), 1×RS-485 (Modbus RTU, multi-drop up to 32 devices), 1×Ethernet (10/100 Mbps, Modbus TCP/IP).

AEG 170BDI34600 Modicon Momentum 32-Channel Digital Input Module

• Product Introduction: This is a 32-channel digital input module for AEG Modicon Momentum series distributed I/O systems, designed to collect discrete signals from industrial sensors in distributed automation environments. It supports 24 VDC sink (NPN) input, with channel isolation and noise immunity, ideal for high-density input applications in remote field locations, such as oil and gas pipelines, water treatment plants, and mining operations.
• Technical Specifications:
  • Input Channels: 32 independent channels, sink (NPN) configuration, 24 VDC input.
  • Input Voltage: 24 VDC (18-30 VDC range), input current 5 mA per channel.
  • Isolation: 2500 VAC between channels and backplane, 1500 VAC between channels.
  • Response Time: ≤1 ms (on/off), ensuring fast signal detection.
  • Noise Immunity: ±2 kV surge protection, CMRR ≥120 dB.
  • Power Supply: 24 VDC from Momentum base module, power consumption ≤5 W.

AEG AM-SA85-000 Modicon Serial Communication Module

• Product Introduction: This is a dual-port serial communication module for AEG Modicon 800 series PLC systems, enabling data exchange between the PLC and external devices (HMI, sensors, VFDs, SCADA systems) via RS-232 and RS-485 interfaces. It supports Modbus RTU/ASCII protocols, with baud rates up to 115200 bps and multi-drop capability, ideal for integrating legacy serial devices into modern industrial networks.
• Technical Specifications:
  • Interfaces: 1×RS-232 (DB9), 1×RS-485 (screw terminal), auto-sensing for Modbus RTU/ASCII.
  • Protocols: Modbus RTU, Modbus ASCII, configurable via programming software.
  • Baud Rates: 300-115200 bps (configurable), parity (none/even/odd), data bits (7/8), stop bits (1/2).
  • Multi-Drop: RS-485 supports up to 32 devices on a single bus, line length up to 1200 meters.
  • Isolation: 2500 VAC between interfaces and backplane, surge protection ±2 kV.
  • Processor: 32-bit communication processor, dedicated to protocol handling.
