AEG 3185996 Series Industrial PLC Cable Assembly

  • Product Introduction: AEG 3185996 is a high-quality industrial shielded cable assembly exclusively designed for connecting Modicon PLC main chassis to remote I/O racks in industrial automation systems. The cable features heavy-duty shielded construction, industrial-grade connectors and a rugged outer jacket, engineered to deliver reliable high-speed data transmission while resisting electrical interference, mechanical damage, oil and moisture in harsh industrial environments. It is pre-terminated with factory-installed connectors for plug-and-play installation, eliminating on-site wiring errors and ensuring consistent performance across Modicon automation systems. It is a critical interconnect component for distributed I/O systems, enabling reliable communication between the central PLC and remote field I/O in large-scale industrial applications.
  • Technical Specifications:
    • Cable Type: Multi-core shielded twisted pair cable (for data) + power conductors (for remote I/O power)
    • Number of Conductors: 8 twisted pairs (data) + 4 power conductors (24 V DC + GND), 12 total conductors
    • Conductor Gauge: 22 AWG (data conductors, tinned copper); 18 AWG (power conductors, tinned copper) – high conductivity and corrosion resistance
    • Shielding: Double shielding – foil shield (individual twisted pairs) + braided copper shield (overall cable) – 100% coverage for maximum EMC protection

AEG AS-BDEP-216 Modicon AS-BDEP-216 16-Channel Digital Output Module

  • Product Introduction: AEG AS-BDEP-216 is a high-density 16-channel digital output module for the Modicon 800 series PLC systems, designed for general-purpose digital output control in industrial automation, process control and building automation applications. The module features NPN transistor outputs with high current capacity, channel-to-group isolation and a compact modular design, enabling cost-effective control of a large number of field actuators, solenoids, relays and indicator lights in a single module. It integrates seamlessly with Modicon 800 series PLC chassis via the proprietary backplane bus, with simple configuration and reliable operation, making it an ideal solution for high-density digital output applications requiring a balance of performance, density and cost.
  • Technical Specifications:
    • Number of Channels: 16 digital output channels (4-channel groups isolated, channel-to-backplane isolated)
    • Output Type: NPN transistor (sink output), open collector
    • Output Voltage: 24 V DC (18-30 V DC operating range)
    • Output Current: 1.5 A per channel, 8 A per 4-channel group, 16 A total per module
    • Output Response Time: <1 ms (on/off)

AEG 7428-042-24809 Series Industrial Power Supply Module

  • Product Introduction: AEG 7428-042-24809 is a rugged industrial DIN-rail mount power supply module designed for providing stable and reliable DC power to PLCs, I/O modules, HMIs and other industrial automation equipment in harsh industrial environments. The module features a wide AC input voltage range, high efficiency, comprehensive electrical protection and a compact design, with a metal housing for enhanced heat dissipation and mechanical protection. It is engineered for continuous 24/7 operation, with low ripple and noise to ensure the safe and reliable operation of sensitive electronic equipment, and is a universal power supply solution for industrial control cabinets, automation systems and remote monitoring stations.
  • Technical Specifications:
    • Topology: Switch mode power supply (SMPS), single output
    • Input Voltage: 85-265 V AC (single-phase, 50/60 Hz) / 120-370 V DC (universal input, no voltage selection required)
    • Output Voltage: 24 V DC (fixed, adjustable ±10% via trim potentiometer for fine tuning)
    • Output Current: 10 A (continuous at 40°C); 8 A (continuous at 50°C); 5 A (continuous at 60°C)
    • Output Power: 240 W (nominal at 40°C)

AEG AS-BDAP-208 Modicon AS-BDAP-208 8-Channel Analog Input Module

  • Product Introduction: AEG AS-BDAP-208 is a cost-effective 8-channel analog input module for the Modicon 800 series PLC systems, designed for general-purpose analog signal acquisition in industrial automation, process control and building automation applications. The module supports all mainstream industrial analog input signals, with built-in signal conditioning and electrical isolation, delivering reliable and accurate analog data for non-critical process monitoring and control. It features a compact modular design, simple configuration and seamless integration with Modicon 800 series PLC chassis, making it an ideal solution for medium-density analog input applications requiring a balance of performance and cost-effectiveness.
  • Technical Specifications:
    • Number of Channels: 8 independent analog input channels (2-channel groups isolated, channel-to-backplane isolated)
    • Input Signal Types: Software-configurable per group – 4-20 mA DC, 0-10 V DC, 0-20 mA DC, 1-5 V DC (4 standard industrial signals)
    • Resolution: 14-bit (all signal types)
    • Accuracy: ±0.2% of full scale (25°C); ±0.3% of full scale (-25°C to +70°C)

AEG AS-H810-1208 Modicon AS-H810-1208 High-Speed Digital I/O Module

  • Product Introduction: AEG AS-H810-1208 is a high-performance high-speed digital I/O module for the Modicon H800 series advanced PLC systems, designed for fast digital signal acquisition and control in high-speed industrial automation, motion control and packaging applications. The module combines 12 high-speed digital inputs and 8 high-speed digital outputs in a single compact unit, with ultra-fast response times and support for high-frequency pulse signals (encoder inputs, pulse output for stepper/servo drives). It features channel-to-channel isolation and a high-speed backplane bus interface, delivering real-time I/O performance with sub-millisecond latency, and is a core component for high-speed sequence control, motion positioning and machine vision integration in modern manufacturing systems.
  • Technical Specifications:
    • Digital Inputs: 12 channels (high-speed, isolated), NPN/PNP configurable (sink/source)
    • Input Voltage: 24 V DC (18-30 V DC operating range)
    • Input Response Time: <50 μs (configurable 10/20/50/100 μs via software)
    • Input Current: <5 mA per channel
    • Digital Outputs: 8 channels (high-speed, transistor output), NPN (sink)

AEG S31N-R00-F010 Series Compact Soft Starter for 3-Phase AC Motors

  • Product Introduction: AEG S31N-R00-F010 is a compact, cost-effective soft starter for 3-phase AC induction motors, engineered for reducing inrush current and mechanical stress during motor startup/shutdown in light to medium industrial applications. The module features a voltage ramp control algorithm, built-in motor protection and a compact DIN-rail mount design, eliminating the need for separate contactors and overload relays in most applications. It is designed for seamless integration with PLC and relay control systems, with simple wiring and configuration, and is an ideal replacement for direct-on-line (DOL) starters in applications where smooth motor acceleration, energy savings and equipment protection are required.
  • Technical Specifications:
    • Motor Type: 3-phase squirrel cage AC induction motors (standard and high-efficiency IE2/IE3/IE4)
    • Rated Voltage: 380-480 V AC (3-phase, 50/60 Hz)
    • Rated Current: 10 A (continuous at 40°C)
    • Motor Power Rating: 4 kW (at 400 V AC, 50 Hz); 5.5 kW (at 460 V AC, 60 Hz)
    • Startup Control: Voltage ramp control (adjustable ramp time: 0.5-30 s; adjustable start voltage: 20-80% of rated voltage)

AEG 410-3/S908 Series Industrial Signal Isolator & Converter

  • Product Introduction: AEG 410-3/S908 is a rugged industrial signal isolator and converter designed for conditioning, isolating and converting analog signals between field sensors/actuators and PLC/DCS systems in harsh industrial environments. The module provides galvanic isolation between input, output and power supply, eliminating ground loops and electrical interference that cause signal distortion. It supports a wide range of standard analog input/output signals, with a compact DIN-rail mount design and industrial-grade components for continuous operation in extreme temperature, vibration and humidity conditions. It is a critical component for signal integrity in industrial automation, process control and power distribution systems, ensuring reliable data transmission between field and control layers.
  • Technical Specifications:
    • Signal Type: Analog input to analog output (4-20 mA, 0-10 V DC, 0-20 mA, 1-5 V DC – all configurable)
    • Input Range: 4-20 mA DC / 0-10 V DC / 0-20 mA DC / 1-5 V DC (selectable via DIP switches)
    • Output Range: 4-20 mA DC / 0-10 V DC / 0-20 mA DC / 1-5 V DC (selectable via DIP switches), 1:1 signal conversion (scalable via calibration)
    • Isolation: 3-way galvanic isolation (input → output → power supply), 2500 V AC isolation voltage (all paths)
    • Accuracy: ±0.1% of full scale (25°C); ±0.2% of full scale (-20°C to +60°C)
    • Linearity: ±0.05% of full scale

AEG AS-B875-011 Modicon AS-B875-011 8-Channel RTD Input Module

  • Product Introduction: AEG AS-B875-011 is a high-precision 8-channel resistance temperature detector (RTD) input module exclusively designed for the Modicon 800 series PLC systems, optimized for accurate and stable temperature measurement in industrial process control, manufacturing and instrumentation applications. The module features built-in signal conditioning, excitation current regulation and support for all mainstream industrial RTD types, with channel-to-channel electrical isolation to eliminate interference in noisy industrial environments. It integrates seamlessly with Modicon 800 series PLC chassis via the proprietary backplane bus, delivering real-time temperature data with ultra-low latency, and is a core component for high-precision temperature monitoring and closed-loop control systems requiring consistent, drift-free measurements.
  • Technical Specifications:
    • Number of Channels: 8 independent RTD input channels (fully isolated channel-to-channel and channel-to-backplane)
    • Supported RTD Types: Software-configurable per channel – Pt100 (2/3/4 wire), Pt200, Pt500, Pt1000, Ni100, Ni1000 (6 industrial standard types)
    • Measurement Range: -200°C to +850°C (Pt100/Pt200/Pt500/Pt1000); -60°C to +200°C (Ni100/Ni1000)
    • Resolution: 16-bit, 0.01°C (range -100°C to +200°C); 0.1°C (range -200°C to -100°C / +200°C to +850°C)
    • Accuracy: ±0.1°C (at 25°C, 3-wire Pt100); ±0.2°C (2/4-wire Pt100); ±0.3°C (Ni-based RTDs) + 0.02% of reading

AEG 7628-244734.00

Technical Specifications

  • Manufacturer: AEG (Modicon)
  • Model Number: 7628-244734.00 (A020PLUS GL)
  • Power Supply: 24V DC
  • Physical Dimensions: 22.9 cm × 10.2 cm × 30.5 cm (9.0" × 4.0" × 12.0")
  • Weight: 3 kg (6 lbs)
  • Processor: High-performance 8-bit or 16-bit microprocessor (specific model: AEG proprietary)
  • Memory:
    • User Program Memory: 8 KB (expandable up to 16 KB)
    • Data Memory: 2 KB (expandable up to 4 KB)
  • Input/Output (I/O) Configuration:
    • Digital Inputs: 16 channels (24V DC, sink/source configurable)
    • Digital Outputs: 12 channels (relay output, 250V AC/30V DC, 5A per channel)
    • Analog Inputs: 4 channels (12-bit resolution, 0-10V DC or 4-20mA)
    • Analog Outputs: 2 channels (12-bit resolution, 0-10V DC or 4-20mA)

AEG AS-B875-101

  • Product Introduction: AEG AS-B875-101 is a dedicated 8-channel thermocouple input module for the Modicon 800 series PLC systems, designed for precise temperature measurement and monitoring using industrial thermocouples in process control and industrial automation applications. The module features built-in cold junction compensation (CJC), high-precision signal conditioning and support for multiple thermocouple types, with channel-to-channel isolation for reliable operation in noisy industrial environments. It integrates seamlessly with Modicon 800 series PLC chassis via the backplane bus, providing real-time temperature data with high accuracy and low latency, and is a key component for temperature control in manufacturing, process control and energy management applications.
  • Technical Specifications:
    • Number of Channels: 8 independent thermocouple input channels (isolated from each other and backplane bus)
    • Supported Thermocouple Types: Software-configurable per channel – J, K, T, E, R, S, B, N (8 common industrial types)
    • Measurement Range: Dependent on thermocouple type – J (-210°C to +1250°C), K (-270°C to +1372°C), T (-270°C to +400°C), E (-270°C to +900°C), R (0°C to +1768°C), S (0°C to +1768°C), B (400°C to +1820°C), N (-200°C to +1300°C)

AEG AM-S980-100

  • Product Introduction: AEG AM-S980-100 is a dedicated non-volatile memory expansion module for the Modicon 980 series industrial PLCs, designed to provide additional high-capacity storage for PLC control programs, data logs, recipe parameters and process data. The module features high-speed Flash memory with long data retention time (no battery required), and integrates seamlessly with Modicon 980 series CPU modules via the proprietary backplane bus, with plug-and-play installation and no additional configuration required. It is engineered for industrial use, with wide environmental adaptability and shock/vibration resistance, and is a key component for complex industrial automation applications requiring large program storage and long-term data logging.
  • Technical Specifications:
    • Memory Type: Industrial-grade SLC NAND Flash memory (non-volatile, no battery required for data retention)
    • Memory Capacity: 1 MB (program memory) + 1 MB (data memory), dual partition for program and data storage
    • Data Retention: >10 years at 25°C, >5 years at 70°C (no power applied)
    • Access Speed: <50 ns read speed, <100 μs write speed (high-speed data access for real-time PLC operation)

AEG AS-B884-002

  • Product Introduction: AEG AS-B884-002 is a high-performance 2-channel high-speed analog output module for the Modicon 800 series PLC systems, designed for precise and fast analog signal output to control industrial actuators, valves, drives and process control equipment. The module features high-resolution digital-to-analog conversion (DAC), high output speed and multiple configurable output signal types, with channel-to-channel isolation for reliable operation in noisy industrial environments. It integrates seamlessly with Modicon 800 series PLC chassis via the backplane bus, providing real-time signal output with low latency, and is a key component for closed-loop process control and motion control applications requiring high precision and fast response.
  • Technical Specifications:
    • Number of Channels: 2 independent high-speed analog output channels (isolated from each other and backplane bus)
    • Output Signal Types: Configurable per channel – 0-10 V DC, 4-20 mA, 0-20 mA (3 signal types selectable via software)
    • Resolution: 16-bit (for all signal types), 0.015% of full scale
    • Accuracy: ±0.1% of full scale (25°C), ±0.2% of full scale (-25°C to +70°C)
