AEG 92-00838-03 Industrial Signal Isolator/Converter Module

  • Product Introduction: AEG 92-00838-03 is a precision industrial signal isolator and converter module designed to transmit and convert analog signals (4–20 mA, 0–10 V) while providing electrical isolation between field devices and control systems. It eliminates ground loops and electrical interference, ensuring accurate signal transmission in high-noise industrial environments. The module features high conversion accuracy, wide input/output range, and a compact design, making it suitable for process monitoring and control applications in chemical processing, power generation, and manufacturing, where signal integrity is critical to operational efficiency and safety.
  • Technical Specifications:
    • Input Signal: 4–20 mA DC, 0–10 V DC (configurable)
    • Output Signal: 4–20 mA DC, 0–10 V DC (selectable, dual output option)
    • Conversion Accuracy: ±0.1% of full scale
    • Isolation Voltage: 3000 V AC (input-output, input-ground, output-ground)
    • Common Mode Rejection Ratio (CMRR): >120 dB (@50/60 Hz)
    • Power Supply: 24 V DC (18–30 V DC)
    • Power Consumption: <1.2 W

AEG 140DDO84300

  • Product Introduction: AEG 140 DDO84300 is a high-performance 16-channel DC output module designed for the Modicon Quantum series PLC systems, optimized for high-current industrial control applications requiring reliable switching of 10–60 V DC loads. The module is organized into two 8-channel groups, with fast switching response and robust protection against electrical transients, making it suitable for controlling DC motors, solenoid valves, and other high-power DC devices in demanding automation environments. It integrates seamlessly with Modicon Quantum chassis, with built-in diagnostics and LED status indicators, ensuring optimal performance and easy troubleshooting in factory automation, process control, and material handling applications.
  • Technical Specifications:
    • Number of Channels: 16 DC output channels, 2 groups of 8 channels each
    • Output Voltage Range: 10–60 V DC (10.2–72 V DC surge tolerance)
    • Current Capacity: 6 A per group, 12 A total (resistive load)
    • Switching Response Time: 1 ms (on/off)
    • Output Logic: Positive (source) logic
    • Isolation: 2500 V AC (channel group-to-backplane bus)

AEG 120-147-005 Industrial Power Distribution Terminal Block Module

  • Product Introduction: AEG 120-147-005 is a heavy-duty industrial power distribution terminal block module engineered for secure, high-current electrical connections in industrial automation, power distribution, and control panel applications. It is designed to terminate and distribute 24-600 V AC/DC power to multiple field devices, with a robust modular design that ensures stable power transmission and protection against electrical faults. The module features a high-current carrying capacity, corrosion-resistant terminals, and compliance with global industrial safety standards, making it ideal for high-power applications in manufacturing plants, power generation facilities, and heavy-duty industrial environments where reliable power distribution is critical to operational continuity.
  • Technical Specifications:
    • Voltage Rating: 600 V AC/DC (continuous operation)
    • Current Rating: 35 A per terminal, 70 A per module (max)
    • Terminal Type: Copper alloy, screw-clamp terminals with tin plating
    • Terminal Quantity: 6 power distribution terminals (3 input, 3 output)
    • Wire Size: 1.5–16 mm² (AWG 16–6) solid/stranded copper wire

AEG AS-P933-01

  • Product Introduction: AEG AS-P933-01 is a high-reliability 120W redundant power supply module exclusively designed for Modicon 900 series PLC chassis, engineered to deliver uninterrupted, stable DC power to PLC CPU, I/O and communication modules in mission-critical industrial automation and process control applications. The module features dual independent 24 V DC input power paths, automatic power failover, high efficiency power conversion, and comprehensive overvoltage/overcurrent protection, ensuring zero power interruption to the PLC system if one input power source fails. It has a compact modular design, seamless backplane integration, and real-time status monitoring with LED indicators, making it an essential component for safety instrumented systems (SIS), critical process control, and 24/7 continuous operation applications where PLC downtime would result in production loss, equipment damage, or safety hazards.
  • Technical Specifications:
    • Power Output: 24 V DC (adjustable ±5% via trim potentiometer), 5 A continuous output (120 W total power)
    • Input Power: Dual redundant 24 V DC input (Path 1 + Path 2), 18-30 V DC operating range per input
    • Power Failover: Automatic seamless switchover (<1 ms) between input paths, no PLC system interruption
    • Conversion Efficiency: >92% at full load, >90% at 50% load (high efficiency reduces heat generation)
    • Ripple & Noise: <30 mV peak-to-peak (at 24 V DC output, full load) – low noise for sensitive PLC electronics
    • Protection Features: Overvoltage protection (OVP: 28.8 V DC auto-shutoff), overcurrent protection (OCP: 6 A current limit), overtemperature protection (OTP: thermal shutdown at 85°C), reverse polarity protection (input paths)

AEG AS-S908-000

  • Product Introduction: AEG AS-S908-000 is a high-reliability serial communication module designed for the Modicon 900 and 984 series PLC systems, engineered to extend serial communication capabilities for connection to field devices, HMIs, printers and third-party control equipment with RS-232/RS-485 interfaces. The module features two independent configurable serial ports, support for multiple industrial serial protocols, high-speed data transfer and built-in fault detection, delivering reliable bi-directional communication in harsh industrial environments. It integrates seamlessly with the Modicon backplane bus, supports configuration via PLC programming software, and is an ideal solution for expanding serial communication in Modicon PLC systems for factory automation, process control and building automation applications where industrial serial fieldbus connectivity is required.
  • Technical Specifications:
    • Number of Communication Ports: 2 fully independent configurable serial ports (Port 1: RS-232/RS-485; Port 2: RS-485 only)
    • Supported Protocols: Modbus RTU/ASCII, DF1, ASCII/RTU generic serial, Siemens S7 PPI, Mitsubishi FX protocol
    • Port Configuration: Software-configurable per port (protocol, baud rate, data bits, stop bits, parity, flow control)
    • Baud Rate: 1200/2400/4800/9600/19200/38400/57600/115200 bps, selectable per port
    • Data Format: Configurable data bits (7/8), stop bits (1/2), parity (none/odd/even)
    • Communication Distance: Up to 15 meters (RS-232), up to 1200 meters (RS-485, 9600 bps), extendable via repeaters

AEG PC-A984

  • Product Introduction: AEG PC-A984 is a high-performance central processing unit (CPU) module designed as the core of the Modicon 984 series PLC systems, engineered for medium to large-scale industrial automation and process control applications. The CPU features a 32-bit RISC processor, high-capacity on-board memory, multi-protocol communication support and a high-speed backplane bus interface, delivering fast program execution and real-time I/O data processing. It supports IEC 61131-3 programming standards, built-in diagnostic functions and redundant power supply input, with a rugged industrial design optimized for 24/7 continuous operation in harsh environments. The PC-A984 is the primary control component for Modicon 984 series PLC systems, enabling complex control logic, sequential process control and integration with industrial networks in factory automation, process control and building automation applications.
  • Technical Specifications:
    • Processor: 32-bit industrial RISC processor, 80 MHz clock speed
    • Program Execution Speed: 0.1 μs per boolean instruction, 0.5 μs per floating-point instruction
    • On-Board Memory: 2 MB Flash program memory (non-volatile), 1 MB RAM data memory, expandable via AS-M996-000 memory module
    • Supported Programming Standards: IEC 61131-3 (Ladder Logic, Function Block Diagram, Structured Text, Sequential Function Chart, Instruction List)

AEG AS-J890-001

  • Product Introduction: AEG AS-J890-001 is a multi-protocol industrial communication gateway module designed for the Modicon 800 and 900 series PLC systems, engineered to enable seamless data exchange between Modicon PLCs and third-party industrial control devices, HMIs, SCADA systems and industrial networks. The module features dual independent communication ports, support for all mainstream industrial communication protocols, and a high-speed backplane interface, providing bi-directional real-time data transfer and protocol conversion with ultra-low latency. It supports configuration via PLC programming software, has built-in fault detection and redundant communication options, and is an ideal solution for integrating Modicon PLC systems into multi-vendor industrial automation networks in factory automation, process control and building automation applications.
  • Technical Specifications:
    • Communication Ports: 2 independent configurable communication ports (Port 1: RS-485/RS-232; Port 2: Ethernet RJ45 + RS-485)
    • Supported Protocols: Modbus RTU/ASCII/TCP, Profibus-DP, Ethernet/IP, DeviceNet, CANopen, Siemens S7 PPI/MPI, Mitsubishi MC Protocol
    • Backplane Interface: Modicon 800/900 series proprietary high-speed bus, 20 Mbps data transfer rate, <0.5 ms latency
    • Data Transfer Capacity: Up to 1024 input and 1024 output data words (bi-directional), configurable data mapping

AEG 15A0251-000

  • Product Introduction: AEG 15A0251-000 is a high-reliability backplane module engineered as the core interconnect component for Modicon 800 series PLC chassis, providing a dedicated communication and power distribution bus for all installed I/O, communication and power modules. The backplane features a rugged PCB construction, gold-plated contact pins, isolated power/communication channels and built-in fault detection, ensuring fast, reliable data transfer and stable power distribution between the PLC CPU and all peripheral modules. It is designed for 24/7 continuous operation in harsh industrial environments, with high vibration/shock resistance and wide temperature tolerance, and is a critical replacement and upgrade component for Modicon 800 series PLC systems in factory automation, process control and building automation applications.
  • Technical Specifications:
    • Chassis Compatibility: Modicon 800 series 8-slot PLC chassis (primary and expansion chassis)
    • Number of Module Slots: 8 standard Modicon 800 series module slots, 1 dedicated CPU slot + 7 universal I/O/communication slots
    • Backplane Bus Protocol: Modicon 800 series proprietary high-speed bus, 20 Mbps data transfer rate
    • Data Transfer Latency: <0.5 ms between CPU and any I/O slot, synchronous data transfer for all slots
    • Power Distribution: Isolated +5 V DC (logic power) and +24 V DC (I/O power) to each slot; 5 A +5 V DC / 10 A +24 V DC per chassis total

AEG AS-BDEP-218

  • Product Introduction: AEG AS-BDEP-218 is a high-density 16-channel digital output module with electromechanical relay outputs, designed for the Modicon 800 series PLC systems. Engineered for general-purpose industrial control applications, the module provides isolated dry contact outputs for controlling AC/DC field devices, eliminating the need for additional signal conversion components and enabling seamless integration with both low-voltage DC and line-voltage AC equipment. It features channel-to-group isolation, comprehensive fault protection, and a compact modular design, with individual LED status indicators for each channel. The module is ideal for high-density output control in factory automation, building automation and process control applications where reliable switching of mixed AC/DC loads is required.
  • Technical Specifications:
    • Number of Output Channels: 16 independent relay output channels, 8-channel isolation groups (2 isolation groups total)
    • Output Type: Electromechanical dry contact relays, SPST (Single Pole Single Throw), normally open (NO) contacts
    • Rated Switching Voltage: 24 V DC, 115 V AC, 230 V AC (mixed AC/DC load support)
    • Rated Switching Current: 2 A per channel (resistive load), 1 A per channel (inductive load), 8 A per isolation group

AEG A1482AES Industrial Grade AC Drive/VFD for 3-Phase Motors

  • Product Introduction: AEG A1482AES is a high-performance variable frequency drive (VFD) designed for precise speed and torque control of 3-phase AC induction motors in industrial automation, process control and material handling applications. The drive features advanced vector control algorithms, a wide power range, comprehensive motor protection and multi-protocol communication support, with a rugged industrial design optimized for reliable operation in harsh environments. It supports both constant torque and variable torque applications, enables energy savings for fan, pump and blower applications, and integrates seamlessly with PLC and HMI systems, making it a versatile motor control solution for industrial, commercial and municipal applications requiring efficient, precise motor control.
  • Technical Specifications:
    • Motor Type: 3-phase squirrel cage AC induction motors (IE1/IE2/IE3/IE4 high-efficiency motors)
    • Rated Voltage: 380-480 V AC 3-phase (50/60 Hz), wide input range 320-528 V AC
    • Power Range: 7.5 kW (10 HP) at 400 V AC, 9.2 kW (12.5 HP) at 460 V AC (continuous duty)
    • Control Modes: V/f scalar control, sensorless vector control (SLVC), torque control, speed control
    • Speed Regulation Accuracy: ±0.5% of rated speed (SLVC mode), ±3% of rated speed (V/f mode)
    • Starting Torque: 150% of rated torque at 0.5 Hz (SLVC mode), 100% of rated torque at 0 Hz (torque control mode)

AEG AS-P930-104

  • Product Introduction: AEG AS-P930-104 is a compact, rugged remote I/O chassis designed for the Modicon 900 series PLC systems, engineered to extend modular I/O capabilities to field locations in industrial automation and process control applications. The chassis features an integrated communication module, 4 standard Modicon I/O slots, and a robust industrial design, enabling distributed I/O control with seamless data transmission to the central PLC main chassis. It supports hot-swappable I/O module installation, comprehensive power and communication fault detection, and wide environmental adaptability, making it an ideal solution for decentralized control systems in large-scale factories, remote processing plants and harsh industrial environments where long cable runs to a central chassis are impractical.
  • Technical Specifications:
    • Number of I/O Slots: 4 standard Modicon 900 series I/O slots, compatible with digital/analog/temperature I/O modules
    • Integrated Communication: Modbus RTU/RS-485, baud rate configurable (9600/19200/38400/57600/115200 bps)
    • Communication Distance: Up to 1200 meters (RS-485) with proper shielding, extendable via repeaters
    • Power Supply Input: 24 V DC (18-30 V DC), redundant power input support (dual 24 V DC terminals)
    • Power Distribution: Independent 24 V DC power to each I/O slot, 2 A per slot overcurrent protection

AEG MMPMC1200 Series 12-inch Advanced Industrial HMI Panel

  • Product Introduction: AEG MMPMC1200 is a high-performance 12-inch human-machine interface (HMI) panel designed for advanced industrial automation, process control and machine control applications. The panel features a high-resolution touchscreen, powerful embedded processor, multi-protocol communication support and a rugged industrial design, enabling intuitive real-time monitoring and control of complex industrial systems. It supports advanced functionality including data logging, recipe management, remote access and machine vision integration, with a user-friendly development environment for custom HMI project creation. It is an ideal operator interface for medium to large-scale industrial machines and process control systems requiring a balance of screen size, performance and functionality.
  • Technical Specifications:
    • Display: 12.1-inch color TFT LCD, 1024×768 XGA resolution, 500 cd/m² high brightness, 1000:1 contrast ratio, LED backlight (50,000 hour lifespan)
    • Touch Input: Resistive touchscreen (4-wire), scratch-resistant tempered glass surface, single-touch operation (gesture support: zoom, pan)
