SAACKE FSC-01

Technical Specifications
  • Safety Integrity Level: SIL 3 according to IEC 61508.
  • Compliance Standards: DIN EN 298, DIN EN 230, Pressure Equipment Directive 97/23/EC, Gas Appliances Directive 2009/142/EC.
  • Channels and Modes: In the basic version, it has 8 fail - safe channels, 4 operating modes, and up to 4 integrated controllers.

PARKER AR-04AE-13574

Technical Specifications

  • Maximum Output Power: 400W (continuous current @ 240VAC)
  • Rated Output Power: 1.1kVA
  • Input Power: Single - phase 120/240VAC
  • Feedback Options: Square - wave incremental encoder, Heidenhain EnDat absolute encoder
  • Command Interface Options: ±10V, Pulse/Direction, Ethernet PowerLink
  • Certifications: CE (EMC and LVD), UL approved

BENDER IRDH575B1W-435

Technical Specifications

  • Rated Insulation Voltage: AC 800V
  • Rated Impulse Voltage/Pollution Degree: 8kV/3
  • Nominal System Voltage: AC, 3/(N)AC 20 - 575V; DC 20 - 575V; AC, 3/(N)AC 340 - 760V; DC 340 - 575V
  • Power Supply Voltage: 88 - 264V AC, 42 - 460Hz; DC 19.2 - 72V
  • DC Internal Resistance: ≥180k
  • Positioning Current DC: 1/2.5/10/25/50 mA
  • Operating Temperature Range: -10 - +55°C (working); -40 - +70°C (storage)
  • Protection Class: IP30 (internal components); IP20 (terminals); IP40 (for installation door); IP42 (for installation door with sealed panel); IP65 (for installation with transparent front - plate cover)
  • Weight: ≤900g

DEIF DLQ144-PC-NB

Technical Specifications
  • Input Voltage: ±10V
  • Load: 9k ohm
  • Illumination Voltage: 24V AC/DC
  • Measurement Range: 0 - 100% pitch
  • Weight: 630 gm

KONGSBERG MRU-E-JB3

Technical Specifications

  • Roll and Pitch Output
    • Angle Range: ±45 degrees
    • Angular Velocity Range: ±100 degrees/second
    • Resolution: 0.001 degrees
    • Angular Velocity Noise: 0.1 degrees/second RMS
    • Static Accuracy: 0.08 degrees RMS
    • Dynamic Accuracy (±5° Amplitude): 0.08 degrees RMS
    • Scale Factor Error: 0.5% RMS

EATON XV-112-DB-70TWRC-00

Technical Specifications

  • Power Supply: 24V DC.
  • Operating Voltage: 24V.
  • Output Current: The maximum output current is 3A/phase.
  • Display: 7 - inch TFT color display with WVGA resolution.
  • Communication Interfaces: Ethernet interface, USB device, RS232, Profibus/MPI, and it also supports 2 CAN interfaces for communication with PLC.
  • Control Modes: Supports protocol position control, speed control, and periodic position control modes.
  • Encoder Resolution: The servo motor encoder can be optionally 20BIT or 17BIT resolution, and the standard is 2500 lines.
  • Pulse Input Frequency: Up to 4MPPS.
  • Speed Frequency Response: Can reach 1200HZ.
  • Overload Capacity: Up to 3 times.

ALSTOM EP3-E-4-A

Technical Specifications

  • Communication Protocols: Supports multiple protocols such as Ethernet, CAN, and Modbus for versatile integration.
  • Connectivity: Equipped with multiple input/output ports for connecting various devices and systems.
  • Operating Voltage: Typically rated for 24V DC.
  • Output Voltage: 0 - 10V DC.
  • Current Rating: 4A.
  • Operating Temperature: - 40℃ - + 85℃.
  • Mounting: Can be easily mounted in standard enclosures or on DIN rails.
  • Weight: Approximately 1 kg.

Fireye 45UV5-1101

Compatibility & Integration

  • Controllers: Fireye BurnerLogix™, D-Series, MicroM, and Flame Monitor™ systems.
  • Burner Types: Single-point monitoring for manual, semi-auto, or fully automatic burners.
  • Fuels: Natural gas, diesel, propane, kerosene (not for hydrogen/solar flames).

Alstom Micom P40 AGILE MICOM P141

Application Scenarios

1. Power Distribution Networks
  • MV Feeder Protection: Overcurrent/earth fault protection for 6.6–33kV substations .
  • Fault Location: Pinpoints cable/line faults via impedance-based algorithms .
2. Industrial Facilities
  • Motor/Generator Backup: Protects critical drives in plants using directional overcurrent .
  • Microgrid Control: Manages grid-tie transitions and load balancing .
3. Renewable Integration
  • Solar/Wind Farm Collection Grids: Synchronizes distributed resources with autoreclosing .
4. Transportation & Infrastructure
  • Rail Electrification: Protects catenary systems with distance protection .

NOUENVOG AAP3798102-00131

Application Scenarios

  1. Compressor Control Systems
    • Cameron TA-Series: Manages inlet valve positioning, oil pressure, and vibration monitoring in TA2000/TA3000 compressors .
  2. Energy Infrastructure
    • Pump Stations: Regulates flow/pressure in pipeline transport .
    • Gas Turbine Backup: Synchronizes auxiliary systems during grid failures .
  3. Industrial Automation
    • Production Lines: Interfaces with Schneider/Bently Nevada PLCs for safety interlocks .
    • Remote Monitoring: Transmits operational data to SCADA via Modbus .

Basler BE3-25A Phase Overcurrent Relay

echnical Specifications

  • Sensor Type: CMOS sensor technology optimized for high-speed and high-resolution image capture
  • Resolution: 25 MP (megapixels), providing detailed images for precise analysis
  • Frame Rate: Up to 30 frames per second at full resolution, ensuring smooth video capture even in fast-moving environments
  • Interface: CoaXPress (CXP) interface, supporting high-speed data transfer rates up to 12.5 Gbps per connection, with support for multiple connections
  • Pixel Size: Typically around 3.45 µm, contributing to high sensitivity and dynamic range
  • Shutter Type: Global shutter, minimizing distortion in moving objects

CCC IOC-555-D 17-550555-001 Simplex I/O Card / Communication Control Board

Technical Specifications

  1. I/O Configuration:
    • Digital Inputs: 8 channels .
    • Digital Outputs: 8 channels .
    • Analog I/O:
      • 2 analog inputs and 2 analog outputs (per ) .
      • Note:  describes 32 channels total (digital/analog combined), but this conflicts with earlier sources; the 8+8 digital configuration is consistently verified.
