GE IC800VMM10MBKS

Technical Specifications

  • Rated Output: 1000 watts
  • Rated Torque: 4.77 Nm
  • Maximum Torque: 14.32 Nm
  • Rated Speed: 2000 rpm
  • Maximum Speed: 3000 rpm
  • Rated Current: 5.6 amps
  • Maximum Current: 24.9 amps
  • Rotor Moment of Inertia: 9.14 kg·m² x 10⁻⁴

GE IC800VMA302-BB

Technical Specifications
  • Power Supply: Operates on a three - phase voltage of 220V AC, with a frequency of 50/60Hz ± 5%. The permissible voltage fluctuation range is 170 VAC to 225 VAC.
  • Output Current: The output short - circuit current is 107 A (peak), and the three - phase operation current leakage is 0.13 mA.
  • Electronic Gear Ratio: n/m, where n: 1 ~ 32767, m: 1 ~ 32767 (1/50 < n/m < 200).
  • Dimensions: Height 245 mm, width 110 mm, length 206 mm.
  • Operating Temperature: 0 to 55 °C. For operation above 55 °C, forced cooling is required. The storage temperature is - 22 °C to 65 °C, and condensation should be avoided.

GE IC800VMA302-BB

Technical Specifications
  • Power Supply: It operates on a 220V AC three - phase voltage, with a frequency of 50/60Hz ± 5%. The permissible voltage fluctuation range is 170 VAC to 225 VAC.
  • Output Current: The output short - circuit current is 107 A (peak), and the three - phase operation current leakage is 0.13 mA.
  • Electronic Gear Ratio: The electronic gear ratio is n/m, where n ranges from 1 to 32767, and m ranges from 1 to 32767 (1/50 < n/m < 200).
  • Dimensions: The height is 245 mm, the width is 110 mm, and the length is 206 mm.
  • Operating Temperature: The operating temperature should be between 0 °C and 55 °C. For temperatures above 55 °C, forced cooling is required. The storage temperature range is - 22 °C to 65 °C, and condensation must be avoided.

GE IC800VMA202

Technical Specifications
  • Power Supply: Requires a three - phase voltage of 220V AC, 50/60Hz ± 5%. The permissible voltage fluctuation range is 170 VAC to 255 VAC.
  • Electronic Gear Ratio: n/m, where n: 1 ~ 32767, m: 1 ~ 32767 (1/50 < n/m < 200).
  • Cooling Method: Fan - cooled.
  • Dimensions: Height 245 mm, width 110 mm, length 206 mm. An additional 70 mm should be allowed for connected cables to prevent bending.
  • Operating Temperature: 0 to 55 °C. For operation above 55 °C, forced cooling is required.
  • Storage Temperature: - 20 °C to 65 °C.
  • Humidity: 0 to 90% non - condensing.

GE IC800S107RS1-DE

Technical Specifications

  • Power Supply: Usually, it may support a wide - range power input, such as 90 - 250 VAC, 1 or 3 - phase, 50 - 440 Hz.
  • Output Current: Similar models can provide 4.3 A continuous full - load current and 8.6 A peak full - load current for 3 - phase output at 90 - 250 VAC.
  • Operating Temperature: The operating temperature range is generally 0 - 40 °C.

GE IC800SSD107RS1-DC

Technical Specifications
  • Power Input: 90 - 250 VAC, 1 or 3 phase, 50 - 440 Hz, 1.6 kVA max cont.（Note: The power input specification is similar to that of the related IC800 series modules, and there may be slight differences in the actual product.）
  • Output Current: 4.3 A continuous full load, 8.6 A peak full load for 3 - phase output at 90 - 250 VAC, 0 - 1000 Hz.（Note: The output current specification is for reference only according to the similar model IC800SSD104RS1 - CC.）
  • Operating Temperature: 0 - 40 °C.

GE IC800SSD104RS1-DC

Technical Specifications
  • Power Input: 90 - 250 VAC, 1 or 3 phase, 50 - 440 Hz, 1.6 kVA max cont.
  • Output Current: 4.3 A continuous full load, 8.6 A peak full load for 3 - phase output at 90 - 250 VAC, 0 - 1000 Hz.
  • Operating Temperature: 0 - 40 °C.

GE IC755CSS15CDA-AG

Technical Specifications
  • Processor: Freescale i.MX 535 based on ARM Cortex A8, with a clock speed of 1 GHz.
  • Memory: 1 GB DDR3 SDRAM, 512 MB SLC NAND flash memory, 512 KB battery - backed SDRAM.
  • Display: 15 - inch projected capacitive multi - touch TFT LCD display, with a resolution of 1024 x 768 pixels.
  • Operating System: Windows Embedded Compact 7.
  • Communication Interfaces: Two Ethernet interfaces, one RS232 port, one RS485 port, and three USB interfaces (2x USB 2.0 Type - A, 1x USB 2.0 Mini Type - B).
  • Power Supply: 12/24 VDC.
  • Power Consumption: 30 watts.
  • Dimensions: 399 x 323 x 70 millimeters (15.7 x 12.7 x 2.7 inches).
  • Weight: Approximately 5 kg.

GE IC754VSL06MTD-KH

Technical Specifications

  • Display Size: 5.75 - inch diagonal.
  • Resolution: 320 x 240 pixels.
  • Touchscreen Type: 12 - bit resistive touchscreen.
  • Processor: Intel Xscale PXA255, with a clock speed of 300 MHz.
  • Memory: 32 MB of non - volatile flash memory, 32 MB of dynamic memory, 512 KB of static memory, and 512 KB of read - only memory.
  • Power Supply: 12 - 30 VDC.
  • Communication Ports: Two RS232 and RS485 serial ports, one 10BaseT/100BaseTX Ethernet port, and two USB 1.1 ports.
  • External Storage: One Type 2 CompactFlash card port.
  • Dimensions: 4.86 inches (126 mm) in height, 6.14 inches (158 mm) in width, and 2.76 inches (70 mm) in depth.
  • Weight: About 2.5 pounds (1.16 kg).

GE IC754VSL06MTD-KH

Technical Specifications
  • Display Size: 5.75 - inch diagonal.
  • Resolution: 320 x 240 pixels.
  • Touchscreen Type: 12 - bit resistive touchscreen.
  • Processor: Intel Xscale PXA255, with a clock speed of 300 MHz.
  • Memory: 32 MB of non - volatile flash memory, 32 MB of dynamic memory, 512 KB of static memory, and 512 KB of read - only memory.
  • Power Supply: 12 - 30 VDC.

GE IC754VSB06MTD-GF

Technical Specifications
  • Display Size: 6 - inch diagonal, with an actual display size of 5.75 inches (14.6 centimeters).
  • Resolution: 320 x 240 pixels.
  • Touchscreen Type: 12 - bit resistive touchscreen.
  • Processor: Intel Xscale PXA255, with a clock speed of 200 MHz.
  • Memory: 32 MB of internal memory (including flash and DRAM), and 512 KB of SRAM with battery backup.
  • Power Supply: Input voltage range is 12 - 30 volts DC.
  • Communication Ports: Usually includes RS232 and RS485 serial ports, and may also have an Ethernet port.
  • Dimensions: Approximately 4.86 inches (126 millimeters) in height, 6.14 inches (156 millimeters) in width, and 2.026 inches (51.5 millimeters) in depth.
  • Weight: About 2.5 pounds (1.16 kg).
  • Operating Temperature: - 10 to 60 degrees Celsius.
  • Humidity: 10 - 85%.

GE IC754VBI12CTD-EG

Technical Specifications
  • Display Size: 12 - inch.
  • Resolution: 800 x 600 pixels.
  • Touchscreen Type: Resistive (inferred from similar models).
  • Display Type: Color - TFT LCD.
  • Power Supply: 12 or 24 VDC.
  • Memory: Combined internal memory of 32 MB.
  • Communication Ports: One Ethernet interface, one serial RS232/RS422 combo port.
  • Dimensions: Approximately 16 x 14 x 8 inches.
  • Weight: Approximately 10 lbs.
