GE IC693PBS201 Power Module

Technical Specifications

  • Brand: GE (General Electric)
  • Model: IC693PBS201
  • Type: Power module for PLC systems
  • Output Type: Transistor-based output
  • Output Points: 16 points
  • Output Voltage: DC 5-24V
  • Output Current: Maximum 0.5A per point
  • Isolation Method: Optical isolation
  • Operating Temperature Range: -20°C to 60°C

GE IC200MDL742D Analog Output Module

Technical Specifications

  • Brand: GE (General Electric)
  • Model: IC200MDL742D
  • Type: Analog output module for PLC systems
  • Output Channels: Supports multiple analog output channels (specific channel count depends on configuration, typically ranging from 2 to 8 channels).
  • Output Signal Type: Voltage or current output (configurable based on application requirements).
  • Voltage Output Range: 0-5V, 0-10V, ±5V, ±10V (configurable).
  • Current Output Range: 0-20mA, 4-20mA (configurable).

GE IC200ALG325H Logic Module

Technical Specifications

  • Brand: GE (General Electric)
  • Model: IC200ALG325H
  • Type: Logic module for PLC systems
  • Input/Output Channels:
    • Supports up to 8 analog input channels (configurable for voltage or current signals).
    • Voltage input range: 0-5V, 0-10V, ±5V, ±10V.
    • Current input range: 0-20mA, 4-20mA.
    • Resolution: 16-bit for high-precision data acquisition.

GE IC694APU300 Processor Module

Technical Specifications

  • Brand: GE (General Electric)
  • Model: IC694APU300
  • Type: Processor module for PLC systems
  • Input/Output Channels:
    • Supports up to 8 analog input channels (configurable for voltage or current signals).
    • Voltage input range: 0-5V, 0-10V, ±5V, ±10V.
    • Current input range: 0-20mA, 4-20mA.
    • Resolution: 16-bit for high-precision data acquisition.

GE IC200PWR002 Power Supply Module

Technical Specifications

  • Input Voltage: 18-30 VDC (nominal 24 VDC)
  • Output Voltage: 5 VDC and 3.3 VDC
  • Output Current:
    • Total maximum output current: 1.5 A
    • 5 VDC output: Up to 1.0 A
    • 3.3 VDC output: Up to 0.25 A (when 5 VDC output is not fully loaded)
  • Power Rating: 11 W
  • Hold-up Time: 10 ms
  • Surge Current:
    • 20 A for 6 ms at 24 VDC
    • 25 A for 6 ms at 30 VDC

GE IC641SWP708B Touch Screen Module

Technical Specifications

  • Model: IC641SWP708B
  • Brand: GE (General Electric)
  • Application: PLC system touch screen module
  • Function: Human-machine interface (HMI) for monitoring and controlling PLC operations
  • Compatibility: Designed to work seamlessly with GE PLC systems
  • Power Supply: 24V DC (typical for industrial PLC modules)
  • Mounting: DIN rail mounting for compact installation in control cabinets
  • Operating Temperature: -20°C to 70°C (industrial-grade temperature range for harsh environments)
  • Humidity Tolerance: 5% to 95% non-condensing humidity

GE IC693MDL940F Redundancy Module

Technical Specifications

  • Module Type: Redundancy module for PLC systems.
  • Compatibility: Works with GE Series 90-30 PLCs, supporting seamless integration into existing control architectures.
  • Power Supply: 24V DC power input with reverse polarity protection.
  • Operating Temperature: -20°C to 70°C (industrial-grade temperature range).
  • Humidity Tolerance: 5% to 95% non-condensing humidity for reliable operation in harsh environments.
  • Isolation: Features electrical isolation between input/output sections and the bus system to prevent interference.
  • Mounting: DIN rail mounting for compact installation in control cabinets.

GE IC687BEM731F-AB Analog Input Module

Technical Specifications

  • Input Channels: Supports multiple analog input channels (specific channel count depends on configuration).
  • Signal Types: Accepts voltage signals (e.g., 0-10V, ±10V) and current signals (e.g., 4-20mA).
  • Accuracy: High-precision measurement with minimal error margin (exact value depends on calibration and configuration).
  • Isolation: Provides electrical isolation between input channels and the bus system to prevent interference.
  • Resolution: Typically offers 12-bit or higher resolution for accurate signal representation.
  • Sampling Rate: High-speed sampling to capture dynamic signal changes in real-time.

GE IC660ELB921H Communication Interface Module

Technical Specifications

  • Input/Output Configuration:
    • Supports four keyphasor input channels (configurable in paired or unpaired modes).
    • Provides four output channels (one per module).
  • Signal Compatibility:
    • Measures machine speed (not phase) via keyphasor signals.
    • Compatible with 24V DC power supply.
  • Isolation:
    • Input/output isolation rated at 1500V AC.
    • Channel-to-channel isolation rated at 500V AC.

GE IC600PB553BPDT Signal Conditioning Module

Technical Specifications

  • Input Signal Types: Supports voltage (±10V), current (4-20mA), and thermocouple/RTD signals.
  • Output Signal Types: Provides isolated voltage (±10V) or current (4-20mA) outputs.
  • Accuracy: ±0.1% of full-scale range for voltage/current signals.
  • Isolation Voltage: 2500V RMS between input, output, and power sections.
  • Bandwidth: Adjustable up to 10kHz for dynamic signal processing.
  • Operating Temperature: -20°C to +70°C (-4°F to +158°F).
  • Power Supply: 24V DC ±20%, with reverse polarity protection.
  • Dimensions: 120mm x 80mm x 40mm (L x W x H).

GE IS200DTAIH1ABB

Technical Specifications
  • Input Range: -10V to +10V, 4mA to 20mA, etc.
  • Input Impedance: ≥10MΩ
  • Output Signal: 4 - 20mA (one output can be configured for 0 - 200mA by reconfiguring jumpers)
  • Operating Temperature Range: -40°C to +85°C
  • Storage Temperature Range: -55°C to +125°C
  • Humidity: 5% to 95% (non - condensing)
  • Dimensions: 80mm x 45mm x 25mm
  • Weight: 150g

GE IS200ADIIH1AAA

Technical Specifications
  • Board Type: IS200
  • LED Indicators: 6
  • Time Delay: 200 μsec (required for the LAN control processor to write the drive's feedbacks into the IS bus controller before the start of the next frame)
  • Connectors: Connects to the DS200 LDCC drive control/LAN communications board through the LNPL ribbon cable and COM1 wire. It interfaces to the IS bus through two RJ45 connectors (P2 for TX/OUT and P3 for RX/IN).
