GE IC693MDL753

  • Operating Voltage: 12 or 24 volts DC.
  • Output Voltage Range: 10.2 to 28.8 volts DC.
  • Output Current: 0.5 amps maximum per output point, 4 amps maximum per group.
  • Number of Outputs: 32 individual output channels, grouped into four isolated groups of eight.
  • Isolation: 1,500 V between field side and logic side, 250 V between groups.
  • Response Time: 0.5ms max. on and off response time.
  • Power Consumption: 260 ma max. from 5v bus on backplane (13 ma + 3 ma / point on + 4.7 ma / led).
  • Operating Temperature Range: -10 °C to +55 °C.
  • Storage Temperature Range: -40 °C to +70 °C.
  • Humidity Range: 5% to 95% non - condensing.
  • Dimensions: Width x Depth x Height (mm): 144 x 85 x 73.
  • Weight: Approximately 0.2 kg.

GE IC693MDL340

  • Input Voltage: Not applicable (operates on AC power source, output voltage is 85 - 132 VAC)
  • Output Voltage: 85 - 132 VAC, 50/60 Hz
  • Output Points: 16
  • Output Current: 0.5 A maximum per point, 3 A maximum per group
  • Response Time: Maximum 1 ms on - time, maximum ½ cycle off - time
  • Power Consumption: 315 mA (when all outputs are on) from 5 - voltage bus on backplane
  • Operating Temperature Range: 0°C to 60°C
  • Dimensions: Not fully specified, but typically suitable for standard PLC module installation spaces
  • Mounting Method: Can be installed in any I/O slot of a 5 - or 10 - slot baseplate in a Series 90 - 30 PLC system

GE IC300OCS110E

  • Input Voltage: The specific input voltage details are not fully provided, but it is known that it can support common industrial power supply voltages.
  • Output Power: The exact output power rating is not clearly stated in the available information.
  • Operating Temperature Range: Generally, similar power modules can operate in a range of -20℃ to +70℃, but this needs to be confirmed for the IC300OCS110E.
  • Protection Level: It may have a protection level of IP20 or higher, depending on the specific design.
  • Installation Method: Likely supports DIN - rail or panel - mounting, which is common for such modules.

GE IC693DNM200-CD

  • Rated Voltage: 12 - 24V DC (positive logic)
  • On - state Voltage Drop: 0.3V DC
  • Output Points: 32
  • Output Current: 0.5A per point, 4A per group, and a maximum of 3A per group common pin
  • Inrush Current: 5.4A for 10ms
  • On/Off Response Time: Maximum 0.5ms
  • Communication Protocol: DeviceNet
  • Data Rates: Supports 125K, 250K, and 500K Baud
  • Backplane Current Consumption: 450mA at 5V DC (typical)
  • Operating Temperature Range: 0℃ - 60℃
  • Storage Temperature Range: - 40℃ - 85℃
  • Mounting Location: In the main rack of Series 90 - 30 (any slot except slots 0 and 1), and in the main rack of PACSystems RX3i (any slot except slot 0)

GE IS200SPIDG1ABA

  • Input Voltage: 220V AC/DC (±15%)
  • Operating Temperature Range: - 30℃ to +65℃
  • Communication Protocol: Profibus DP, Modbus TCP/IP
  • Protection Level: IP20 (for indoor use)
  • Installation Method: DIN rail or panel mounting
  • Dimensions: 159mm (width) x 178mm (height) x 64mm (depth)
  • Weight: 1.0kg
  • Output Frequency: 50kHz
  • Certification: CE, UL, IEC 61131 - 2

GE IC693PWR321 Power Supply Module

Technical Specifications

  • Input Voltage:
    • Rated Voltage: 120/240 V AC
    • Voltage Range: 85-264 V AC
    • Frequency Range: 47-63 Hz
  • Output Voltage:
    • Primary Output: 5 V DC (for PLC logic circuits)
    • Secondary Output: 24 V DC (for I/O modules and peripherals)
  • Output Current:
    • 5 V DC Output: 4 A
    • 24 V DC Output: 1.5 A

GE IC697PWR711 Power Supply Module

Technical Specifications

  • Input Voltage:
    • Rated Voltage: 120/240 V AC
    • Voltage Range: 85-264 V AC
    • Frequency Range: 47-63 Hz
  • Output Voltage:
    • Rated Voltage: 24 V DC
    • Other Output Options: 5 V DC, 12 V DC (specific models may vary)
  • Output Current:
    • Maximum Output Current: 5 A (at 24 V DC)

GE 531X111PSHAPG2 Programmable Controller Module

Technical Specifications

  • Input Voltage: 24 VDC
  • Output Current: Maximum 2 A
  • I/O Configuration:
    • 8 digital input channels (voltage range: 5-30 VDC)
    • 8 digital output channels (voltage range: 5-30 VDC)
    • 4 analog input channels (12-bit resolution)
    • 4 analog output channels (12-bit resolution)
  • Communication Protocols: Supports ProfiBus, DeviceNet, EtherNet/IP, Ethernet, RS-232, and RS-485.
  • Operating Temperature: -20°C to 60°C
  • Storage Temperature: -40°C to 85°C

GE IC752DPA062A Power Supply Module

Technical Specifications

  • Input Voltage: 24 VDC (±10%)
  • Output Voltage: Configurable to meet system requirements (specific output details may vary based on configuration).
  • Power Capacity: Designed to support the power demands of PLCs and peripheral devices in industrial setups.
  • Operating Temperature: -20°C to 70°C
  • Storage Temperature: -40°C to 85°C
  • Relative Humidity: 5% to 95% (non-condensing)
  • Dimensions: Approximately 160 mm × 115 mm × 60 mm (may vary slightly based on specific design).

GE IC697CPX772-HD Communication Module

Technical Specifications

  • Processor: 96 MHz, 32-bit, 80486DX4 microprocessor
  • Memory:
    • 512 KB battery-backed RAM (for program and data storage)
    • 256 KB non-volatile user flash memory
  • I/O Capacity: Supports up to 2K inputs and outputs (any combination) and up to 8K analog I/O points
  • Communication Ports: Three serial ports for flexible networking options
  • Power Supply: 24 VDC (±10%)
  • Operating Temperature: -20°C to 70°C
  • Storage Temperature: -40°C to 85°C

GE IC697BEM763 Ethernet Communication Module

Technical Specifications

  • Manufacturer: GE Fanuc
  • Series: 90-70 Series
  • Type: Ethernet Communication Module
  • Communication Protocol: Ethernet/IP
  • Ports: 1 × 10/100 Mbps adaptive Ethernet port
  • Standards Supported: IEEE 802.3
  • Memory: Built-in large-capacity cache for stable data transmission
  • Processing Speed: High-speed data processing for real-time control applications

GE IC693PCM311H Communication Processor Module

Technical Specifications

  • Processor Type: 32-bit microprocessor for fast and stable data processing.
  • Memory:
    • RAM: 512 KB (expandable to 1 MB).
    • Program Storage: 512 KB flash memory.
    • Data Storage: 256 KB flash memory.
  • I/O Capacity:
    • Supports up to 1024 digital I/O points and 256 analog I/O points.
