GE VMIVME-7696

1. Core Architecture

  • Processor: Intel Pentium II processor with MMX™ technology, operating at 333 MHz or 450 MHz clock speeds. Features 32-bit addressing, 64-bit data bus, and dual independent bus architecture with 512 KB L2 cache for high bandwidth .
  • Memory:
    • SDRAM: Up to 512 MB via 144-pin SODIMM slots.
    • Non-Volatile Storage: 8–96 MB bootable flash on secondary IDE .
    • Battery-Backed SRAM: 128 KB for critical data retention during power loss .
  • Graphics: Integrated 64-bit AGP SVGA controller with 4 MB SGRAM, supporting resolutions up to 1,600 × 1,200 pixels .

GE VMIC-4941

1. Core Architecture

  • Function: Quad-Channel Synchro/Resolver-to-Digital Converter .
  • Channels: Four independent synchro/resolver input channels .
  • Resolution: Programmable 10-bit, 12-bit, 14-bit, or 16-bit digital output .
  • Bandwidth: Selectable 530 Hz (high-speed) or 130 Hz (high-precision) modes .
  • Accuracy: ±2.3 arc-minutes (optional enhanced precision) .
  • Reference Frequency: 360 Hz to 6 kHz (user-configurable) .

GE VMIVME-4514

1. Technical Specifications

Analog Input (AI) Channels

  • Channels: 16 independent channels .
  • Input Modes:
    • Differential (true differential signal pairs) .
    • Pseudo-differential (single-ended) .
  • Resolution: 12-bit analog-to-digital converter (ADC) .
  • Voltage Range: Programmable via on-board jumpers .
  • Filtering: Optional 36 Hz unipolar input filter .

GE VMIVME-7589

Processor & Architecture

  • CPU: Intel Pentium MMX processor at 166 MHz, 200 MHz, or 233 MHz clock speeds .
  • Data Bus: 64-bit data bus with 32-bit addressing .
  • Memory:
    • SDRAM: Up to 128 MB via 168-pin DIMM slots .
    • Non-Volatile Storage: 8 MB bootable flash on secondary IDE .
    • Battery-Backed SRAM: 32 KB for critical data retention during power loss .

GE VMIVME-2536

1. Core Architecture

  • Form Factor: 6U VMEbus single-slot Eurocard (233.4 mm × 160 mm × 20.3 mm) .
  • I/O Channels:
    • 32 optically isolated digital inputs (configurable as voltage/contact sensing).
    • 32 optically isolated digital outputs (open-collector, 300 mA sink current) .
  • Isolation:
    • System Isolation: 1,000V sustained to VME backplane; 3,500V transient for 1 second .
    • Channel-to-Channel Isolation: 500V sustained .
  • Power Requirements: +5VDC ±5% at 2.65A .

GE PCI-5565

Technical Specifications of GE PCI-5565 Reflective Memory Card

  1. Core Architecture:
    • Memory: 128 MB SDRAM (expandable to 256 MB in variants like PCI-5565PIORC-210000) .
    • Bus Interface: PCI 32-bit/33 MHz, compatible with 3.3V/5V signaling .
    • Data Transfer:
      • Speed: 43 MB/s (4-byte packets) to 174 MB/s (64-byte packets) .
      • Serial Baud Rate: 2.125 Gbps .
    • Network Scalability: Supports 256 nodes .

GE VME7807RC

  1. Core Architecture:
    • Processor: Intel Pentium M (1.1 GHz, 1.4 GHz, or 1.8 GHz variants) with up to 2 MB L2 cache .
    • Memory: 1.5 GB DDR SDRAM (expandable), 32 KB battery-backed SRAM for critical data retention .
    • Storage: Up to 2 GB bootable CompactFlash; supports SATA drives .
    • Bus Standard: VME64x/VME320 with A16/A24/A32/D32 addressing and BLT32/BLT64 block transfers .

GE VMIVME-7750-74

Comprehensive Technical Specifications of GE VMIVME-7750-74 Series

1. Core Architecture

  • Processor:
    • PowerPC 7447A at 1.267 GHz (aligned with Freescale PowerPC architecture) .
    • FPGA Coprocessor: Xilinx Virtex-5 SX95T for hardware-accelerated signal processing .
  • Memory:
    • 512 MB DDR2 SDRAM (onboard), expandable to 4 GB .
    • 256 MB Flash for firmware and critical data storage .
  • Data Bus:
    • VME64x backplane interface with A16/A24/A32/D32 addressing modes .
    • Support for BLT32/BLT64 block transfers.

GE VMIVME-7805

Technical Specifications of GE VMIVME-7805

  1. Core Architecture:
    • Processor: Intel Pentium 4 Processor-M (NetBurst microarchitecture) at 2.2 GHz, 478-pin Micro-FCPGA packaging .
    • Chipset: Intel 852GM with 400 MHz front-side bus .
    • Memory: Up to 1 GB PC2100 DDR SDRAM .
    • Graphics: Integrated SVGA controller with 4 MB DRAM display cache; supports resolutions up to 1,600 × 1,200 pixels .

GE PCIE-5565PIORC-100000

Technical Specifications

  • Interface: PCI Express (PCIe) x3.
  • Memory: 128 MByte onboard SDRAM.
  • Data Transfer Rates:
    • Minimum: 43 MB/s (4-byte packets).
    • Peak: 170 MB/s (64-byte packets).
    • Serial Baud Rate: 2.12 Gbaud.
  • Fiber Optic Support:
    • Multimode Range: 300 meters.
    • Single-Mode Range: 10 kilometers.
    • Network Capacity: Supports 256 nodes.
    • Operating Temperature:
      • Standard: 0°C to +65°C.
      • Industrial: -40°C to +85°C.
    • Cooling: Passive (fanless).
    • Compliance: RoHS, VCCI Class A, CISPR 22 EMC.

GE VMIPC4-7301

1. Technical Specifications

  • Form Factor: CompactPCI (cPCI) compatible module, designed for industrial backplane integration .
  • Processor Architecture: Intel x86-based processor (exact model unspecified, but aligned with GE's embedded computing platforms) .
  • Memory:
    • Supports onboard SDRAM (capacity not explicitly stated in evidence; comparable GE cPCI modules typically range from 64 MB to 1 GB) .
  • Interfaces:
    • Network: Integrated Fast Ethernet (10/100 Mbps) controller for industrial communication .
    • Expansion: Likely includes PCI Mezzanine Card (PMC) sites for I/O customization .
  • Operating Temperature: Industrial-grade range (0°C to +55°C inferred from similar VMIVME modules) .
  • Compliance: RoHS (Restriction of Hazardous Substances) certified .

GE VMIVME-7698

1. Technical Specifications

  • Processor:
    • Intel Celeron socket 370 processor (366 MHz PPG model) .
    • Supports 32-bit addressing and 64-bit data bus .
  • Memory:
    • SDRAM: 64 MB onboard (expandable up to 256 MB via 144-pin SODIMM) .
    • Flash Storage: 64 MB CompactFlash (optional) .
  • Graphics:
    • 64-bit Intel AGP SVGA controller with 2 MB SGRAM .
    • Supports resolutions up to 1,280 × 1,024 pixels (256 colors) .
