GE PQMII-T20

Technical Specifications

  • Voltage Measurement
    • Range: 100 V to 600 V phase-to-phase (direct connection); up to 34.5 kV with current transformers (CTs) and voltage transformers (VTs)
    • Accuracy: ±0.1% of reading (for voltage, current, power)
  • Current Measurement
    • Range: Up to 5 A (direct connection); scalable with CTs (up to 10,000 A)
    • Accuracy: ±0.1% of reading
  • Power Measurement
    • Active Power: ±0.1% of reading
    • Reactive Power: ±0.2% of reading
    • Apparent Power: ±0.1% of reading

GE IC800SSI228RD2-CE

Technical Specifications

Electrical Parameters
  • Input Voltage: 24V DC (±10%)
  • Rated Power: 228W
  • Output Current: 9.5A (continuous), 19A (peak)
  • Control Frequency: 0.5–200 Hz

GE IS210AEBIH3B AE Bridge Interface Board

Technical Specifications

  • Interface Type: Dual Ethernet ports supporting 10/100/1000 Mbps speeds
  • Communication Protocols: Supports standard industrial protocols including Ethernet/IP, Modbus TCP, and GE's proprietary Speedtronic communication protocols
  • Network Redundancy: Features such as Rapid Spanning Tree Protocol (RSTP) or link redundancy to ensure network reliability and continuous operation
  • Data Throughput: High bandwidth capacity to support real-time data exchange between controllers, HMIs, and diagnostic systems
  • Operating Voltage: Typically powered by the backplane within the Mark VIe chassis, with nominal voltage around 3.3V and 5V DC

GE 239-RTD-AN Motor Protection Relay with RTD Inputs

Technical Specifications

  • Sensor Type: Compatible with various RTD types, commonly Pt100 and Pt1000
  • Input Channels: Multiple channels for connecting several RTD sensors simultaneously
  • Measurement Range: Wide range to accommodate different temperature measurement needs, typically from -200°C to +850°C depending on the RTD type
  • Accuracy: High accuracy, often within ±0.1°C or better, ensuring reliable temperature readings
  • Resolution: High resolution for precise measurements, usually up to 16-bit or higher
  • Supply Voltage: Operates on standard industrial power supplies, typically 24V DC

GE DS200TCQCG1AJD Mark V Series RST Overflow / Analog I/O Expansion Board

Technical Specifications

  • Interface: Designed to interface with various sensors and actuators within a turbine control environment
  • Input Voltage: Operates on standard industrial power supplies, typically 24V DC or 125V DC depending on application requirements
  • Output Channels: Provides multiple output channels for controlling external devices such as valves and motors
  • Communication Protocols: Supports communication protocols relevant to industrial automation, including Modbus and proprietary GE protocols
  • Operating Temperature: Engineered to withstand harsh industrial environments, usually ranging from -40°C to +70°C
  • Humidity Range: Suitable for operation in environments with humidity levels from 0% to 95%, non-condensing
  • Physical Dimensions: Compact design suitable for integration into existing control cabinets
  • Compliance Standards: Meets international safety and EMC standards

GE IS215UCVEM08 Mark VI Controller Processor Module

Technical Specifications • Microprocessor: Intel Celeron 300 MHz • Memory: 32 MB DRAM • Storage: QNX real-time operating system pre-loaded • Ethernet: 10BaseT / 100BaseTX RJ-45 port on front panel • Serial Ports: COM1 and COM2 RS-232C • Auxiliary Interfaces: SVGA monitoring port (GE service use), PS/2 keyboard/mouse connector

GE VMIVME-2540 Intelligent Counter/Controller

1. Technical Specifications • Processor: on-board 15 MHz 68HC000 CPU • Counting depth: up to 4 billion events per channel • Frequency range: 1.16 × 10⁻³ Hz to 2.5 MHz • Period / pulse-width window: 400 ns to 8.5899 × 10⁶ s (32-bit floating-point) or 858 s (unsigned integer) • Channels: 4, 8, 16 or 24 software-selectable configurations • Output drive: 24 discrete outputs, ±10 V at 10 mA per channel, 12-bit resolution • Step rate for quadrature position control: up to 1.25 MHz with ¼-wave resolution • VMEbus interface: A32/A24/D32/D16/D8 slave, 64 kbyte memory window, ANSI/IEEE 1014-1987

GE IS210BPPCH1AD – Complete Technical Dossier

1. Identification & Overview IS210BPPCH1AD is a simplex analog input / output terminal board engineered by General Electric for the Mark VI Speedtronic turbine-control family. It mounts on DIN rail, uses surface-mount technology, and communicates with the VAIC processor via a single high-density cable.

GE PMC-0247RC-282000 350-93750247-282000F Compact Intelligent PLC & I/O Module for GE PACSystems RX3i

1. Technical Specifications • Input power: 24 VDC nominal (18–30 VDC range) • Output type: relay, 10 A maximum per channel • Communication: Ethernet/IP, Modbus TCP, serial RS-232/RS-485 • Processor: high-performance 32-bit CPU • Memory: large-capacity RAM and user Flash for program and data storage • Programming: IEC 61131-3 languages (LD, ST, FBD, SFC, IL) • Isolation: 2.5 kV channel-to-bus, 3 kV channel-to-channel • Dimensions: compact single-slot RX3i form factor, DIN-rail or rack mount • Operating temperature: –20 °C to +60 °C • Humidity: 5 %–95 % RH non-condensing • Protection: IP20 enclosure, vibration 2 g, shock 15 g

GE VMIVME-5576 High-Speed Fiber-Optic Reflective Memory Interface

  1. Hardware Architecture:
    • Core Function: VME-to-VME reflective memory interface for real-time data sharing .
    • Memory Capacity: 256 KB to 1 MB SRAM (configurable) .
    • Data Transfer Rate: Up to 6.2 MB/s .
    • Node Support: Up to 256 independent systems .
    • Bus Compatibility: VMEbus (ANSI/IEEE STD 1014-1987, IEC 821/297) .

GE IC698CPE020 Central Processing Unit

Technical Specifications

  1. Processor & Performance:
    • CPU Architecture: High-performance industrial-grade processor (exact chipset unspecified; Intel Atom/PowerPC equivalent inferred) .
    • Memory: ≥10 MB non-volatile flash storage; ≥10 MB user memory (battery-less retention via capacitor backup) .
    • Execution Speed: Sub-millisecond scan times for complex logic (comparable to IC698CPE030’s 0.072 ms/kBoolean instructions) .
    • I/O Capacity: Supports ≥32K discrete I/O points and ≥32K analog words .

GE IC695CPE310 PACSystems RX3i Controller — Full Technical Profile

Technical Specifications

  1. Processor & Performance:
    • CPU: 1.1 GHz Intel Atom processor.
    • Memory: 10 MB non-volatile flash storage; 10 MB user memory (battery-less retention via Energy Pack).
    • Execution Speed: 0.072 ms per 1,000 Boolean instructions.
    • I/O Capacity: Supports 32K discrete I/O points and 32K analog words.
