GE IC693CMM311S

Technical Specifications

  • Communication Protocols: Supports EtherNet/IP, Profibus, DeviceNet, and Modbus TCP/IP for seamless connectivity with various devices and systems.
  • I/O Configuration:
    • Discrete I/O: Up to 1024 digital inputs/outputs for binary signal processing.
    • Analog I/O: Up to 256 analog inputs/outputs for precise measurement and control of continuous signals (e.g., temperature, pressure).
  • Processor: 32-bit microprocessor with high-speed data processing (e.g., 0.3 ms/K logic scan rate for CPU340).

GE IC693CMM305Q

Technical Specifications

  • Communication Protocol: Supports Genius protocol for real-time data transmission.
  • Device Connectivity: Can communicate with up to 31 Genius devices per module (up to 62 devices per controller when two modules are used).
  • Data Transfer Rates:
    • Transmit: Up to 693 bytes of global data.
    • Receive: Up to 302 bytes of global data.
  • Register Support: Compatible with PLC registers including %G (Global), %I (Discrete Input), %Q (Discrete Output), %AI (Analog Input), %AQ (Analog Output), and %R (Register Memory).
  • Power Consumption: <5 mA at 300VDC backplane power.

GE IC693CHS399G

Technical Specifications

  • Slot Configuration:
    • 5 I/O slots for standard 90-30 Series I/O modules (e.g., discrete, analog, temperature, or RTD modules).
    • 1 dedicated power supply slot (requires a separate GE 90-30 Series power module, such as IC693PWR321).
    • 1 expansion port for connecting additional baseplates or remote I/O branches (cable length up to 50 feet / 15 meters).
  • Physical Dimensions:
    • Width: 10.43 inches (265 mm).
    • Height: 5.12 inches (130 mm).
    • Depth: 5.59 inches (142 mm).

GE IC693CHS398F

Technical Specifications

  • Slot Configuration:
    • 5 I/O slots for standard 90-30 Series I/O modules or specialized modules (e.g., analog, digital, high-speed counters).
    • 1 dedicated power supply slot (requires a separate power module for operation).
    • 1 expansion port for connecting additional baseplates or remote I/O branches.
  • Physical Dimensions:
    • Width: 10.43 inches (265 mm).
    • Height: 5.12 inches (130 mm).
    • Depth: 5.59 inches (142 mm).

GE IC693CHS391K

Technical Specifications

  • Series Compatibility: Series 90-30 PLC platform.
  • Slot Capacity: 10 expansion slots for modular components (e.g., I/O, power, communication).
  • Installation: Designed for field installation in industrial environments.
  • Structure: Modular form factor with standardized mounting for PLC components.
  • Power Requirements:
    • Voltage: 115 V AC (93–132 V AC operating range).
    • Frequency: 47–63 Hz.
    • Current Consumption: 0.4 A at +5 V (2 watts).

GE IC693BEM331K

Technical Specifications

  • Processor: 32-bit RISC CPU for high-speed data processing.
  • I/O Capacity: Handles up to 128 bytes of input/output data from field devices.
  • Communication Protocols: Supports Genius bus protocol for real-time data exchange with field devices.
  • Status Indicators:
    • OK LED: Steady illumination after power-on diagnostics confirms normal operation.
    • COM LED: Steady illumination indicates active communication; flashing signals intermittent connections or errors.
  • Environmental Tolerance:
    • Operating Temperature: -20°C to +60°C.
    • Storage Temperature: -40°C to +70°C.
    • Humidity: 5%–95% non-condensing.

GE IC693APU302R

Technical Specifications

  • Processor: 32-bit RISC CPU
  • Output Channels: 2 independent servo axes
  • Output Types:
    • Current: 0–20 mA, 4–20 mA
    • Voltage: 0–10 V, ±10 V
  • Resolution: 16-bit for precise position control
  • Update Rate: Up to 1000 updates per second per channel (configurable)
  • Memory: Flash storage for up to 10 motion programs and 40 subroutines

GE IC693APU302P

Technical Specifications

  • Input Voltage: 12–48 VDC
  • Output Voltage: 5 VDC
  • Output Current: Maximum 10 A
  • Efficiency: >90%
  • Processor: 32-bit RISC CPU
  • Dimensions: 170 mm (L) x 105 mm (W) x 32 mm (H)
  • Weight: Approximately 120 g
  • Operating Temperature: -20°C to +50°C

GE IC693ALG392-CG

Technical Specifications

  • Output Channels: 4 independent channels
  • Output Types:
    • Current: 0–20 mA, 4–20 mA
    • Voltage: 0–10 V, ±10 V
  • Resolution: 12-bit (standard), up to 16-bit (configurable for select models)
  • Accuracy:
    • Voltage Output: ±0.1% of full scale
    • Current Output: ±0.2% of full scale
  • Update Rate: 10 updates per second per channel (standard); up to 1000 updates per second (configurable for high-speed models)

GE IC693ALG391F

Technical Specifications

  • Expansion Capability:
    • Supports seven expansion racks connected via a daisy-chain arrangement.
    • Maximum interconnecting cable length: 15 meters (50 feet) between racks.
  • Slot Requirement: Occupies one single slot in the main or expansion rack.
  • Connectors:
    • One connector for attachment to the upstream or CPU rack.
    • One connector for linking to downstream expansion racks.
  • Bus Terminator: Requires an I/O Bus Terminator Plug (IC693ALG391F) in the last rack to ensure signal integrity.

GE IC693ALG391C

Technical Specifications

  • Output Channels: 2 independent channels
  • Current Output Ranges:
    • 0–20 mA
    • 4–20 mA
  • Voltage Output Ranges:
    • 0–5 VDC
    • 1–5 VDC
  • Resolution:
    • 4–20 mA: 4 µA (1 LSB = 4 µA)
    • 0–20 mA: 5 µA (1 LSB = 5 µA)
    • 1–5 V: 1 mV (1 LSB = 1 mV)
    • 0–5 V: 1.25 mV (1 LSB = 1.25 mV)

GE IS220PTURH1A

Technical Specifications

  • Input Voltage: 24 VDC
  • Output Voltage: 24 VDC
  • Current: 5 A
  • Communication: Dual 100Mb full - duplex Ethernet ports
  • Operating Temperature: - 40 °C to + 85 °C
  • Storage Temperature: - 55 °C to + 90 °C
  • Humidity: 5% to 95% RH, non - condensing
  • Vibration: 0.03 g rms, 5 Hz to 500 Hz
  • Shock: 15 g, 20 ms half - sine
