GE IC693360-BA

  • Processor: Not explicitly mentioned, but it is a 32 - bit - compatible processor.
  • Clock Speed: Not explicitly mentioned.
  • User Program Memory: 240 K bytes (configurable).
  • I/O Capacity: Supports up to 4096 discrete I/O points and 2048 analog I/O points (configurable).
  • Rack Support: Can support up to 8 racks.
  • Serial Ports: No built - in serial ports.
  • Power Supply: Requires 670 milliamps from a +5 VDC supply.
  • Memory Type: RAM and Flash.
  • Battery Life: With the original cache RAM component, the battery life was 6.5 years. The battery for the CPU is included in the CPU backplane box.

GE IC693352-OH

  • Processor Type: 80386ex
  • Clock Speed: 25 MHz
  • User Program Memory: Up to 240 Kbytes (for firmware version 9.0 and later)
  • Discrete Inputs: 2048
  • Discrete Outputs: 2048
  • Analog Inputs/Outputs: Configurable in increments of 128 words
  • Serial Ports: 3
  • Power Supply: 5V DC
  • Power Consumption: 890 milliamps load required from 5V DC power supply
  • Operating Temperature: 0°C to 60°C
  • Storage Temperature: - 40°C to 85°C

GE IC693351-KT

  • Processor Type: 80386ex
  • Clock Speed: 25 MHz
  • User Program Memory: 240 Kbytes (for firmware version 9.0 and later); 80 Kbytes for earlier firmware versions
  • Register Memory: Up to 32,640 words
  • Discrete Inputs: 2048
  • Discrete Outputs: 2048
  • Analog Inputs/Outputs: Up to 32,640 words (configurable)
  • Serial Ports: 3
  • Power Supply: 5V DC
  • Power Consumption: 890 milliamps load required from 5V DC power supply
  • Operating Temperature: 0°C to 60°C

GE Ic693351-ek

  • Processor Type: 80386ex
  • Clock Speed: 25 MHz
  • User Program Memory: 240 Kbytes (for firmware version 9.0 and later; 80 Kbytes for earlier firmware versions)
  • Register Memory: Up to 32,640 words
  • Discrete Inputs: 2048
  • Discrete Outputs: 2048
  • Analog Inputs: Up to 32,640 words (configurable)

GE IC693351-DG

  • Processor Type: 80386ex
  • Clock Speed: 25 MHz
  • User Program Memory: 240 Kbytes
  • Register Memory: Configurable from 128 to 32,640 words in 128 - word increments
  • Power Supply: 5V DC
  • Power Consumption: 890 milliamps load required from 5V DC power supply
  • Operating Temperature: 0°C to 60°C (32°F to 140°F)
  • Scan Rate: 0.22 ms per 1K of logic (Boolean contacts)
  • Serial Ports: 3 serial ports, supporting SNP slave and RTU slave

GE IC693350-DH

  • Processor Type: 80386ex
  • Clock Speed: 25 MHz
  • Memory: 32 KB of user - programmable memory with 19.9 K of register memory
  • I/O Ports: 8 analog inputs & 8 analog outputs
  • Communication Interface: RS - 485
  • Power Supply: DC 24V
  • Power Consumption: 670 milliamps load required from 5V DC power supply
  • Operating Temperature: 32°F to 140°F (0°C to 60°C)
  • Scan Rate: 0.22 ms typical scan rate per 1K of logic (Boolean contacts)

GE IC693331W

  • Processor Type: 80188
  • Clock Speed: 10 MHz
  • User Program Memory: 16 Kbytes
  • Register Memory: 4 Kbytes
  • Discrete Inputs: 512
  • Discrete Outputs: 512
  • Analog Inputs: 128 words
  • Analog Outputs: 64 words
  • Serial Port: 1, supporting SNP/SNP - X slave protocols
  • Scan Rate: 0.4 ms typical per 1 k of logic (Boolean contacts)

E IC693331L的

  • Processor Type: 80188
  • Clock Speed: 10 MHz
  • Scan Rate: 0.4 milliseconds per 1K of boolean logic
  • User Program Memory: 16K bytes
  • Discrete Inputs: 512
  • Discrete Outputs: 512
  • Analog Inputs: 128 words
  • Analog Outputs: 64 words
  • Serial Port: 1, supporting SNP/SNP - X slave protocols
  • Power Consumption: 350 mA at +5 VDC
  • Operating Temperature: 32°F to 140°F (0°C to 60°C)

GE IC693331-EE

  • Processor Type: 80188
  • Clock Speed: 10 MHz
  • Scan Rate: 0.4 ms typical per 1 k of logic (Boolean contacts)
  • User Program Memory: 16 kbytes
  • Register Memory: 4 kbytes
  • Discrete Inputs: 512
  • Discrete Outputs: 512
  • Analog Inputs: 128 words
  • Analog Outputs: 64 words
  • Serial Port: 1, supporting SNP/SNP - X slave protocols
  • Power Consumption: 350 mA from 5V DC power supply
  • Operating Temperature: 32 to 140°F (0 to 60°C)

GE IC693313S

  • Processor Type: 80188
  • Clock Speed: 10 MHz
  • Scan Rate: 0.6 milliseconds per 1 k of logic (Boolean contacts)
  • User Program Memory: 12 kbytes (6 kbytes before release 7)
  • I/O Points: Supports up to 160 discrete input points and 160 discrete output points, 64 words for analog input and 32 words for analog output.
  • Serial Port: Has one serial port that supports SNP slave and SNP - X slave protocols.
  • Power Consumption: Requires a load power supply of 430 mA at 5V DC.
  • Operating Temperature: 32 to 140 degrees Fahrenheit (0 to 60 degrees Celsius)

GE IC693310-EP

  • Rated Voltage: 120V AC
  • Output Voltage Range: 85 - 132V AC, 50/60Hz
  • Output Current per Point: 0.5A max.
  • Output Current per Group: 1A max. at 140°F (60°C), 2A max. at 122°F (50°C)
  • Inrush Current: 5A max. for one cycle
  • Minimum Load Current: 50mA
  • Maximum Output Voltage Drop: 1.5V
  • Maximum Output Leakage Current: 3mA at 120V AC
  • On - Response Time: 1ms max.
  • Off - Response Time: 1/2 cycle max.
  • Power Consumption: 210mA (all outputs on) from 5V bus on backplane

GE IC693CMM311F

  • Communication Protocols: Supports GE Fanuc CCM, RTU (Modbus) slave, and SNP protocols.
  • Ports: Has two serial ports. Port 1 supports RS - 232, and port 2 supports either RS - 232 or RS - 485.
  • Internal Power: 400 mA at 5 VDC.
