GE IC752CCS049C

Technical Specifications

  • Display Type: Color TFT LCD with LED backlight (specific resolution and size may vary based on manufacturer documentation).
  • Processor: Typically includes an embedded processor for real-time data processing and graphical rendering.
  • Memory: Built-in flash memory for storing application data, configurations, and historical logs.
  • Communication Ports:
    • Ethernet port(s) for network connectivity (e.g., 10/100 Mbps).
    • Serial ports (RS-232/RS-485) for legacy device integration.
    • USB ports for firmware updates or data transfer.

GE IC698ETM001-DK

Technical Specifications

  • Processor: 200 MHz Ethernet processor for high-speed data handling.
  • Memory: Flash storage for protocol and configuration data, supporting firmware upgrades via CPU serial port.
  • Ethernet Ports:
    • 2 × 10/100 Mbps auto-sensing RJ-45 ports with full-duplex/half-duplex auto-negotiation.
    • Crossover cable detection and network speed adjustment.
  • Power Requirements:
    • Operating Voltage: +5 VDC (±5%).
    • Current Consumption: 1.5 A (maximum).

GE IC698ETM001-CD

Technical Specifications

  • Processor: 200 MHz Ethernet processor
  • Memory: Flash storage for protocol and configuration data
  • Ethernet Ports:
    • 2 × 10/100 Mbps auto-sensing RJ-45 ports
    • Full-duplex/half-duplex automatic negotiation
    • Crossover cable detection and network speed adjustment
  • Power Requirements:
    • Operating Voltage: +5 VDC
    • Current Consumption: 1.5 A (maximum)

GE IC698CRE020-FF

Technical Specifications

  • Processor: 1.6 GHz Intel Pentium M microprocessor
  • Memory:
    • 512 MB RAM (battery-backed for data retention during power loss)
    • 256 MB Flash NVRAM (non-volatile storage for firmware and user programs)
  • Power Requirements:
    • Operating Voltage: 18–32 VDC
    • Current Consumption: 1.5 A (typical)
  • I/O Expansion:
    • Supports up to 12 I/O modules via VME64 backplane
    • Compatible with analog/digital input/output, temperature control, and motion control modules

GE IC698CPE020-GM

Technical Specifications

  • Processor: Intel Pentium III 700 MHz floating-point microprocessor
  • Memory:
    • 10 MB RAM (volatile memory, requires CMOS battery backup)
    • 10 MB Flash NVRAM (non-volatile memory for firmware and user data storage)
  • Operating Voltage: 24 V DC (5–12 V DC range for flexibility)
  • Current Rating: 4.3 A
  • Communication Ports:
    • 2 × 10/100 Mbps Ethernet ports (RJ-45)
    • 3 × serial ports (RS-232, RS-485, and station manager port)

GE IC697VRM015-B

Technical Specifications

  • Dimensions: 170 mm × 125 mm × 167 mm
  • Weight: 1.5 kg
  • Input Voltage: 25.8 VDC
  • Output Frequency: 16 Hz
  • Power Consumption: 2.48 W
  • Current Consumption: 804 mA
  • Program Capacity: 44 KB
  • Operating Temperature Range: 0°C to 60°C
  • Storage Temperature Range: -40°C to 85°C

GE IC697PWR724D

Technical Specifications

  • Input Voltage:
    • AC: 100–240 VAC (50/60 Hz, wide-range global compatibility)
    • DC: 18–32 VDC (alternative input option)
  • Output Specifications:
    • 5 VDC: Rated 10 A (max 50 W), powers CPU and digital I/O modules.
    • 24 VDC: Rated 2 A (max 48 W), supplies sensors, actuators, and low-power peripherals.
  • Efficiency: Typical 85% at full load, meeting industrial-grade energy standards.

GE IC697PWR710

Technical Specifications

  • Input Voltage:
    • AC: 90–264 VAC (47–63 Hz)
    • DC: 100–150 VDC
  • Output Voltage:
    • Nominal: 5.1 VDC
    • Range: 4.90–5.25 VDC
  • Power Capacity:
    • Maximum Input Power: 90 W (at full load)
    • Maximum Output Power: 56 W
    • Output Current: Up to 11 A

GE IC693MDL240G

  • nput Voltage: 0 - 132 VAC, with a nominal voltage of 120 VAC.
  • Input Current: 12 mA per channel at rated voltage.
  • Input Frequency: 47 - 63 Hz.
  • Number of Channels: 16.
  • Isolation: 1500 volts RMS between field side and logic side.
  • On - State Voltage: 74 - 132 VAC.
  • Off - State Voltage: 0 - 20 VAC.
  • On - Response Time: Maximum 30 ms.
  • Off - Response Time: Maximum 45 ms.

GE IC693MDL240E

  • Input Voltage: 0 - 132 VAC, with a nominal voltage of 120 VAC.
  • Input Current: 12 mA per channel.
  • Input Frequency: 47 - 63 Hz.
  • Number of Channels: 16.
  • Isolation: 1500 volts RMS between field side and logic side.
  • On - State Voltage: 74 - 132 VAC.
  • Off - State Voltage: 0 - 20 VAC.
  • On - Response Time: Maximum 30 ms.
  • Off - Response Time: Maximum 45 ms.

GE IC693374-FN

  • Processor: Embedded 586, with a speed of 133 MHz.
  • Memory: User memory is 240 KB configurable, and system memory is 512 KB. The memory type is RAM and Flash.
  • I/O Points: 2048 discrete fixed points (1024 input, 1024 output). The configurable register memory is 128 to 32,640 words, and the configurable analogue inputs and outputs are also 128 to 32,640 words each.
  • Communication Ports: It has 2 built - in Ethernet 10/100 Base - T/TX ports with auto - sensing, and an RJ - 45 connection. There are no built - in serial ports.
  • Power Requirements: Requires 7.4 watts from a 5 - volt DC supply.
  • Operating Temperature: 0 to 55 °C (32 to 131 °F).
  • Storage Temperature: - 40 °C to + 85 °C.
  • Certifications: UL 508, c - UL (Class I, Div II, A, B, C, D), CE mark.

GE IC693363-D

  • Processor: 32 - bit processor, with a main frequency of 200MHz.
  • Memory: Program memory capacity is 512KB, and data memory capacity is 256KB.
  • I/O Capacity: Supports up to 4096 discrete I/O points and 2048 analog I/O points.
  • Communication Interfaces: Built - in Ethernet, RS - 232, and RS - 485 interfaces.
  • Power Consumption: Requires 890 milliamps from a 5V DC power supply.
  • Operating Temperature: 0 to 60°C (32 to 140°F).
