GE IS215UCVEM08 Mark VI Controller Processor Module

Technical Specifications • Microprocessor: Intel Celeron 300 MHz • Memory: 32 MB DRAM • Storage: QNX real-time operating system pre-loaded • Ethernet: 10BaseT / 100BaseTX RJ-45 port on front panel • Serial Ports: COM1 and COM2 RS-232C • Auxiliary Interfaces: SVGA monitoring port (GE service use), PS/2 keyboard/mouse connector

GE VMIVME-2540 Intelligent Counter/Controller

1. Technical Specifications • Processor: on-board 15 MHz 68HC000 CPU • Counting depth: up to 4 billion events per channel • Frequency range: 1.16 × 10⁻³ Hz to 2.5 MHz • Period / pulse-width window: 400 ns to 8.5899 × 10⁶ s (32-bit floating-point) or 858 s (unsigned integer) • Channels: 4, 8, 16 or 24 software-selectable configurations • Output drive: 24 discrete outputs, ±10 V at 10 mA per channel, 12-bit resolution • Step rate for quadrature position control: up to 1.25 MHz with ¼-wave resolution • VMEbus interface: A32/A24/D32/D16/D8 slave, 64 kbyte memory window, ANSI/IEEE 1014-1987

GE IS210BPPCH1AD – Complete Technical Dossier

1. Identification & Overview IS210BPPCH1AD is a simplex analog input / output terminal board engineered by General Electric for the Mark VI Speedtronic turbine-control family. It mounts on DIN rail, uses surface-mount technology, and communicates with the VAIC processor via a single high-density cable.

GE PMC-0247RC-282000 350-93750247-282000F Compact Intelligent PLC & I/O Module for GE PACSystems RX3i

1. Technical Specifications • Input power: 24 VDC nominal (18–30 VDC range) • Output type: relay, 10 A maximum per channel • Communication: Ethernet/IP, Modbus TCP, serial RS-232/RS-485 • Processor: high-performance 32-bit CPU • Memory: large-capacity RAM and user Flash for program and data storage • Programming: IEC 61131-3 languages (LD, ST, FBD, SFC, IL) • Isolation: 2.5 kV channel-to-bus, 3 kV channel-to-channel • Dimensions: compact single-slot RX3i form factor, DIN-rail or rack mount • Operating temperature: –20 °C to +60 °C • Humidity: 5 %–95 % RH non-condensing • Protection: IP20 enclosure, vibration 2 g, shock 15 g

GE VMIVME-5576 High-Speed Fiber-Optic Reflective Memory Interface

  1. Hardware Architecture:
    • Core Function: VME-to-VME reflective memory interface for real-time data sharing .
    • Memory Capacity: 256 KB to 1 MB SRAM (configurable) .
    • Data Transfer Rate: Up to 6.2 MB/s .
    • Node Support: Up to 256 independent systems .
    • Bus Compatibility: VMEbus (ANSI/IEEE STD 1014-1987, IEC 821/297) .

GE IC698CPE020 Central Processing Unit

Technical Specifications

  1. Processor & Performance:
    • CPU Architecture: High-performance industrial-grade processor (exact chipset unspecified; Intel Atom/PowerPC equivalent inferred) .
    • Memory: ≥10 MB non-volatile flash storage; ≥10 MB user memory (battery-less retention via capacitor backup) .
    • Execution Speed: Sub-millisecond scan times for complex logic (comparable to IC698CPE030’s 0.072 ms/kBoolean instructions) .
    • I/O Capacity: Supports ≥32K discrete I/O points and ≥32K analog words .

GE IC695CPE310 PACSystems RX3i Controller — Full Technical Profile

Technical Specifications

  1. Processor & Performance:
    • CPU: 1.1 GHz Intel Atom processor.
    • Memory: 10 MB non-volatile flash storage; 10 MB user memory (battery-less retention via Energy Pack).
    • Execution Speed: 0.072 ms per 1,000 Boolean instructions.
    • I/O Capacity: Supports 32K discrete I/O points and 32K analog words.

GE 469-P5-HI-A20-E-H Motor Management Relay

  1. Electrical Parameters:
    • Input Voltage: 90–300 VDC or 70–265 VAC @ 48–62 Hz .
    • Analog Output: 4–20 mA .
    • Power Consumption: 25 W .
    • Rated Current: 5A (phase CT secondaries) .
  2. Environmental Ratings:
    • Operating Temperature: -40°C to +60°C .
    • Humidity Tolerance: 95% non-condensing .
    • Protection Rating: IP54 (dust/water-resistant) .
    • Pollution Degree: 2 (industrial environments) .

GE IS220PSVOH1A Servo I/O Module

echnical Specifications

  1. Electrical Parameters:
    • Input/Output Voltage: 24 V DC .
    • Input/Output Current: 2.5 A .
    • Power Consumption: ~25 W .
  2. Environmental Ratings:
    • Operating Temperature: -40°C to +70°C .
    • Storage Temperature: -40°C to +85°C .
    • Humidity Tolerance: 5%–95% RH (non-condensing) .
    • Protection Rating: IP20 (standard) .

GE VME7740-841 High-Performance VMEbus Single-Board Computer

VMEbus Single-Board Computer (SBC) Technical Specifications

  • Form Factor: 6U VMEbus (233 mm × 160 mm)
  • Processor: PowerPC G4 (MPC7448) running at 1.0 GHz or higher variants
  • Memory:
    • Up to 1 GB of DDR SDRAM (ECC support available)
    • Boot flash memory for firmware and system software

GE IC698CPE040-FJ Central Processing Unit Designed for RX7i PACSystems

Technical Specifications

  • Model Number: IC698CPE040-FJ
  • Series: Proficy PACSystems RX3i
  • Processor: High-speed 32-bit or 64-bit RISC processor
  • Memory:
    • RAM: 64 MB (user memory)
    • Flash Memory: 64 MB (for firmware and program storage)
  • Execution Speed:
    • Boolean instructions: Approximately 1.5 nanoseconds per instruction
    • Integer instructions: Approximately 2.5 nanoseconds per instruction

GE DS200FCGDH1B

Category: Field Control Gate Distribution Card for Drive Systems

Technical Specifications
  • Manufacturer: General Electric
  • Series: Mark V
  • Function: Interface system for six-pulse phase-controlled non-reversible bridges
  • Signal Processing: Receives and decrypts information from the Digital Signal Processing Card (DSPC)
  • Feedback Signals: Handles frequency, voltage, and board status information
  • Communication: Uses integrated VME backplane for signal transmission
  • LED Indicators: Integrated IMOK LED for basic system status indication
  • Environmental Conditions: Designed for industrial environments with appropriate temperature and humidity ratings
